PLEASE RETAIN
Ardmore
Boiler Solid Fuel Stove
INSTALLATION AND OPERATING INSTRUCTIONS
This appliance is hot while in operation and retains its heat for a long period of time after use. Children,
aged or infirm persons should be supervised at all times and should not be allowed to touch the hot
working surfaces while in use or until the appliance has thoroughly cooled.
When using the boiler stove in situations where children, aged and/or infirm persons are present a fire-
guard must be used to prevent accidental contact with the stove. The fireguard should be
manufactured in accordance with BS 8423:2002.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ardmore and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Stanley Ardmore

Summary of Contents for Stanley Ardmore

  • Page 1 PLEASE RETAIN Ardmore Boiler Solid Fuel Stove INSTALLATION AND OPERATING INSTRUCTIONS This appliance is hot while in operation and retains its heat for a long period of time after use. Children, aged or infirm persons should be supervised at all times and should not be allowed to touch the hot working surfaces while in use or until the appliance has thoroughly cooled.

  • Page 2: Table Of Contents

    Stanley Solid Fuel Stove Warranty ........
  • Page 3 TABLE OF CONTENTS PAGE NO. 45. Prolonged Periods of Non Use ........... . . 17 46.
  • Page 4 Note: Adequate clearance must be maintained around the appliance to ensure the ease of part removal in the possible event of their damage/failure. Waterford Stanley are not responsible for any costs incurred in the removal of items installed in the vicinity of the appliance that have to be moved to facilitate a part replacement.

  • Page 5: Installation Checklist

    INSTALLATION CHECK LIST Tick Flue System 1. Minimum Flue Height of 4.6 metres (15 feet). 2. Appliance should be connected to a 125mm (5”) flue pipe within a metre and then the flue size increased to a minimum of 150mm (6”) diameter. 3.

  • Page 6: Important Operation/ Maintenance Notes

    IMPORTANT OPERATION / MAINTENANCE NOTES Now that your Stanley Solid Fuel Stove is installed and no doubt you are looking forward to many comforts it will provide, we would like to give you some tips on how to get the best results from your stove.

  • Page 7: Installation & Operating Instructions

    Buildings. method for determine what regulations are in force. Save these calculation of the design heat load. instructions for future reference. Your Ardmore stove is supplied with the following items: Please note that it is a legal requirement under Eng- •...

  • Page 8: Flue Exit - Top And Rear

    The stove must be connected to a chimney with a FLUE EXIT (TOP & REAR) minimum continuous draught of 0.06 w.g. Poor draught conditions will result in poor performance. The stove is designed to allow the chimney be cleaned through the stove. If the chimney cannot be All register plates, restricter plates, damper etc., cleaned through the stove it is necessary to provide which could obstruct the flue at a future date should...

  • Page 9: Down Draughts

    VENTILATION & COMBUSTION AIR REQUIRE- Fig.4 MENTS It is imperative that there is sufficient air supply to the stove in order to support correct combustion. The air supply to this appliance must comply with current Building Regulations Part J, Heat Providing Appli- Blanking ances.
  • Page 10 If there is an extraction fan fitted in adjacent rooms EXTERNAL DUCTED AIR where this appliance is fitted, additional air vents may be required to alleviate the possibility of spillage of An outside air kit complete with primary air supply products of combustion from the appliance/flue while can be ducted from outside and is available to order the fan is in operation.

  • Page 11: Location

    2. Fit a CO Alarm which has been approved to EN 50291. LOCATION There are several conditions to be considered in se- lecting a location for your Stanley Ardmore Stove. a. Position in the area to be heated, central locations are usually best. PLUMBING b.

  • Page 12: Regulations

    INJECTOR TEE REGULATIONS Where the gravity and central heating circuits join to- The plumbing must be in accordance with all gether to return to the stove we recommend the use relevant regulations and practices. It must include a of an injector tee connection, situated as close to the gravity circuit with expansion pipe, open to the atmos- unit as possible.

  • Page 13: Flue & Water Pipe Locations

    Fig.10 FLUE & WATER PIPE LOCATIONS Flue outlet to suit 125mm (5”) internal diameter flue pipe. Water outlets 25mm (1”) B.S.P. Fig.11...

  • Page 14: Stove Dimensions

    STOVE DIMENSIONS Fig.12 WARNING: DO NOT OBSTRUCT PRIMARY AIR SUPPLY TO THE STOVE Note: Dimensions stated are in millimetres unless otherwise stated and may be subject to a slight +/- variation. COMMISSIONING AND HANDOVER OPERATION On completion of the installation allow a suitable pe- Check that all dampers and catches are operating riod of time for any fire cement and mortar to dry out, correctly and ensure that all flue connections are...

  • Page 15: Recommended Fuels

    Fig.13 In the event where a stove is fitted to a central heat- ing system which is undersized in relation to the nominal heat output to boiler then the stove will op- erate satisfactorily but will be unable to achieve the nominal heat output to room as the thermostatic damper will shut off the air supply to prevent an over- heat situation in the boiler.

  • Page 16: Technical Data

    Model Class Room Water Index Fuel Output Efficiency Ardmore HPB SF Stove 99.03 Wood 74.5 LIGHTING Before lighting the stove check with the installer, that the installation work and commissioning checks de- scribed previously have been carried out correctly and the chimney has been swept clean, is sound and free from any obstructions.

  • Page 17: Refuelling

    REFUELLING DISPOSAL OF ASHES Riddle the fire by pulling the grate riddling knob back and forward (See Figure 15). Before opening Your stove is provided with a steel ashpan. This ash- pan should be emptied every day. the door, turn the thermostat knob to setting 4 as this will help to eliminate any smoke or fly ash resi- If ashes are allowed to build to grate level you could dent in the combustion chamber.

  • Page 18: Chimney Cleaning

    Fig 17 Fig 19 Flue Exits Removable Boiler Baffle Fire Grate Ashpan MONTHLY MAINTENANCE CHIMNEY CLEANING Adjusting the Door Catch The chimney should be cleaned twice annually or if the stove is not used for a prolonged period during Over time, the fire door latch can loosen due to the the summer period, it should be cleaned prior to com- continual compression and hardening of the rope mencement of usage.

  • Page 19: Vitreous Enamel Cleaning

    VITREOUS ENAMEL CLEANING PROLONGED PERIODS OF NON USE If the stove is to be left unused for a prolonged period General cleaning must be carried out when the stove of time then it should be given a thorough clean to re- is cool.

  • Page 20: Glass Replacement

    CO ALARM (d) While awaiting the fire department watch for ignition to adjacent combustibles from over- The fitting of CO Alarms in the same room as the ap- heated flue pipe or from embers or sparks pliance is a compulsory requirement under current from the chimney.

  • Page 21: Exploded View

    ARDMORE SF BOILER EXPLODED VIEW FLUE BLANKING PLATE - B00006AXX 26. SERIAL NUMBER PLATE - N00234BXX FLUE SPIGOT - B00007BXX 27. GLASS - T00102AXX OPERATING TOOL - B00009DXX 28. AIR CONTROL KNOB - U00006AXX BASE - B00620AXX 29. SECONDARY AIR CONTROL...
  • Page 22 NOTES...
  • Page 23 NOTES...
  • Page 24 Manufactured by Waterford Stanley Ltd., Unit 401-403, IDA Industrial Estate, Cork Road, Waterford, Ireland. Tel: (051) 302300 Fax (051) 302315 YS 160517 Item No: N00569AXX Rev:007...
