GREER Company MicroGuard 586 Quick Manual

1. System Self-Test:
begins when turned on.
• Alarm indicators light up
• Display windows appear black
• Audible alarm sounds
The crane model is displayed.
Next, the setup code window displays the last
configuration when powered off.
Check that the correct setup code is displayed
before operating the crane.

2. Configuration Selection

upon system power up; but can also be
entered by pressing the SETUP key.
Steps:
1: O/R or RUBBER?•
•
Select On Outriggers or
•
Press OK
2: ERECTED ATTACHMENT?
•
Select NONE or 10' Boom Extension
•
Press OK
3: STOWED ATTACHMENT?
•
Select NONE or 10' Boom Extension
•
Press OK
4: PARTS-OF-LINE?
•
Select 1 OR 2
•
Press OK
The system will exit the configuration mode and
return to the normal operation screen.
Configuration Codes:
100:1 100:2 101:1
or
O/R or RUBBER?• O/R or RUBBER?•
On Outriggers
ERECTED ATTACHMENT? ERECTED ATTACHMENT?
NONE
STOWED ATTACHMENT? STOWED ATTACHMENT?
NONE
PARTS-OF-LINE? PARTS-OF-LINE?
1 or 2
If On Rubber is selected in
110:1
step 1, O/R or RUBBER?,
O/R or RUBBER?•
instead of On Outriggers,
then configuration codes
ERECTED ATTACHMENT?
and selections are the same
but in the 200's instead of
the 100's:
200:1 200:2
or
201:1 201:2
or
210:1

3. Normal Operation

: is required
• "Rated Capacity" = heaviest load the crane
can lift in the current crane configuration.
• "Percent of Rated Capacity" = how near the
operation is to full capacity and overload.
On Rubber
The green zone = normal operating limits.
• Note: The displayed capacity will move to
the left of the bar graph when the bars
value exceeds 60%.
101:2
or
On Outriggers
• "Actual Load" weight includes the load plus
the weight of everything hanging below the
NONE
boom (hook block, etc.).
• "RADIUS" followed by • " ANGLE"/"LENGTH"
10' Boom Extension
of the Boom. The select arrow keys can
1 or 2
toggle between Boom ANGLE and LENGTH.
• Internal faults, use the select arrow keys to
view to the fault messages.
On Outriggers
Warning: You must select the correct crane
10' Boom Extension
configuration code number for each setup
configuration change. Inaccurate or non-
selection will result in incorrect calculations of
the actual load weight and Percent of Rated
Capacity.
