ISON IS-RG528 Series Web Configuration Tool Manual

28-port industrial ethernet managed switch
Hide thumbs
Table of Contents

Advertisement

Quick Links

IS-RG528 Series
28-Port Industrial Ethernet Managed Switch
Web Configuration Tool Guide
Version Number: v1.0
Issue: 1.1r1, June 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IS-RG528 Series and is the answer not in the manual?

Questions and answers

Related Manuals for ISON IS-RG528 Series

Summary of Contents for ISON IS-RG528 Series

  • Page 1 IS-RG528 Series 28-Port Industrial Ethernet Managed Switch Web Configuration Tool Guide Version Number: v1.0 Issue: 1.1r1, June 2015...

  • Page 2: Table Of Contents

    [CONTENTS] 1. Introductions ............................ 4 1.1 System Description ........................4 1.2 Using the Web Interface ......................4 1.2.1 Web Browser Support ....................4 1.2.2 Navigation ........................5 1.2.3 Title Bar Icons....................... 5 1.2.4 Ending a Session ......................6 1.3 Using the Online Help....................... 6 2.
  • Page 3 2.4.3 Fdb ..........................85 2.4.4 Giga Port Statistics...................... 86 2.4.5 RMON ......................... 89 2.4.6 Users ........................... 91 2.4.7 I.A. Ring & Chain Status ....................92 2.4.8 802.1x ......................... 93 2.4.9 IGMP ........................... 98 2.5 System ..........................100 2.5.1 Restart ........................100 2.5.2 Save &...

  • Page 4: Introductions

    Ethernet OAM, IEEE 1588v2 / Sync-E and QoS, customers can ensure their network is qualified to deliver any real-time and high quality applications. 1.2 Using the Web Interface “IS-RG528 Series Web Configuration Tool Guide” The object of this document is to address the web feature, design layout and descript how to use the web interface.

  • Page 5: Navigation

    Google Chrome with the following default settings is recommended: Web page font Times New Roman Encoding Unicode (UTF-8) Text size Medium 1.2.2 Navigation All main screens of the web interface can be reached by clicking on hyperlinks in the four menu boxes on the left side of the screen: ...

  • Page 6: Ending A Session

    Save Button If any unsaved change has been made to the configuration (by you during this or a prior session, or by any other administrator using the web interface or the Command Line Interface), a Save icon appears in the title line. To save the running configuration to the startup configuration: Click on the Save icon.

  • Page 7: Using The Web

    2. Using the Web 2.1 Login Fill Username and Password Operation Click “Sign in” Field Description Login user name. The maximum length is 32. Username Default: admin Login user password. The maximum length is 32. Password Default: admin...

  • Page 8: Tree View

    2.2 Tree View The tree view is a menu of the web. It offers user quickly to get the page for expected data or configuration. 2.2.1 Configuration Menu 2.2.2 Monitor Menu...

  • Page 9: Maintenance Menu

    2.2.3 Maintenance Menu...

  • Page 10: Configuration

    2.3 Configuration 2.3.1 Link Aggregation Operation Modify: Select port with check box from GE-1 ~ GE-xx (xx = 10~28). Click Modify button. Field Description Trunk Group Trunk Group number.

  • Page 11: Authentication

    Note: Trunk Group 1 & 2 CANNOT take the member port that is already assigned to another Trunk Group; Max 4 member ports in a Trunk Group. Otherwise, the modification would be failed. Member Port Display current member port of Trunk Group. Mode To enable/disable Link Aggregation for Trunk Group.
  • Page 12 Auth Port The UDP port of RADIUS server for authentication. Range 1~65535. Default is 1812. Secret Key The key to be used between RADIUS server and Authenticator. Range 0~16 chars. Default is empty string. 2.3.2.2 PAE Port Authentication Operation Modify System Auth. Control: 1.
  • Page 13 Field Description System AuthControl Enable/Disable system 802.1x authentication function. Default value is Disabled. Port PAE port: 1 ~ MAX Number of Port. Auth Control The authentication type of PAE port. Allow Force_Unauthorized/Force_Authorized/Auto. Default is Force_Authorized. ReAuth Enabled Enable/Disable re-authenticate of PAE port. Default is Disable.

  • Page 14: Interface Vlan

    2.3.3 Interface VLAN Operation Create: Fill VID, IP Address and Netmask Click "Create New" button to create Interface VLAN. Delete: Multi-select a row data in Interface VLAN table. Click "Delete" button to delete Interface VLAN. Field Description The identity for the RIP Interface. Range 1~4094.

  • Page 15: Static Route

    2.3.4 Static Route Operation Modify: Click "Modify" button to apply new gateway. Create: Fill Destination, Netmask and Gateway. Click "Create New" button to create one static route. Delete: Select static route entry(s). Click "Delete" button to delete selection. Field Description Default Gateway Input default gateway IP address for management and Layer3 VLAN interface routing Destination...

  • Page 16: Port Configuration

    2.3.5 Port Configuration 2.3.5.1 Bridge Port Operation Modify: Enter or select row by checking up check box. Modify the configuration Press “Modify” button to apply modification. Refresh: Click “Refresh” button to get current data. Field Description Port Bridge port number...
  • Page 17 PVID Value: 1~4094. Default value is 1. Default Default Priority value: 0~7. Priority Default is 0. Accept Frame Type Type: All/ OnlyVlanTagged/ Only Untagged. Default is All. Max MAC Limit Range: Enabled/ Disabled. Default is Disabled. Max MAC Range: 0~32. Default is 8.
  • Page 18 Operation Modify: 1. Select a row item to selected 2. Set or select the following fields. 3. Click "Modify" button to modify. Field Description Port GE-1~ MAX Number of Port. Admin Status Enabled/Disabled, default=Enabled. Configuration for Link Mode: Auto (default is Auto) 10Mbps Half/Full Duplex Link Mode 100Mbps Half/Full Duplex...
  • Page 19 2.3.5.3 Port Isolation Port Isolation-Modify...
  • Page 21 Operation Modify: Click “Modify” button to open modification page. Port Isolation - Modify: 1. Click “Disable All”, ”Enable All” or click on (Y/N/-) to change isolation setting by port. 2. Click “Apply” to apply change or Press “Cancel” to cancel and go back to main page of Isolation.
  • Page 22 2.3.5.4. Jumbo Frame Operation Modify: Modify the configuration. Click “Modify” button to apply change. Field Description Jumbo Frame Option: Enabled/ Disabled, Default is Disabled. Size Range: 1536~9000 bytes, Default is 1536 bytes. 2.3.5.5 Port Mirror...
  • Page 23 Operation Modify: Modify the configuration Click “Modify” button to apply change Field Description Port Mirror Enable/Disable Port Mirror function, default is Disabled. Monitored Port Value range is GE-1 ~ Port MAX Number, default is GE-1. Port to be monitored. Tx Analyzer Port Value range is GE-1 ~ Port MAX Number, default is GE-1.
  • Page 24 2.3.5.6 I.A. Ring & Chain Operation Modify: Modify the configuration Press “Modify” button to apply change. Field Description The group index. This parameter is used for easy identifying the ring when user Group configure it. Group 1 - this group supports configuration of ring. Group 2 - this group supports configuration of ring, coupling and dual-homing.
  • Page 25 Enable Ring on the specific group. Mode # When Group 1 or 2 is enabled: All configuration of Group 3 will be reset to default. Group 3 all configuration options will be locked. # To configure Group 3: Both Group1 and 2 should be disabled first. When Group 3 is enabled, all configuration of Group1 and 2 will be reset to default.
  • Page 26 Ring Port(s) Selecting ring port(s). Each ring port must be unique, CANNOT be configured in different groups; 2 ring ports between ring/chain CANNOT be the same. # When role is ring/master: One ring port is forward port and another is block port. The block port is redundant port;...

  • Page 27: Vlan

    2.3.6 VLAN 2.3.6.1 Static VLAN Create New VLAN...
  • Page 28 Modify VLAN Operation Create New: Click “Create New” button to open “Create New” page. Set VID and Name. Click fields to change status. Click “Apply” button to create, or click “Cancel” button to cancel. Modify: Click “Modify” button to open “Modify” page. Modify Name.
  • Page 29 Field Description Value: 1~4094. Default value is 1. Name Range:0~32 characters Range: T/ U/ －. Tagged T: Tagged U: Untagged －: None (not join this VLAN) Set All Ports to None Set all ports to None (no port join this VLAN) Set All Ports to Tagged Set all ports join the VLAN as Tagged.
  • Page 30 Operation Create New: 1. Click "Create New" button to Create New page. 2. Set Port and Ether Type, input SVLAN and S-Prio. 3. Click Create New button. (Max entry: 10.) Delete: 1. Select Index with check box. Click "Delete" button to delete data. Field Description Index...
  • Page 31 2.3.6.3 VLAN Translation Operation Create: 1. Select Port, fill CVLAN, C-Prio, SVLAN and S-Prio. 2. Click "Create New" button to create new entry. Click Delete button to delete selected entry(s). Field Description Index Index 1~10, max entry number: VLAN translation port number: Port GE-1 ~ MAX Number of Port.
  • Page 32 2.3.6.4 VLAN Stacking Operation Modify: 1. Select Port check box : 2. Select Select mode Disabled/ Enabled, click "Modify" button to apply change. Field Description The range is from 1~FFFF ( 0x1 to 0xffff ) Ext-TPID (Hex) Default is 0x8100 VLAN Stacking Port Port: GE-1 ~ MAX Number of Port.

  • Page 33: Mac Learning & Forwarding

    2.3.7 MAC Learning & Forwarding 2.3.7.1 Fdb Static Operation Create New: Setting Port, VID and MAC Address Click “Create New” to create a new data Delete: Select a delete type “All/Port/VID/Selected” If delete type is “Port”, then select a port from list. If delete type is “VID”, then input a VID.

  • Page 34: Spanning Tree Protocol (Stp)

    2.3.7.2 Aging Time Operation Modify: Modify the configuration Click “Modify” button to apply the change Field Description Aging Time(Sec) Range: 10~1000000, Default is 300 seconds. 2.3.8 Spanning Tree Protocol (STP) 2.3.8.1 STP Bridge Status:...
  • Page 36 Config: Operation Modify: Select “Config” page. Modify the configuration. Clicks “Modify” button to apply change. Refresh: Click “Refresh” button to get current data. Field Description Specify whether or not the system is to implement the spanning tree protocol. Range: Enabled/Disabled, default=Disabled. Protocol RSTP (IEEE 802.1W), STP (IEEE 802.1D) Option: STP/RSTP, Default=STP.
  • Page 37 Priority Sets the spanning tree protocol priority. The lower the priority number, the more significant the bridge becomes in protocol terms. Where two bridges have the same priority, their MAC address is compared and the smaller MAC address is treated as the most significant.
  • Page 38 2.3.8.2 STP Port Major:...
  • Page 39 Minor: Operation Modify: Select “Major” page Select row(s) to be changed by checking up checkbox Modify the configuration Click “Modify” button to apply change. Refresh: Click “Refresh” button to get current data. Field Description Port Range: GE-1 ~ MAX Number of Port Priority Range: 0~240 in step 16, Default is default=0x80(128).
  • Page 40 Edge Range: Enabled/Disabled, default=Disabled. Range: Disabled/ Blocking/ Listening/ Learning/ Forwarding/ Broken State Disabled : For ports which are disabled (see dot1dStpPortEnable), this object will have a value of disabled. Blocking: The port will go into a blocking state at the time of selection process, when a switch receives a BPDU on a port that indicates a better path to the root switch, and if a port is not a root port or a designated port.
  • Page 41 Designated Bridge The parameter is the Bridge Identifier of the bridge which this port considers to be the Designated Bridge for this port's segment. Format: Designated bridge priority + Designated Bridge MAC address. [0x8000-001122334455] Designated Port The parameter (dot1dStpPortDesignatedPort) is the Port Identifier of the port of the Designated Bridge for this port's segment.
  • Page 42 2.3.8.3 MSTP Bridge Operation Create New: Fill "MSTI Name" and select "Priority" fields. (Default MSTI Name will be set when name is not input.) Click "Create New" button to create new data. Max MSTI number is 10. Delete: Select "MSTI Name". Click "Delete"...
  • Page 43 VLAN ID, Format: 2-5,7,100-4094. Accept number, space, dash and comma. Priority MSTI's priority. The lower the priority number, the more significant the bridge becomes in protocol terms. Where two bridges have the same priority, their MAC address is compared and the smaller MAC address is treated as the most significant.
  • Page 44 2.3.8.4 MSTP Port Operation Modify: Select a row item to selected Set or select the following fields. Click "Modify" button. Field Description Port Range: GE-1 ~ MAX Number of Port Priority Range: 0~240 in step 16, Default is default=0x80(128). Path Cost Range: 1 ~ 200000000, Default is 20000.
  • Page 45 begins to process user frames and start updating the MAC address table. But the user frames are not forwarded to the destination. After a forward time delay (The default forward delay time is 15 seconds), the switch port moves from the learning state to the forwarding state.

  • Page 46: Policer

    2.3.9 Policer 2.3.9.1 Policer Ingress Color Operation Modify: Select “Color Blind” or “Color Aware” Modify the configuration Click “Modify” button to apply change Field Description Color Aware Mode Color Blind/ Color Aware. Default is Color Blind. CoS 0 Green/Yellow/Red, default is green CoS 1 Green/Yellow/Red, default is green CoS 2...
  • Page 47 CoS 6 Green/Yellow/Red, default is green CoS 7 Green/Yellow/Red, default is green...
  • Page 48 2.3.9.2 Policer Color Marking Operation Modify: Modify the configuration Click “Modify” button to apply change Field Description Color Aware Mode Color Blind/ Color Aware. Default is Color Blind. CoS Green Range: 0~7, Default is 7 CoS Yellow Range: 0~7, Default is 5 CoS Red Range: 0~7, Default is 3 DSCP Green...
  • Page 49 2.3.9.3 Ingress Policer Operation Modify: Modify the configuration Click “Modify” button to apply change Field Description Port Bridge port number. GE-1 ~ MAX Number of Port. Mode Ingress Policer Mode Enabled/Disabled, default is Disabled. Exceed Action Value range is Drop/CoS Mark/DSCP Mark, default is Drop. PIR (Kbps) Value range is 1~1000000 Kbps, default is 1000000 Kbps.

  • Page 50: Acl

    2.3.10 ACL 2.3.10.1 Profile Operation Create New: Fill ACL Profile Name, the max length is 31. Click “Create New” button to Create New ACL profile. Modify: 1. Select checkbox of profile to be changed. 2. Modify the “Name” of profile 3.
  • Page 51 2.3.10.2 Entry Create New...
  • Page 52 Operation Create New: Click “Create New” button to open page of Create New entry. Fill ACL Entry Index field and select Type. Fill fields and then click “Apply” to create or click “Cancel” to cancel. Modify: Modify field data. Click “Modify” button to open modification page. Fill Entry Index field and select Type.
  • Page 53 Destination IP Mask Format XXX:XXX:XXX:XXX, each field value range 0~255. Protocol Value range 0~255. Action Value range Deny/Permit/Queue Mapping/CoS Marking/Copy Frame. Type = L4PORT Protocol Value range TCP/UDP. Source IP Format XXX:XXX:XXX:XXX, each field value range 0~255. Source IP Mask Format XXX:XXX:XXX:XXX, each field value range 0~255.
  • Page 54 2.3.10.3 Binding Operation Modify: Modify the configuration. Click “Modify” button to apply change. Field Description Port Giga Port, GE-1 ~ MAX Number of Port. Profile Index ACL Profile Index, range is 1 ~ MAX SIZE of profile, default is 1. Default ACL Rule ACL Default Rule, could be Permit/Deny, default is Permit.
  • Page 55 2.3.10.4 Mirror Analyzer Port Operation Modify: Modify the configuration. Click “Modify” button to apply change. Field Description Analyzer Mode Enabled/Disabled, default is Disabled. Analyzer Port Giga Port GE-1 ~ MAX Number of Port, default is GE-1.

  • Page 56: Shaper

    2.3.11 Shaper 2.3.11.1 Port Shaper Operation Modify: Modify the configuration. Click “Modify” button to apply change. Field Description Port Bridge port, range is 1 ~ MAX Number of Port. Mode Enabled/Disabled, default is Disabled. Rate (Kbps) Rate range is 1~1000000 Kbps, default is 1000000 Kbps.
  • Page 57 2.3.11.2 Queue Shaper Operation Modify: Modify the configuration. Click “Modify” button to apply change. Field Description Bridge port, range is 1 ~ MAX Number of Port. Mode Option: Enabled/Disabled, default is Disabled. Queue 0~3 (Rate) Queue 0~3, rate range is 1~1000000 Kbps, default is 1000000 Kbps. Queue 4~7 (Rate) Queue 4~7, rate range is 1~1000000 Kbps, default is 1000000 Kbps.

  • Page 58: Queue & Scheduler

    2.3.12 Queue & Scheduler 2.3.12.1 CoS & Queue Mapping Operation Modify: Modify the configuration. Click “Modify” button to apply change. Field Description CoS 0 Queue 0~7, default is Queue 0. CoS 1 Queue 0~7, default is Queue 1. CoS 2 Queue 0~7, default is Queue 2.
  • Page 59 2.3.12.2 Scheduler Profile Operation Modify: Modify the configuration. Click “Modify” button to apply change. Field Description Index Value range is 1~8. Mode Option: SP/SPWRR/WRR, default is SP. Queue 0~3 weight Queue 0~3 Weight, range is 1~255, default is 1. Queue 4~7 weight Queue 4~7 Weight, range is 1~255, default is 1.
  • Page 60 2.3.12.3 Binding Operation Modify: Modify the configuration. Click “Modify” button to apply change. Field Description Port Giga Port GE-1 ~ MAX Number of Port. Profile Index Range is 1~8, default is 1.

  • Page 61: Storm Control

    2.3.13 Storm Control 2.3.13.1 Unknown Unicast Control Operation Modify: Modify the configuration. Click “Modify” button to apply change. Field Description Port Giga Port GE-1 ~ MAX Number of Port. Mode Forward -> Forward unknown unicast packet (default) Block -> Block unknown unicast packet Rate limit ->...
  • Page 62 2.3.13.2 Unknown Multicast Control Operation Modify: Modify the configuration. Click “Modify” button to apply change. Field Description Port Giga Port GE-1 ~ MAX Number of Port. Mode Forward -> Forward unknown unicast packet (default) Block -> Block unknown unicast packet Rate limit ->...
  • Page 63 2.3.13.3 Broadcast Control Operation Modify: Modify the configuration. Click “Modify” button to apply change. Field Description Port Giga Port GE-1 ~ MAX Number of Port. Mode Forward -> Forward broadcast packet (default) Block -> Block broadcast packet Rate limit -> Control rate. Rate range is 1~1000000 Kbps, default is 1000000 Kbps.
  • Page 64 2.3.13.4 Unknown Unicast by VLAN Operation Modify: 1. Fill VLAN ID 2. Change Mode 3. Click “Modify” button to apply change Field Description VLAN ID Value range is 1~4094. Mode Forward -> Forward unicast packet (default). Block -> Block unicast packet. Block VLAN ID All blocked VLAN ID...
  • Page 65 2.3.13.5 Unknown Multicast by VLAN Operation Modify: Fill VLAN ID Change Mode Click “Modify” button to apply change Field Description VLAN ID Value range is 1~4094. Mode Forward -> Forward unknown multicast packet (default). Block -> Block unknown multicast packet. Block VLAN ID All blocked VLAN ID...
  • Page 66 2.3.13.6 Broadcast by VLAN Operation Modify: Fill VLAN ID Change Mode Click “Modify” button to apply change Field Description VLAN ID Value range is 1~4094. Mode Forward -> Forward broadcast packet (default). Block -> Block broadcast packet. Block VLAN ID All blocked VLAN ID...

  • Page 67: Igmp

    2.3.14 IGMP 2.3.14.1 ACL Profile Operation Create New: 1. Click "Create New" button to create a default profile. 2. Click "Modify" button to modify existing profile. Modify (allow multiple selection): 1. Check up Profile Index and select Default Rule for profile. 2.
  • Page 68 2.3.14.2 ACL Entry Operation Create: 1. Click "Create New" button to open new page for create. 2. Fill Entry Index, SVLAN, Start IP, End IP and select Permission Rule. 3. Click "Apply" button to create IGMP ACL entry or click "Cancel" to cancel create. Delete: Check up target entry, click Delete button to delete them.
  • Page 69 2.3.14.3 ACL Binding Operation Modify: 1. Check up the rows to be modified, select ACL Profile and set Max channel. 2. Click "Modify" button to change IGMP ACL Binding. Field Description Port GE Port: 1 ~ MAX Number of Port. IGMP ACL profile index: 1~15.
  • Page 70 2.3.14.4 MVR Profile Operation Create: 1. Click "Create New" button to create a new profile. Modify: Check up Profile Index. 2. Click the Profile Index hyper link to open page for profile entry modification. [ or click "Delete" delete Profile, allow multiple delete. If profile is in use, delete action will be failed.] Field Description...
  • Page 71 2.3.14.5 MVR Entry Operation Create New: 1. Click "Create New" button to open new page for create. 2. Fill Entry Index, SVLAN, Start IP, End IP. 3. Click "Apply" button to create IGMP MVR entry or click "Cancel" to cancel create. Delete: Check up target entry, click Delete button to delete them.
  • Page 72 2.3.14.6 MVR Binding Operation Modify: 1. Check up the rows to be modified, select MVR Profile. 2. Click "Modify" button to change IGMP MVR Binding. Field Description Port GE Port: 1 ~ MAX Number of Port Profile Index IGMP MVR profile index. Value range is 1~15.
  • Page 73 2.3.14.7 VLAN Interface Create...
  • Page 74 Modify Operation Refresh: Refresh to get current data. Create: Into Create web page. Setting data Click “Apply” to setting data or click “Cancel” to cancel setting data. Delete: Delete current selected row data. Modify: Into Modify web page. Setting data Click “Apply”...
  • Page 75 Entry Index, max 64. VLAN ID (1~4094) Version IGMP Version: IGMPv2 or IGMPv3. Run Version Current running IGMP version. Mode IGMP Access Mode: Normal Snooping (default) or Proxy. Leave Mode IGMP Leave Mode: Normal Leave (default) or Fast Leave. Robustness IGMP VLAN robustness variable.
  • Page 76 Router Port IGMP VLAN interface: Bridge port:GE-1 ~ Port MAX Number. Default value is 1 V2 Present Time(sec) Read-only, it can be tuned by (last RunQueryInterval *10*robustness + maxRespTime) Querier Source IP Querier Source IP Address. Default: 0.0.0.0 Address 2.3.14.8 Static Group Membership...

  • Page 77: Front Panel

    Operation Create New: Fill IP Address, VID and select Membership. Click “Create New” button to create new data. Delete: Select Delete Type "All/ Membership/ VID/ Selected" If delete type is “Port”, then select a port If delete type is "VID", then fill a VID If delete type is "Selected", then select one row Click “Delete”...
  • Page 78 Object Description The group index. This parameter is used for easy identifying the ring when user configure it. Index Group 1 (Index 1) - It supports configuration of ring. Group 2 (Index 2) - It supports configuration of ring, coupling and dual-homing. Group 3 (Index 3) - It supports configuration of chain and balancing-chain.
  • Page 79 configuration options will be locked. To configure Group 3, both Group1 and 2 should be disabled first. When Group 3 is enabled, all configuration of Group1 and 2 will be reset to default. Group 1 and 2 all configuration options will be locked. Role Configure the Ring group on this switch as specific role.
  • Page 80 # When role is chain/head, one ring port is member portand another is head port. Both ring ports are forwarding port in normal state. # When role is chain/tail, one ring port is member port and another is tail port. The tail port is redundant port;...
  • Page 81 Ring Coupling Configuration Dual Homing Configuration...
  • Page 82 I.A.Chain (Daisy Chain) I.A.Chain (Balancing Chain) NLB...

  • Page 83: Alarm/Event

    2.4.1 Front Panel This page still can’t display the real status of system’s panel. 2.4.2 Alarm/Event Alarm Current Alarm History...
  • Page 84 Event Log Operation Refresh: 1. Click "Refresh" button to refresh data.

  • Page 85: Fdb

    Clear: 1. Click "Clear" to clear data. Field Description SeqNo Alarm/Event Sequential Number. Alarm/Event Type ID. Description Alarm/Event Type Description. Position/Name Event Position/Name. Level No matter alarm is major/minor, Alarm LED color always be red. State Alarm State. Value is Set/Cleared. Time Time.

  • Page 86: Giga Port Statistics

    Fill delete condition Click “Delete” to delete data. Field Description Port GE-1 ~ MAX Number of Port or Trunk Group. VLAN ID: 1~4094 MAC Address Format xx:xx:xx:xx:xx:xx Status Data type: Dynamic/ Static 2.4.4 Giga Port Statistics Operation Refresh: Fill query condition (Port) Refresh current data.
  • Page 87 Input Unicast Pkts The number of packets, delivered by this sub-layer to a higher (sub-) layer, which were not addressed to a multicast or broadcast address at this sub-layer. Input Multicast Pkts The number of packets, delivered by this sub-layer to a higher (sub-) layer, which were addressed to a multicast address at this sub-layer.

  • Page 89: Rmon

    2.4.5 RMON Operation Refresh: Click “Refresh” button to refresh current data. Clear: 1. Select clear port. 2. Click “Clear” to clear setting physical port data. Field Description Pkts 64 Octets Total number of packets (including bad packets) received that were 64 octets in length. Pkts 65 to 127 Octets Total number of packets (including bad packets) received that were between 65 and 127 octets in length.
  • Page 90 Pkts 512 to 1023 Octets Total number of packets (including bad packets) received that were between 512 and 1023 octets in length. Pkts 1024 to 1518 Octets Total number of packets (including bad packets) received that were between 1024 and 1518 octets in length.

  • Page 91: Users

    2.4.6 Users Operation Refresh: Click “Refresh” button to refresh current data. Field Description Index Show the index of login user list. Interface Type Show the mode of access. Possible values Console, CLI, Web. Account Name Show the account name of the user. Information Show more information about the user, including IP address of the management host.

  • Page 92: Ring & Chain Status

    2.4.7 I.A. Ring & Chain Status Operation Refresh: Click “Refresh” button to refresh current data. Field Description Group Index The group Index. This parameter is used for easy to identify the ring when use to configure Mode It indicates whether the ring is enabled. Role It indicates that the ring is configured to what role.
  • Page 93 2.4.8 802.1x 2.4.8.1 PAE Port Status Operation Refresh: Click “Refresh” button to refresh current data. Field Description Port The index of PAE Port: Value Range 1 ~ MAX Number of Port. PAE State The authenticator status of PAE port: Possible state: Initialize Disconnected...
  • Page 94 Authenticating Authenticated Aborting Held Force Auth Force Unauth Backend State The number of RADIUS Access-Accept received from RADIUS server. Range: 0~65535. Rejects The backend authenticator status of PAE port. Possible state: Initialize Idle Request Response Success Fail Timeout Ignore Port Status The authentication status of PAE port.
  • Page 95 2.4.8.2 RADIUS Statistics Operation Refresh: Click “Refresh” button to refresh current data. Clear: Click "Clear" button to reset the counters. Field Description Index The index of RADIUS Server: Current only support 1 RADIUS server Requests The number of RADIUS Access-Request sent to RADIUS server Range 0~65535.
  • Page 96 2.4.8.3 EAPOL Statistics Operation Clear: 1. Select "Clear Type". 2. If clear type is "Port", then select port number to be cleared. 3. Click "Clear" button. Field Description Port The index of PAE port: Value range 1 ~ MAX Number of port. Protocol Version The protocol version number carried in the most recently received EAPOL frame.
  • Page 97 Req Frame Tx The number of EAP Request frames (other than Req/Id frames) that have been transmitted. Range 0~65535. The number of valid EAPOL frames of any type that has been received. Frame Rx Range 0~65535. The number of EAPOL Start frames that have been received. Start Frame Rx Range 0~65535.

  • Page 98: Igmp

    2.4.9 IGMP 2.4.9.1 Group Membership Query: Operation Select Query Type Fill query condition Modify query record range (Index range) Click “Query” button to query data. Delete: Select Delete Type Fill VLAN ID when delete type is “By VID” Select one membership when delete type is “By Membership” Click “Delete”...
  • Page 99 2.4.9.1 Group Membership Source Fdb Operation Query: Select Query Type Fill query condition (Index 1~64) Click “Query” button to query data. Field Description Index Multicast Source FDB table. Max entry size: 64 Group IP Multicast Source FDB group IP address. Multicast Source FDB VLAN ID, range 1~4094 Multicast Source FDB Filter Mode: Include/Exclude Filter Mode...

  • Page 100: System

    2.5 System 2.5.1 Restart Operation Restart: Click “Restart” button will restart the system Save Running Config & Restart: Click “ Save Running Config & Restart” button will redirect page to “Save & Restore”...

  • Page 101: Save & Restore

    2.5.2 Save & Restore Submit: Operation Select Control Action. Fill necessary data for action. Click “Submit” button to start the instruction. Field Description Database Control action Select Database control. (A)Save Inband configuration and runtime configuration as the active restoration database for next power-on restoration. (B)Restore Inband configuration and control plane configuration by setting another restoration database active.
  • Page 102 Inband configuration. is lost) (F)Clear control plane configuration in the active restoration database. (runtime configuration. is also changed.) (G)Clear control plane configuration in the active restoration database and restart. (runtime configuration is also changed.) (H)Export runtime configuration in CLI command format to ftp server. (I)Export runtime configuration in binary format to ftp server.

  • Page 103: Firmware

    2.5.3 Firmware FTP Get and Write Flash: Operation Select Schedule time checkbox to setting schedule Fill schedule time Click “FTP Get and Write Flash” button will load firmware from remote server IP, If the “Reboot After Remote Download” was selected it will restart system when the firmware was changed.

  • Page 104: Alarm Profile

    Server User Name Type in a user name accepted by the FTP server. Server Password Type in a password accepted by the FTP server. File Name Type in the name of the firmware file (string length 1 ~ 64). Schedule Time Select Enable checkbox and type in the schedule time to update of the firmware file.

  • Page 105: Cli Options

    Operation Modify: Select Row data checkbox. Modify Level and Mask. Note: When any alarm exists, the Alarm LED will be lit, and Alarm Output Relay will also be enabled. Click "Modify" button to modify data. Field Description Alarm Type ID. Description Alarm Type Description.

  • Page 106: Http (Https)

    2.5.6 HTTP (HTTPS) Operation Modify: Select HTTP or HTTPS. Change the port number if necessary. Click “Modify” button to apply the change. Field Description HTTPS Service HTTPS / HTTP. Default is HTTP (HTTPS disabled). HTTPS Port HTTPS service port. Range: 1~65535, Default Port: 443. HTTP Port HTTP service port.

  • Page 107: Sll

    2.5.7 SLL Operation Use Default Certificate: Click "Use Default Certificate" button. System will delete uploaded certificate, if it's exist. After delete success, it will show default SSL certificate. Upload New: Click "Upload New" button. Copy and Paste both Private Key (privatekey) and Self-Signed SSL Certificate (cert) in the input area.

  • Page 108: Sntp

    -----END RSA PRIVATE KEY----- -----BEGIN CERTIFICATE----- ..-----END CERTIFICATE----- 2.5.8 SNTP Operation Modify: Modify the configuration. Click “Modify” button to modify data. Sync: Click “Sync” button to manual synchronize system time from SNTP server. Field Description Select Time zone Sets the local time zone with Time Zone list. Sixty-six of the world's time zones are presented (including those using standard time and summer/daylight savings time).

  • Page 109: Syslog

    2.5.9 Syslog Operation Modify: Select Enabled/Disabled option and click Modify button to enable Syslog function. Modify the configuration. Click “Modify” button to modify data. Field Description Status Value is Enabled/Disabled, default is Disables. It will control the system log work or not. Current Server Current Syslog server IP address.

  • Page 110: User Administration

    2.5.10 User Administration...
  • Page 111 Operation Create: Click “Create” button to create page. Fill user name, access level, password, confirm password and comment fields. Click “Apply” to create setting data or click “Cancel” to cancel it. Delete: Select one row data for delete. Click “Delete” to delete selected data. Modify: Click “Modify”...

  • Page 112: Snmp

    2.5.11 SNMP 2.5.11.1 SNMP Options Operation Restart: After any SNMP setting changed, only configuration is changed, but not apply to the system yet. All SNMP changed configuration could work after restart SNMP. It will not reboot system, but may take several seconds to load SNMP setting. Modify SNMP Version: This button is used to set whether snmp v3 is enable or not.
  • Page 113 2.5.11.2 SNMP Community Operation Create: Fill the Community name. Click "Create New" button to create new Community. Modify community entry: Select entry by check up the check box Modify field data: Click "Modify" button to apply the change Delete community entry: Select entry by check box, then click "Delete".
  • Page 114 View and Group are used for SNMP v3 only. A community is allowed to bind one of the view or group name. If it does not take any group or view, it will be a v1/v2c community. If it takes a view or a group name, the View/Group Name community will be treated as a v3 community.
  • Page 115 1. Select entry by check box 2. Click "Delete" button to delete Notify Tag item. Field Description Index SNMP notify tag index, The system supports up to 32 notify tags. Notify Name Name of Notify entry. Notify Name max size is 31 characters. Notify Tag string.
  • Page 116 SNMP Target: Operation Create: 1. Click "Create New" button to create new target data 2. Fill the target IP address, name, port number, and trap version. Give a new tag name or select a existing notify tag name as target name 3.
  • Page 117 2.5.11.4 User Operation Create new: 1. Fill "User Name" and select "User Type", "Auth Protocol" and "Priv Protocol". 2. Click "Create New" button to create new user. Delete: 1. Select a row data in user account table (also support multi-select). 2.
  • Page 118 User authentication protocol. Works only if SNMPv3 is enabled. Options: 1. None Auth Protocol 2. MD5 3. SHA If "Auth Protocol" is "None", "Priv Protocol" always is "None". If "Auth Protocol" is MD5 or SHA, "Auth Password" should be input. Authentication password, length 8~15.
  • Page 119 2.5.11.5 Group Operation Create new: 1. Fill "Group Name" and select "Sec. Model", "Sec. Level". 2. Click "Create New" button to create new group. Note: max group entry: 32 Delete : 1. Select a row data in VACM group table (also support multi-select). 2.
  • Page 120 User security level. If "Security Model" is "v1" or "v2c", the field is not used, it will be show as "--". States as below: Security Level - NoAuth, NoPriv (No authentication and no Privacy) - Auth, NoPriv (Authentication and no Privacy) - Auth, Priv (Authentication and Privacy) Access View for Read (snmp-get) Select from the view list.
  • Page 121 2.5.11.6 SNMP View Operation Create new: 1. Fill "View Name", "Sub Tree" and select "View Type". 2. Click "Create New" button to create new view. Note: max group entry: 32 Delete: 1. Select a row data in VACM view table (also support multi-select). 2.
  • Page 122 View Type Accessible/Not accessible of object (SNMP OID). Select down list box: 1. Include, allow access the subtree/oid; 2. Exclude, doesn't allow access the subtree/oid. Note: the oid is a prefix, no need to match it exactly. For example: 1.3.6.1.2.1 (include), it means 1.3.6.1.2.1.* are accessible. For example: 1.3.6.1.2.1 (exclude), it means 1.3.6.1.2.1.* are NOT accessible.
