BOTTLE COOLER Mistral Language support missing in EDD! M60, M90, TC60 Users Manual S/N:Manual Rev.: 2.0... - Page 2 Dear Customer, Congratulations on deciding to choose a Metos appliance for your kitchen activities. You made an excellent choice. We will do our best to make you a satisfied Metos customer like thousands of customers we have around the world.
-
Page 3: Symbols Used In The Manual
8.7.2011 Rev. General 1. General Carefully read the instructions in this manual as they contain important information re- garding proper, efficient and safe installation, use and maintenance of the appliance. Keep this manual in a safe place for eventual use by other operators of the appliance. The installation of this appliance must be carried out in accordance with the manufactur- er’s instructions and following local regulations. -
Page 4: Safety Instructions In Case Of Malfunction
8.7.2011 Rev. Safety instructions 2. Safety instructions 2.1 Safe use To guarantee the efficiency of the Mistral bottle coolers equipped and to ensure its proper operation, it is essential to adhere to the directions provided by the manufacturer and to make sure that any maintenance work is carried out exclusively by professionally quali- fied staff. -
Page 5: Functional Description
Functional description 3. Functional description 3.1 General Mistral M60 ja Mistral M90 are bottle coolers, placing backbar or underbar. Mistral M90 can also get with sliding door. [M60,M90] Mistral TC60 is high bottle cooler, placing backbar. 3.2 Designed use of appliance Mistral bottle coolers are designed for cooling and storage of deverages. -
Page 6: Use Instructions
8.7.2011 Rev. Use instructions 4. Use instructions 4.1 Use Mistral Bottle Coolers must be earthed. Plug in and switch on at the main. Check that the light is working. The light switch is located inside the appliance, on the top right hand side. - Page 7 8.7.2011 Rev. Use instructions Remove the front grid cover. Clean the compressor coil with a brush and vacuum cleaner every three months or when it´s dirty.[TC60] 4.2.2 Service Any maintenance and reparation operations are to be carried out exclusively by qualified person.
-
Page 8: Installation
5.2 Installation Install the appliance on perfectly level. Mistral M60 and Mistral M90 bottle coolers can install backbar or underbar. They don‘t require clearance for air circulation at the back or sides.[M60,M90] Mistral TC60 install at the backbar. It requires clearance of 40 mm at the back of the ap- pliance.[TC60]... - Page 9 8.7.2011 Rev. Installation Remove hinge cover and hinge from right hand side. Remove door from unit and the remove hinge pins and door handle from door. Refit items in reverse order, to opposite sides of the units. Refit the hinge pins using Lock- tite studlock.
- Page 10 8.7.2011 Rev. Installation Remove grid cover by moving cover upwards and unhooking bottom of cover from case. Remove hinge and lock bracket. Move hinge pin from right to left hand side of the door. Seruce using Locktite stud- lock. Move handle from left to right hand side of door. Refit hinge and lock bracket.
-
Page 11: Technical Informations
8.7.2011 Rev. Technical informations 6. Technical informations... - Page 12 Wiring diagram M60,M90 [M60,M90]...
- Page 13 Wiring diagram TC60 [TC60]...
