- Page 1 NOVA AND DROP-IN COLD AND NEUTRAL UNITS COLD BASIN D-I CB FROST PLANE D-I FrP CRUSHED ICE BASIN D-I CIB NEUTRAL UNIT N SERVING COUNTER SB TYPE: 450, 800, 1200, 1600 Installation and Operation Manual S/N: 10990607100010 Rev.: 1.1...
- Page 3 Dear Customer, Congratulations on deciding to choose a Metos appliance for your kitchen activities. You made an excellent choice. We will do our best to make you a satisfied Metos customer like thousands of customers we have around the world.
- Page 4 11.2.2008 Rev. 1.1...
-
Page 5: Table Of Contents
5.4 Installation of drop-in units ................... 9 5.4.1 All units ........................9 5.4.2 Cold units D-I CB and D-I FrP ................11 5.5 Installation of Nova units .................... 12 5.6 Electrical connections ....................12 5.7 Start-up ........................12 5.7.1 Cold basin and frost plane ................... 12 6. - Page 6 11.2.2008 Rev.
-
Page 7: General
11.2.2008 Rev. 1.1 General 1. General Carefully read the instructions in this manual as they contain important information re- garding proper, efficient and safe installation, use and maintenance of the appliance. Keep this manual in a safe place for eventual use by other operators of the appliance. The installation of this appliance must be carried out in accordance with the manufactur- er’s instructions and following local regulations. -
Page 8: Safety
11.2.2008 Rev. 1.1 Safety 2. Safety 2.1 Safe use of the appliance For safe use of the appliance, observe the following safety instructions: • When moving or servicing the appliance, always unplug it from the power supply. • While cleaning the appliance, be cautious not to allow the electrical devices to come into contact with water. -
Page 9: Functional Description
11.2.2008 Rev. 1.1 Functional description 3. Functional description 3.1 Intended use of the appliance The appliance is intended for short-time storage and distribution of foodstuffs in dining rooms and restaurants. The manufacturer shall not be held liable for situations which may arise from failure to comply with the warnings and instructions given in this manual. -
Page 10: Functional Description
11.2.2008 Rev. 1.1 Functional description 3.2 Functional description The cold basin and frost plane are equipped with a refrigeration unit. The crushed ice basin is insulated, but it does not include a refrigeration unit. 3.2.1 Operating switches Cold basin and frost plane Main switch Thermostat Condenser... -
Page 11: Operating Instructions
11.2.2008 Rev. 1.1 Operating instructions 4. Operating instructions 4.1 Operation 4.1.1 Cold basin CB and frost plane FrP Before placing products in the unit, wait until it has reached the temperature set with the thermostat. Correct cold storage of foodstuffs facilitates kitchen activities and affects energy con- sumption: •... -
Page 12: After Use
4.2 After use 4.2.1 Emptying the basin Nova and drop-in units have a drain valve beneath the basin. Water can be emptied by opening this valve. The units are fitted with a 1 m drain hose to carry water into an emp- tying vessel. -
Page 13: Replacing The Lamp
11.2.2008 Rev. 1.1 Operating instructions 4.2.3 Replacing the lamp Switch off the luminaire at the mains before replacing the lamp. To avoid damaging the starter, it is advisable to replace the lamp before the end of its serv- ice life. The starter cannot be replaced. Lever Lamp holder Lamp... -
Page 14: Installation
11.2.2008 Rev. 1.1 Installation 5. Installation 5.1 Operating conditions The appliance is designed for operation at temperatures of +10°C to + 25°C. The appliance should not be placed close to bain-maries or ovens. 5.2 Transport and storage The appliance should be transported to the installation site in its transport package. Do not remove package until in the immediate vicinity of the installation place. -
Page 15: Installation Of Drop-In Units
11.2.2008 Rev. 1.1 Installation 5.4 Installation of drop-in units Drop-in units are installed inside a separately built counter. The counter must be fitted with an installation opening; for measurements, see drawings in “Technical specifica- tions” at the end of this manual. Sufficient space must be provided under the table top ac- cording to the installation drawings (see “Technical specifications”). - Page 16 11.2.2008 Rev. 1.1 Installation The drop-in unit is mounted on the table top with its own weight, and no separate insula- tion is required. If desired, the junction of the drop-in unit and table top can be sealed with silicone. If you want to have the collar of the drop-in unit flush with the table top, you can make a recess for the collar in the table top.
-
Page 17: Cold Units D-I Cb And D-I Frp
11.2.2008 Rev. 1.1 Installation 5.4.2 Cold units D-I CB and D-I FrP Condenser air circulation Air for the condenser must enter from outside the counter. The panel in front of the refrig- eration unit must be fitted with a grid or perforation to ensure fresh air inlet for the con- denser. -
Page 18: Installation Of Nova Units
After connecting the appliance to the power supply, turn on the main switch (green) and make sure that the indicator light of the switch lights up. In case you have problems with taking the appliance into use, contact the Metos service. -
Page 19: Troubleshooting
In case the appliance does not function as expected, review the following list of problems to find out if the appliance can be put in order without a service call. In all enquiries, please contact the nearest Metos service. Most problems can be managed on the phone. PROBLEM... - Page 20 11.2.2008 Rev. 1.1 Troubleshooting...
-
Page 21: Technical Specifications
11.2.2008 Rev. 1.1 Technical specifications Technical specifications Connection diagram S00142 A4 Installation drawing X01979 A3 Measurements, drop-in 450 Measurements, drop-in 800 Measurements, drop-in 1200 Measurements, drop-in 1600... - Page 22 Connection diagram S00142 A4...
- Page 23 Installation drawing X01979 A3...
- Page 24 11.2.2008 Rev. 1.1 Technical specifications Measurements, drop-in 450...
- Page 25 11.2.2008 Rev. 1.1 Technical specifications Measurements, drop-in 800...
- Page 26 11.2.2008 Rev. 1.1 Technical specifications Measurements, drop-in 1200...
- Page 27 11.2.2008 Rev. 1.1 Technical specifications Measurements, drop-in 1600...
- Page 28 11.2.2008 Rev. 1.1 Technical specifications Item Model Specification Electrical connection 230V 50Hz Power input, refrigeration unit CB,FrP 0,43 kW Power input, lamp CIB,N 18/30 W Refrigerant CB,FrP R134a Insulation material CB,FrP,CIB Foamed polystyrene Control unit CB,FrP Thermostat CB=COLD BASIN D-I CB, FrP=FROST PLANE D-I FrP, CIB=CRUSHED ICE BASIN D-I CIB, N=NEUTRAL UNIT N, SB=SERVING COUNTER SB...
