Mount/Unmount the Unit Base Lifter

6.6

6.6.1 Mounting the Unit Base Lifter

In oder to mount the unit base lifter, switch off the phone and put it on
its keypad. Insert two pins into openings 1 and 2 located at the top part
of the phone. Then, fold back the lifter to insert pins into openings 3
and 4 until a click is
1
3

6.6.2 Unmounting the Unit Base Lifter

To unmount the unit base lifter, switch off the phone and place it with
its keypad facing downwards. Hold the sides of the phone, use your
thumbs to gently press two pins, and gently lift the lifter. After two first
pins are released, remove the lifter.

Mounting the Phone on the Wall

6.7
The telephone has special hooks for wall mount. The hooks are located
where a unit base lifter should be installed. If you want to wall mount
the phone, do not install the unit base lifter.
1. Pull out the handset hook, and place it back the other way
around so that it will hold the handset in vertical position.
heard.
2
4
CLICK
