AXIS P9106-V Network Camera
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P9106-V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Axis P9106-V

Summary of Contents for Axis P9106-V

  • Page 1 AXIS P9106-V Network Camera User Manual...

  • Page 2: Table Of Contents

    AXIS P9106-V Network Camera Table of Contents Solution overview ......... . .

  • Page 3: Solution Overview

    AXIS P9106-V Network Camera Solution overview Solution overview...

  • Page 4: Product Overview

    AXIS P9106-V Network Camera Product overview Product overview Status LED microSD card slot Focus ring Control button Network connector (PoE)

  • Page 5: How To Access The Product

    HTTPS connection and then change the password. The device password is the primary protection for the data and services. Axis devices do not impose a password policy as they may be used in various types of installations. To protect your data we recommend that you: •...

  • Page 6: Setup

    AXIS P9106-V Network Camera Setup Setup About the product's built-in help You can access the built-in help from the product’s webpage. The help provides more detailed information on the product’s features and their settings. Image quality How to select exposure mode There are different exposure mode options in the camera that adjusts aperture, shutter speed, and gain to improve image quality for specific surveillance scenes.
  • Page 7 AXIS P9106-V Network Camera Setup How to create a privacy mask To create a privacy mask, go to Settings > Privacy mask . How to enhance facial recognition To better recognize the face of a person passing by the camera, you can set the optimal pixel resolution with the camera’s pixel counter.

  • Page 8: Overlays

    Image with WDR. Note WDR may cause artifacts in the image. Find out more about WDR and how to use it at axis.com/web-articles/wdr How to maximize details in an image Important If you maximize details in an image, the bitrate will probably increase and you might get a reduced frame rate.

  • Page 9: Streaming And Storage

    H.264 or MPEG-4 Part 10/AVC Note H.264 is a licensed technology. The Axis product includes one H.264 viewing client license. Installing additional unlicensed copies of the client is prohibited. To purchase additional licenses, contact your Axis reseller. H.264 can, without compromising image quality, reduce the size of a digital video file by more than 80% compared to the Motion JPEG format and by as much as 50% compared to the MPEG-4 standard.

  • Page 10: Events

    Make sure the AXIS Video Motion Detection application is running: 1. Go to Settings > Apps > AXIS Video Motion Detection. 2. Start the application if it is not already running. 3. Make sure you have set up the application according to your needs.

  • Page 11: Applications

    Add audio capability to your product Even though your Axis network video product has no built-in audio capability, it is still possible to add this functionality, by using a product from the AXIS T61 Series Audio and I/O Interface (supplied separately), which effectively provides microphone capability where it does not exist.
  • Page 12 The AXIS T61 Series product can be used to good effect in situations such as interview rooms. The Axis network video product is mounted on the wall or ceiling to give good visual coverage, while the AXIS T61 Series product can be mounted, for example, on or...

  • Page 13: Troubleshooting

    AXIS P9106-V Network Camera Troubleshooting Troubleshooting If you can’t find what you’re looking for here, try the troubleshooting section at axis.com/support How to reset to factory default settings Important Reset to factory default should be used with caution. A reset to factory default resets all settings, including the IP address, to the factory default values.

  • Page 14: Technical Issues, Clues And Solutions

    Axis product. Check all cabling and reinstall the product. Possible IP address conflict The static IP address in the Axis product is used before the DHCP server sets a dynamic address. with another device on the...

  • Page 15: Performance Considerations

    The TTL (Time To Live) value may need to be increased. No multicast H.264 Check with your network administrator that the multicast addresses used by the Axis product displayed in the client are valid for your network.
  • Page 16 Heavy network utilization due to poor infrastructure affects the bandwidth. • Viewing on poorly performing client computers lowers perceived performance and affects frame rate. • Running multiple AXIS Camera Application Platform (ACAP) applications simultaneously may affect the frame rate and the general performance.

  • Page 17: Specifications

    AXIS P9106-V Network Camera Specifications Specifications To find the latest version of the product’s datasheet, go to the product page at axis.com and locate Support & Documentation. LED Indicators Note • The Status LED can be configured to flash while an event is active.

  • Page 18: Connectors

    AXIS P9106-V Network Camera Specifications Connectors HDMI Connector The HDMI connector is not used by this product and it is not possible to get a video stream from it. Network connector RJ45 Ethernet connector with Power over Ethernet (PoE).
  • Page 19 User Manual Ver. M1.8 AXIS P9106-V Network Camera Date: October 2018 © Axis Communications AB, 2018 Part No. T10129997...
