Alcatel 29362 User Manual

29362
Speaker Call ID phone
Telephone
User's Guide
I
NTRODUCTION
Your Caller ID phone stores and displays specific
information, provided by your local telephone company,
to subscribers of Caller ID or similar caller identification
services. You must subscribe to one of these services in
order to use this unit.
Your Caller ID phone enables you to:
! Identify callers before you answer the phone.
!
Record up to 58 Caller ID messages sequentially.
! Know who called while you were away.
To get the most from your new phone, we suggest that
you take a few minutes right now to read through this
user's guide.
IMPORTANT: To know who is calling while you are on
the phone, you must subscribe to Caller ID with Call
Waiting Service. To have other options, you must subscribe
to Call Waiting with Options. To receive indication that
you have a voice mail message waiting, you must subscribe
to Voice Mail Service. Contact your local telephone
company to subscribe.
B Y B
EFORE OU EGIN
P C
ARTS HECKLIST
Make sure your package includes the items:
1. Handset Coiled Cord
2. Corded Handset
3. Base
4. Telephone Line Cord
5. Instruction book
M J R
ODULAR ACK EQUIREMENTS
You need an RJ11 type modular phone jack, which is the
most common type of phone jack. If you don't have a
modular jack, call your local phone company to find out
how to get one installed.
I T P
NSTALLING HE HONE
D I
ESKTOP NSTALLATION
1. Plug the coiled cord into the corded handset and the base.
2. Remove the battery compartment door.
3. Insert 3 sized AA batteries. (Not include in package) The
unit will be at its optimal performance provided that you
have installed the 3 pieces AA sized dry batteries.
4. Put the compartment door back on.
5. Plug the telephone line cord into the modular jack and
into the TEL. LINE jack on the back of the base.
NOTE: The phone automatically defaults to touch-tone dialing.
To change to pulse (rotary) dialing, see "Tone/Pulse Dialing". If
you don't know which type of service you have, check with the
phone company.
LCD Display Icons
1. : SPEAKERPHONE
2. : LOW BATTERY INDICATOR
3. MUTE : MUTE
4. : NUMBER OF CALLS
5. NEW : NEW CID
6. : VOICE MAIL
7. REP : REPEAT
8. : TIME
9. : DATE
M D
10. AM : MORNING
11. PM : AFTERNOON
12. Call Waiting : CALL WAITING
F K
UNCTION EY
1. SPEAKER
2. REDIAL
3. VOL
4. CONTRAST
5. STORE
6. DIAL
7. FLASH
8. MUTE
9. DEL
10. <REVIEW>
11. MENU
S U
ET P
T /P D S
ONE ULSE IALING ELECTION
1. Move T/P switch in the bottom by tool to set dialing
mode. (T: tone or P: pulse.)
NOTE: The phone is shipped in Tone Dialing Mode from the
manufacturer.
F T S
LASH IME ETTING
1. Move FLASH switch in the bottom by tool to set
FLASH timing. (100ms/300ms/600ms.)
D A T S
ATE ND IME ETTING
1. Press "MENU" button, LCD displays "SET < OR >".
2. Press "< " OR ">" button to select the menu "DATE/
TIME" and press the "MENU" button to enter
3. Press "< " OR ">" button to input the year, date and time.
4. Press "MENU" button to save the setting and return to
the latest menu.
5. Press "FLASH" button to return to the idle mode.
L A C S
OCAL REA ODE ETTING
1. Press "MENU" button, LCD displays "SET < OR >".
2. Press "< " OR ">" button to select the menu "LOCAL
AREA CODE" and press the "MENU" button to enter.
3. Press 0~9 button to input the local area code number.
4. Press "MENU" button to save the setting and return to
the latest menu.
5. Press "FLASH" button to return to the idle mode.
L D C S
ONG ISTANCE ODE ETTING
1. Press "MENU" button, LCD displays "SET < OR >".
2. Press "< " OR ">" button to select the menu "LONG
DIST CODE" and press the "MENU" button to enter.
3. Press 0~9 button to input the long distance code number.
4. Press "MENU" button to save the setting and return
to the latest menu.
5. Press "FLASH" button to return to the idle mode.
L S
ANGUAGE ETTING
1. Press "MENU" button, LCD displays "SET < OR >".
2. Press "< " OR ">" button to select the menu "SELECT
LANGUAGE" and press the "MENU" button to enter.
3. Press "< " OR ">" button to select the language.
4. Press "MENU" button to save the setting and return
to the latest menu.
5. Press "FLASH" button to return to the idle mode.
R L S
INGER EVEL ETTING
T
here are total 3 ring levels. (HI/MID/LO)
1. Move ring volume switch in the back of the base to
set Ringer level.
R V
ECEIVE OLUME
There are total 3 receive volume levels. (HI/MID/LO)
While on the phone, press the "VOL" button to adjust the
receive volume of handset or speaker.
(Volume "Lo" displays " ", "Mid" displays " ",
"Hi" displays " ".)
P B
HONE ASICS
I U I
N SE NDICATOR
The "IN USE" indicator will light up when the phone is
on the line.
S I
PEAKER NDICATOR
The SPEAKER indicator will light up when the speaker is
activated.
R A C
ECEIVING ALL
1. Check the display to see who is calling.
2. Press the "SPEAKER" button or pick up the handset
to answer the phone.
3. Press the "SPEAKER" button again or put the handset
on cradle to hang up.
M A C
AKING ALL
To make a call, press the "SPEAKER" button or pick up the
handset before you dial and press "SPEAKER" button again
or put the handset on cradle to hang up.
OR Pre-dialing
Input the telephone number (no more than 32 digits), then
press "SPEAKER" button or pick up the handset, the
number will be dialed out automatically.
R
EDIAL
1. Press "REDIAL" button while the phone is off.
2. Press the "REDIAL" button repeatedly to review redial
telephone list.
3. Press "SPEAKER" button or pick up the handset, the
number displayed on the LCD will be dialed out
automatically.
OR
1. Press "SPEAKER" button or pick up the handset.
2. Press "REDIAL" button to dial the last number redial.
C
ONTRAST
1. Press "CONTRAST" button repeatedly to adjust LCD
contrast. Total 5 contrast levels .
F
LASH
Use the FLASH button to activate custom calling
services such as call transfer, which are available
through your local telephone company.
Don't use SPEAKER button to activate custom calling
services, or you'll hang up the phone.
M
UTE
1. Press "MUTE" button, LCD display "MUTE" and "MIC
MUTE". The phone is on mute .
2. Press "MUTE" button again to cancel mute mode. Or
press "SPEAKER" button to switch handset to
speaker mode.
C ID F
ALLER EATURES
This unit receives and displays information transmitted
by your local phone company is running with FSK or
DTMF system.
The unit can store 58 calls (14 digits and 15 characters)
for later review.
