Cornelius I SERIES Installation Instructions

INSTALLATION INSTRUCTIONS
Item No. Part No.
1 620701902
2 620701901
3 620505801
4 50456
5 621701903
6 620037006
7 70171
8 50377
9 50309
10 631500000*
NOTE: *The installation of a Bin Stat Kit is optional and is suggested for locations where high humidity
conditions are encountered. Disregard Steps 6 through 10, 13 and 14 if a Bin Stat Kit is not used.
!
WARNING:
Disconnect power to the unit before installing the adaptor following all lockout/tag out procedures established by the
user. Verify that all the power is off to the unit before performing any work.
Failure to comply could result in serious injury, death or damage to the equipment.
!
WARNING:
All ice baffle plates and bin stats, if included or recommended in this kit, must be installed as directed in this manual or
the equipment manufacturer's instructions.
Failure to comply could result in serious injury, death or damage to the equipment.
!
WARNING:
All of the attachment screws and plates must be installed as directed in this manual.
Failure to comply could result in serious injury, death or damage to the equipment.
Refer to Figure 1 and Figure 2
1. Remove the manual fill cover from the unit.
2. Empty all ice out of dispenser into clean and sanitary containers or plastic bags.
3. Use plastic insulation strip (item 3) as a drill template. Place edge of template flush with front edge of "J" channel
and center left to right on adapter. Tape in place.
4. Drill (4) 3/16" diameter holes using care to catch and remove all metal shavings from the dispenser.
5. Remove tape and the plastic insulator strip.
6. Mount optional Bin Stat Kit (P/N 631500000) as instructed, except for the Bin Stat capillary tube mounting.
7. Pull 32" of capillary out of bottom of the ice maker. Slit and place plastic sleeve (item 9) over the capillary tube
leaving 6" of bare capillary tube exposed between capillary "S" bend and sleeving.
8. Assembly (2) 1/8" plastic clamps (item 8) to the back side of the SS baffle (item 6) with (2) 8-32 x 3/8" screws
(item 7) and plastic acorn nuts (item1). Do not tighten.
Revision Date: April 04, 2014
© 1997-2014, Cornelius Inc.
Cornelius "I" Series Ice Maker ED300 Ice Baffle Kit Installation Instructions
F C
OR ORNELIUS
ED300 I B
CE AFFLE
Table 1. Loose Shipped Parts
Acorn Nut, 8-32 Nylon
Sealing Washer
Insulation Strip - ED300
Clamp, 1/423 Nylon
#8 Nylon Washer
Baffle, Ice ED300
8-32 x 3/8 SS Phil. Head Screw
Clamp, 1/823 Nylon
Tubing, Vinyl 1/8 x 1/2
Bin Star Kit
www.cornelius.com
"I" S I M
ERIES CE
K , P/N 629082901
IT
Name
- 1 -
AKER
Publication Number: 620908301
Qty.
6
4
1
2
2
1
2
2
26"
1
Revision: C
