- Page 1 ICE FLAKE MAKER WITHOUT BIN AIR-CONDENSED WATER-CONDENSED TYPE: Muster 350, Muster 800 Installation and Operation Manual S/N: Rev.: 2.4...
- Page 3 Dear Customer, Congratulations on deciding to choose a Metos appliance for your kitchen activities. You made an excellent choice. We will do our best to make you a satisfied Metos customer like thousands of customers we have around the world.
- Page 4 18.9.2007 Rev. 2.4...
-
Page 5: Table Of Contents
18.9.2007 Rev. 1. General ......................1 1.1 Symbols used in the manual ..................1 1.2 Symbols used on the appliance ..................1 1.3 Checking the relation of the appliance and the manual ..........1 2. Safety instructions ..................2 2.1 Safe use .......................... 2 2.1.1 Modifications ...................... - Page 6 18.9.2007 Rev. 6. Troubleshooting ..................13 7. Technical specifications ................15...
-
Page 7: General
18.9.2007 Rev. 2.4 General 1. General Carefully read the instructions in this manual as they contain important information re- garding proper, efficient and safe installation, use and maintenance of the appliance. Keep this manual in a safe place for eventual use by other operators of the appliance. The installation of this appliance must be carried out in accordance with the manufactur- er’s instructions and following local regulations. -
Page 8: Safety Instructions
18.9.2007 Rev. 2.4 Safety instructions 2. Safety instructions 2.1 Safe use To guarantee the efficiency of the automatic ice flake maker equipped and to ensure its proper operation, it is essential to adhere to the directions provided by the manufacturer and to make sure that any maintenance work is carried out exclusively by professionally qualified staff. -
Page 9: Functional Description
18.9.2007 Rev. 2.4 Functional description 3. Functional description 3.1 General In making ice flake only cold, pure drinking water, should be used. Because ice flakes are mainly used for cooling of beverages for internal use, shall the quality of water used in making ice flake be considered as important as the pureness and good storage of any oth- er food products. -
Page 10: Use Instructions
18.9.2007 Rev. 2.4 Use instructions 4. Use instructions 4.1 Use In making ice flakes, only cold, clean drinking water, should be used. Because ice flakes are mainly used for cooling of beverages for internal use, shall the quality of water used in making ice flakes be considered as important as the pureness and good storage of any other food products. -
Page 11: After Use
18.9.2007 Rev. 2.4 Use instructions Check that the scraper is turning in the clockwise direction. 4.2 After use 4.2.1 Cleaning Unplug the power cable from the socket, before you start cleaning operations. For cleaning operations from surfaces, including subsequent ones, use an ordinary deter- gent for washing dishes or a solution of water and 10 % of vinegar. -
Page 12: Layup
18.9.2007 Rev. 2.4 Use instructions 4.2.2 Layup If you do not intend using the automatic ice flake maker for a certain period of time, pro- ceed as follows: • Unplug the power cable from the socket. • Shut off the water supply by turning off the taps provided during installation. •... -
Page 13: Installation
18.9.2007 Rev. 2.4 Installation 5. Installation 5.1 General The automatic ice flake maker is delivered attached to a special wooden pallet and pro- tected with cardboard packaging. Installation must be carried out exclusively by qualified and authorized staff, in compliance with current national standards and following the manufacturer’s instructions. -
Page 14: Unpacking
18.9.2007 Rev. 2.4 Installation 5.5 Unpacking Remove the cardboard packaging by cutting the straps that hold it in place; then slide it off from the top. Once you have removed the packaging, make sure that the automatic ice flake maker is in perfectly good condition. -
Page 15: Disposal Of Packaging
18.9.2007 Rev. 2.4 Installation 5.6 Disposal of packaging All the packaging items (plastic bags, cardboard, polystyrene foam, nails, etc.) must not be left within reach of children, in that they are potential sources of danger. 5.7 Installation The ice flake maker can be installed on a shelves or on a container. If the ice flake maker installing on the existing structure, it´s recommended doing the technical checking, that come out if the structure are strong as necessary. -
Page 16: Connection To Power Supply Mains
18.9.2007 Rev. 2.4 Installation 5.9 Connection to power supply mains The electrical wiring system scheme is attached inside of the rear panel of the ice flake maker. To reach this, unplug the power cable from the socket, loosen the screws, which fasten the front panel and slide it away. - Page 17 18.9.2007 Rev. 2.4 Installation Where the feed water is particularly hard, you are advised to install a softener. Any solid particles (e.g., sand) may be eliminated by installing a mechanical filter, which must be periodically inspected and cleaned. These filters must be in compliance with the relevant national standards in force.
-
Page 18: Ventilation
18.9.2007 Rev. 2.4 Installation Make sure that: • The internal diameter of the pipe is 22 mm, as required. • The water outlet pipe is not throttled in any point throughout its length. • The outlet pipe get down at least 15 % downwards on its entire length and there are no air pockets in the pipe. - Page 19 18.9.2007 Rev. 2.4 Troubleshooting 6. Troubleshooting Should the appliance fail to produce ice, before calling on the Authorized Technical Serv- ice Centre, first check carefully that: • The water supply tap provided in the istallation phase is open (see fig.). •...
- Page 20 18.9.2007 Rev. 2.4 Troubleshooting Appliance functions, but does not There is no coolant gas Find leakage, fix it, vacuumize and fill make proper ice Warm gas valve leaks Fix or change the valve Compressor does not pump Change the compressor Air condensed models Check the fan, change if needed Condenser fan does not function...
- Page 21 Technical specifications 7. Technical specifications Electric diagram Muster 350 Electric diagram Muster 350 Electric diagram Muster 350 (valid from 2006 05 25) Electric diagram Muster 800 (valid from 2006 05 25) Installation drawing Muster 350 Installation drawings Muster 800 Installation on double roller bin...
- Page 22 Electric diagram Muster 350...
- Page 23 Electric diagram Muster 350...
- Page 24 Electric diagram Muster 350 (valid from 2006 05 25)
- Page 25 Electric diagram Muster 800 (valid from 2006 05 25)
- Page 26 18.9.2007 Rev. 2.4 Technical specifications Installation drawing Muster 350 MUSTER 350 900 mm 472 mm 60 mm 437 mm 120 mm 187 mm 451 mm 257 mm Water OUT, diam. 24 mm Water IN, condensator, diam. 3/4” Water IN, evaporator, diam. 3/4”...
- Page 27 18.9.2007 Rev. 2.4 Technical specifications Installation drawings Muster 800 MUSTER 800 1107 mm 575 mm 65 mm 540 mm 125 mm 192 mm 554 mm 262 mm Water OUT, diam. 24mm Water IN, condensator, diam. 3/4” Water IN, evaporator, diam. 3/4” Power cable...
- Page 28 18.9.2007 Rev. 2.4 Technical specifications Installation on double roller bin...
- Page 29 Weight net 290 kg Weight gross 150 kg Weight gross 328 kg Rerfrigerant R404A 800g Rerfrigerant R404A 550g Rerfrigerant R404A 1900g Rerfrigerant R404A 1200g A=AIR-CONDENSED, W=WATER-CONDENSED 350=Muster 350, 800=Muster 800 A=3/N/PE∼400/230V 50Hz, B=∼250V 16A 50Hz, H=3/PE∼230V 50Hz, I=3/PE∼220V 60Hz, M=3/PE∼440V 60Hz...
