Overview
The iQ 16 Sync Charge Box unit is a compact, portable and robust sync and charge station that provides high
current charging and synchronisation capability for up to 16 Tablet devices - from a large number of Tablet
and portable electronic device manufacturer's that utilise USB charging.
Carry Handle
Host Computer
USB Connector
(Type-B)
Tablet device
USB Connectors
(Type-A)
Cushioned Feet
(Rear and Bottom
sides)
Specification.
Dimensions: 250 x 216 x 66mm (10"x 8"x 2½")
Weight: 2.5 kg (5.95 lbs)
Operating Temperature: 0 to 70 Degrees Celsius (32 to 158 Degrees Fahrenheit)
Input: 250V AC, 50Hz, 1.7A (USA: 120V AC, 60Hz, 3.5A)
Output: 5V DC, 2.1A (x16)
USB Standard: USB1.1 and USB2.0 data rates supported up to 480Mbps
INSTRUCTION MANUAL
Power Switch
IEC Connector
Power Inlet and
Operating Mode
LED Indicators
Ventilation Holes
Fuse
