Summary of Contents for PC Locs FUYL Tower

  • Page 1 USER INSTRUCTIONS FUYL Tower™ www.pclocs.com.au www.lockncharge.com...
  • Page 2 Follow these instructions for easy and fast set-up of your FUYL Tower. Overview The FUYL Tower is an integrated secure storage and charge station for mobile devices, with a central electronic access control panel. The product has individually secured bays for 15 devices.
  • Page 3: Table Of Contents

    INSTRUCTION MANUAL Contents Contents ..............................Safety instructions ............................ Installation ..............................Set up ................................General Use ..............................Renting a new Locker .......................... Returning to a Locker .......................... Unusual Circumstances ..........................Locker Breach ............................Locker Stuck ............................Too many PIN attempts ........................Administration ............................
  • Page 4: Safety Instructions

    Choosing public, well trafficked areas will contribute to the safety of users and reduce the likelihood of successful break-in. d) The main power lead for the FUYL Tower should be connected in a location that is concealed, to avoid accidental or deliberate power down of the unit while devices are charging.
  • Page 5: Setup

    INSTRUCTION MANUAL SETUP Before the cabinet is powered on for the first time, use the cabinet keys to open the master control door. If the battery is already installed in the board on the top of the controller then remove the insulating tag to enable the battery connection.
  • Page 6: Returning To A Locker

    UNUSUAL CIRCUMSTANCES Locker Breach If the FUYL Tower detects that a locker door was opened without the PIN code being entered (i.e. with a forced entry) an alarm flag will be raised. This message will flash indicating a locker breach The FUYL Tower will still be operational so that other users can retrieve their items.
  • Page 7: Administration

    MANUAL DOOR OVERRIDE Admin Keypad Override Mode - Authenticating To enter the mode, the administrator will need the control access key provided with the FUYL Tower. Turn the key to the right and hold for a moment. Once the key has been activated, the administrator will be prompted for their 8 digit authentication code.
  • Page 8: Management Portal

    These options are only relevant when performing remote administration. Please refer to the software manual for the FUYL Tower management portal. MANUAL DOOR OVERRIDE This can be performed if power is not available to the unit and doors need to be opened.
  • Page 9 PIN as before. MANAGEMENT PORTAL The FUYL Tower can be administrated over a wired local network, or by directly connecting to the FUYL Tower using an Ethernet cable. This is performed using a browser (Firefox, Explorer, Chrome, Safari).
  • Page 10: Troubleshooting

    A user has forgotten their PIN code. See the section: ADMINISTRATION for instructions on entering the admin keypad override mode to open the appropriate door. The FUYL Tower is not operational but a user needs Refer to the section: MANUAL DOOR OVERRIDE. to retrieve their items.
  • Page 11: Warranty

    In the event that a defect, malfunction or failure occurs or is discovered during the warranty period, PC Locs / LocknCharge will repair or replace, at its option, the products which in the reasonable judgment of PC Locs / LocknCharge are deemed defective.
  • Page 12: Compliance And Approvals

    COMPLIANCE and APPROVALS AUSTRALIA/NEW ZEALAND: AS/NZS 55022 RCM: N26682 EUROPE: EN 55022 Conforms to USA/CANADA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference 2.
