To fit the draw-bar:
1. Slide the drawbar into approximate position ensuring tow hitch is the
correct way up (See FIG 6, on Page 17).
2. Loosely fit rear attachment bolts (See FIG 8, on Page 18).
3. Attach draw bar to tow-ball on ATV or other towing vehicle.
4. Attach cable protector tube to drawbar in position shown (See FIG 9
on Page 19).
5. Fit adjustment bolts and nuts as per the illustrations on Pages 17.
Adjusting the angle of sled
As shown in FIG 6 on Page 17, a gap of 25mm at the point shown should suffice
for most pasture. Experience will determine the best angle for the terrain being
traversed.
The operator should exercise care and common sense when determining
the speed to be traveled. The equipment is designed to travel at up to
20kph on ideal terrain. If the surface is rough, or if obstacles are present,
then a much slower speed should be used.
