Features and Packing List Features • Simultaneously displays an Ultra HD source on up to two Ultra HD displays or additional splitters • Specifically designed to support 10 layers of splitting/cascading in large video distribution and signage applications, supporting hundreds of displays. •...
Page 7
The 4K Ultra HD 1:2 Splitter for HDMI ships with the items listed below. If any of these items are not present in your box when you first open it, immediately contact your dealer or Gefen. • 1 x 4K Ultra HD 1:2 Splitter for HDMI •...
Introduction Page Title Panel Layout Out 1 Out 2 Fast Slow 4K Ultra HD 1:2 Splitter Multi-ch for HDMI Audio EDID Power 5V DC page | 2...
Page 13
Introduction Page Title Name Description Out 1, Out 2 Connect an Ultra HD display to each of these ports using HDMI cables. Locking HDMI cables can be used on each port. FST (Fast / Slow) Use this slider switcher to switch between Fast and Slow FST (Fast Switching Technology) modes.
Connect the included AC power cord from the power supply to an available electrical outlet. Sample Wiring Diagram HDMI CABLE 4K Ultra HD Source 4K Ultra HD 1:2 Splitter for HDMI 4K Ultra HD Display or additional 4K Ultra HD Splitter GTB-HD4K2K-142C-BLK page | 4...
Installation Cascading Splitters The 4K Ultra HD 1:2 Splitter for HDMI provides the capability to “cascade” (daisy-chain) up to 10 splitters. This feature not only provides you with the means to cascade multiple 4K Ultra HD 1:2 Splitter for HDMI units, but also to combine the 4K Ultra HD 1:8 Splitter for HDMI and/or the 4K Ultra HD 1:4 Splitter for HDMI as well.
WITCHING ECHNOLOGY Fast Switching Technology Fast Switching Technology (FST) is a Gefen software implementation for HDMI products. FST was created to improve the lengthy HDMI authentication process, based on the HDMI and HDCP specifications. FST provides quicker audio/video source switching and greatly improves the overall audio/ video system behavior and performance when more than one HDTV display is used in the system setup.
Setting the Switching Mode Using Slow Mode When set to slow switching mode, the 4K Ultra HD 1:2 Splitter for HDMI will follow the standard authentication process, based on the HDMI and HDCP specifications. Slow mode is recommended when the source does not support multiple devices. Out 1 Out 2 Disconnect the power supply from the splitter.
Setting the Audio Channel Mode The 4K Ultra HD 1:2 Splitter for HDMI features a switch that will switch between 2-channel and multichannel audio output. Information In order for the audio channel mode to be selected, the EDID switch must be set to the Int position. If the EDID switch is set to the Ext position, then the Audio switch will have no effect on the audio output signal.
Setting the Audio Channel Mode Out 1 Out 2 Using Multichannel Audio Use this audio mode when the connected displays (and/or other sink devices) are capable of supporting multichannel audio. Disconnect the power supply from the splitter. Fast Set the EDID switch to the Int (up) position. Slow Set the Audio switch to the Multi-ch (down) position.
Setting the EDID Mode The 4K Ultra HD 1:2 Splitter for HDMI features EDID Management. Before the source can send video and/or audio to the display (sink), the source reads the EDID (Extended Display Identification Data) from the display (sink) devices connected to the splitter. The EDID contains information about what type of audio/video data that the source can send to each output device.
Surface Mount Instructions The 4K Ultra HD 1:2 Splitter for HDMI should be mounted vertically in a wall or cabinet with wood/drywall screws as shown in the diagram above. There should be an inch or two of clearance between the edges of the unit and any walls or vertical surfaces to allow for enough clearance for insertion and retraction of cables at the HDMI connectors.
USB-to-Mini-USB cable • Firmware file Download the firmware from the Gefen Web site. Extract the firmware file from the .ZIP file. Power-Off the 4K Ultra HD 1:2 Splitter for HDMI. It is unnecessary to disconnect any HDMI cables from the splitter during the update process.
Specifications Supported Formats Resolutions (max.) • 4K DCI (4096 x 2160 at 24 Hz) • 4K Ultra HD 60 (3860 x 2160 at 60 Hz, 4:2:0 color space) • 1080p Full HD • 1920 x 1200 (WUXGA) Connectors, Controls, and Indicators Video Input •...
