Component Locations – Console & Valves (Figure 7)
Component Locations – Drive System & Drain Pump (Figure 8)
Specifications
Voltage:
Frequency:
Max. Amps:
Circuit Protection:
Water Pressure:
Drain Height:
Operating Temperature Range:
DO NOT REMOVE OR
DESTROY
FOR SERVICE TECHNICIAN'S USE ONLY
Hot Water
Valve
Main Control Board
Drive Belt and
Pulley Shield
Drive Motor
(Under Shield)
Motor Pulley
Drive Motor
Connector
Drive Belt
Shaft Pulley
WASHER SPECIFICATIONS
Cold Water
Coin Slide
Valve
Temperature
Interface
Thermistor
Module
Water Temperature
Encoder
Shifter Assy
Motor Capacitor
100-135 VAC
15 Amp Instantaneous Type Fuse (Main Control)
34 in. to 8 ft. (86 cm to 244 cm)
40 - 115° F (4.5 - 46° C)
Pressure Transducer
Air Hose
Shifter Assy
Connector
Drain Pump
Pump Outlet Hose
57-63 Hz
12 Amps
15-125 PSI
PAGE 19
