Depending on the conditions of use, installation and
environment, please be sure to make the appropriate settings
and adjustments. If you need help with installation and/or
settings, please consult your dealer.
CONTENTS
PRECAUTIONS .................................................. 2
PARTS NAMES .................................................. 3
MOUNTING THE LENS ...................................... 5
CONNECTIONS.................................................. 7
SETTINGS .......................................................... 8
TROUBLESHOOTING...................................... 13
SPECIFICATIONS ............................................ 14
1
English
FEATURES
• Built-in interline transfer method 1/4" CCD, approx.
320,000 picture elements
• Equipped with a DSP (Digital Signal Processor) function
• Horizontal resolution, more than 350 TV lines
• High sensitivity, minimum required illumination is 0.9 lux
(F1.2)
• Two types of backlight compensation functions (multi-spot
photometry and center focus photometry)
• Low smear, anti-blooming, low lag, no burning and no
geometric distortion using the CCD solid state image
device.
• 100% solid state components giving excellent immunity to
shock and vibration
• Not subject to interference from magnetic or electrostatic
fields
• Power supply: 24 V AC and 12 V DC operation
• Use a DC type auto-iris lens.
