ShopBot PRS Assembly Manual Page -1
ShopBot PRS: Assembly Manual
These assembly instructions apply to both PRSalpha and PRSstandard models of ShopBot
CNC's. Note that there are different sections for connecting each type of tool to the control
box. Make sure that you are using the correct connection section for your 'alpha' or
'standard' PRS model.
The boxes are very heavy! Several components are heavy! Make sure you have
help or proper handling equipment when moving or positioning boxes or parts.
PRSAssembly080922.doc
Copyright 2007,2008 ShopBot Tools, Inc

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRSalpha and is the answer not in the manual?

Questions and answers

Related Manuals for ShopBot PRSalpha

Summary of Contents for ShopBot PRSalpha

  • Page 1: Assembly Manual

    ShopBot PRS Assembly Manual Page -1 ShopBot PRS: Assembly Manual These assembly instructions apply to both PRSalpha and PRSstandard models of ShopBot CNC’s. Note that there are different sections for connecting each type of tool to the control box. Make sure that you are using the correct connection section for your ‘alpha’ or ‘standard’...

  • Page 2: Table Of Contents

    Contents Assembly Manual ....................1 Table Surface Considerations..........................3 Electrical Precautions ............................4 Overview of Your ShopBot PRS CNC Tool......................5 Assembling Your ShopBot ..........................7 Tools You Will Need ..........................7 Unpacking and Getting Your Work Area Organized: .................8 Connection to Electrical Service ........................9 Overview of the Assembly Process .......................10...
  • Page 3 Connect Cables from the Proximity Switch and Z-zero Plate.................58 Seal the Cable Entry............................59 Ground the ShopBot PRSalpha ........................59 Connect the USB cable from PRSalpha Control Box to computer..............60 Hooking Up Your PRSstandard ................. 61 Plug the Motor Cables into your PRS Standard Control Box .................61 Connect the Cable from the Remote-Stop Switch ..................61...

  • Page 4: Electrical Precautions

    ShopBot PRS Assembly Manual Page -4 Electrical Precautions MOTOR CONNECTIONS - DO NOT CONNECT OR DISCONECT ANY MOTOR WIRE CONECTORS WHILE YOUR CONTROL BOX IS TURNED ON !! During the process of a ‘hot’ connect or disconnect there is a high load put on the motor driver circuitry which is very likely to damage the motor driver.

  • Page 5: Overview Of Your Shopbot Prs Cnc Tool

    (fewer or more legs, different shape, etc.). Before you unpack and start to assemble your ShopBot PRS tool, let's go over the some of the major components and get familiar with the terminology and directions we'll be using: THE TABLE To get us located, refer to the orientation diagram above and imagine looking at the tool from the position of the little man in the drawing.
  • Page 6 THE X-AXIS. The X-axis is the basis for your tool's right and left moves (as seen by you as the little man in the front of the diagram) -- it's the long axis on a standard ShopBot. Note that the distance between the tracks on the X-axis is wide. Because of this span, we power the X-Car movement with 2 motors, one on each side.

  • Page 7: Assembling Your Shopbot

    ShopBot PRS Assembly Manual Page -7 Assembling Your ShopBot Tools You Will Need • a wrench set with TWO wrenches of the following sizes 7/16”, 1/2”, 9/16”, and 3/4”(the type with box end on one side and open end on the other works well).

  • Page 8: Unpacking And Getting Your Work Area Organized

    You will receive a large shipping crate with the already-assembled X-Car and YZ- Car. One of the large cartons inside the crate holds the ShopBot Control Box. The motors and motor cables are packaged together. The long package with the rails and table sides will usually be strapped to the top of the shipping crate.

  • Page 9: Connection To Electrical Service

    By way of giving you a little guidance: It takes one of us about 6 hours to assemble a ShopBot, so we think you should be able to put your ShopBot together over a pleasant weekend if you've already read through this Assembly Manual. Of course, the IRS thinks...

  • Page 10: Overview Of The Assembly Process

    Note there are different sections for the PRSstandard and the PRSalpha. Off and Running… Stopping the ShopBot How to stop the ShopBot with the E-Stop, 3-Button Pendant, Remote Stop Switch and the “S” key. Taking a Test Drive Ok, let’s go for a little spin, then we’ll review a couple of other things you will need to attend to before you get into production.

  • Page 11: Assembling The Table

    Measured Drawing (located at the back of this section) specific for the size ShopBot you are assembling. The Measured Drawing plans show the dimensions of the tools, the spacing of the cross supports, and the correct position for the table surface.

  • Page 12: Table Parts

    ShopBot PRS Assembly Manual Page -12 Table Parts Upper Support (note beveled ends in upper support) Lower Support Cross Support PRSAssembly080922.doc Copyright 2007,2008 ShopBot Tools, Inc...
  • Page 13 ShopBot PRS Assembly Manual Page -13 Table Gusset Table Leg 1/2Bolt 1/2Flat washer 1/2Hex nut 1/2Lock Washer 5/16 Bolt 5/16 Flat washer Tee nut Machine Glide (w 5/8 nut and lockwasher) (in several sizes) PRSAssembly080922.doc Copyright 2007,2008 ShopBot Tools, Inc...

  • Page 14: Assembly Steps

    ShopBot PRS Assembly Manual Page -14 Assembly Steps Step1.1: Attach a Machine Glide to the Bottom of Each of the Table Legs Screw a Machine Glide through the 5/8” nut in the bottom of each Table Leg. Place a 5/8”...
  • Page 15 ShopBot PRS Assembly Manual Page -15 hold the pieces securely in place. Keep in mind that you will want to tighten all nuts securely at the end of the table assembly when you square the table. If you tighten all fasteners too much now, you won’t be able to square the table later.

  • Page 16: Step 1.3: Attach The First Upper Table Support

    ShopBot PRS Assembly Manual Page -16 Step 1.3: Attach the First Upper Table Support Attach the first Upper Table Support to the end of the table. Start it on from the side with the temporary outside leg. Slide the T-nuts for the Upper Table Support into the bottom channel of each Table Side on the far end.
  • Page 17 ShopBot PRS Assembly Manual Page -17 Attach the Lower Table Support to the bottom holes in the Table Legs using ½” Hardware Assemblies. Lower Table Support showing attachment to Table Leg. Your table should now look like this: PRSAssembly080922.doc Copyright 2007,2008 ShopBot Tools, Inc...

  • Page 18: Step 1.4: Slide The Cross Supports Into Position

    ShopBot PRS Assembly Manual Page -18 Step 1.4: Slide the Cross Supports into Position Attach two 5/16” Hardware Assemblies to each end of the Cross Supports. Then slide the T- nuts into the bottom channels of the Table Sides and slide the Cross Supports into position.

  • Page 19: Step 1.5: Working On The Other End Of The Table Where The Legs Are Still Temporarily Attached To The Outside Of The Table Sides

    ShopBot PRS Assembly Manual Page -19 Step 1.5: Working on the other End of the Table where the Legs are still temporarily attached to the Outside of the Table Sides Install 5/16” Hardware Assemblies on the Upper Table Support and slide it into position.

  • Page 20: Step 1.6 Square And Level Table

    ShopBot PRS Assembly Manual Page -20 Step 1.6 Square and Level Table Set the table where it will be used. Plan to spend a little time getting it square and adjusted to the exact correct width measurement. [SEE DRAWING & TABLE BELOW] Set the legs perpendicular to the Table Sides with a square and tighten.

  • Page 21: Suggested Materials

    ShopBot PRS Assembly Manual Page -21 ========== WORK AREA ========== WIDTH DIMENSION 48” (121.92cm) 60” (12.40cm) 72” (182.88cm) Outside to Outside of Table Sides 64.5” (163.83cm) 76.5”(194.31cm) 88.5”(234.79cm) Gauge between Rail Spacing 61.5”(156.21cm) 73.5”(186.69cm) 85.5”(217.17cm) Table Surface (probably attach later?) The deck surface of your table is created from several sheets of plywood or MDF.
  • Page 22 Supports or center Cross Support and attach with flat washers, lock washers and nuts. If you are putting a vacuum hold-down system on your ShopBot. Please see the documentation for the vacuum hold-down system for more information on installing your plenum and bleeder board.

  • Page 23: Installing The Gantry

    ShopBot PRS Assembly Manual Page -23 Installing the Gantry Installing the X-Rails and Getting One Rail Straight Slide the X-Rails onto the Table • Mount the X-rails with 5/16 bolts and T-nuts. Slide these nuts into the top track of the table sides as you did with the table legs and cross supports.

  • Page 24: Adjust The Position Of The Rear X-Rail

    ShopBot PRS Assembly Manual Page -24 • With bolts “finger tight,” move along the X-Rail on the front side of your tool, aligning the aluminum bar on the inside exactly flush with the inside of the table side. • Then start at one end further tightening the bolts.

  • Page 25: Putting The X-Car On The Rails And Using It To Align The Rear X-Rail

    ShopBot PRS Assembly Manual Page -25 Putting the X-Car on the Rails and Using it to Align the Rear X-Rail Lower the X-Car onto the X-Rails The X-Car is fully assembled and ready to be placed on the rails. This is a 2-4 person operation as the car is HEAVY! Note that the car goes on the rails so that the sloping edge of the X-Car faces towards the left when you are at the front of the tool.

  • Page 26: Use The X-Car As A Guide To Align The Rear X-Rail

    ShopBot PRS Assembly Manual Page -26 Detail • Put a C-Clamp across the rails at each end of the table to create a temporary end stop to prevent the X-Car from rolling off the table while you are carrying out the...

  • Page 27: Mounting The Yz-Car And Adjusting Its Lower Wheel Bearings

    ShopBot PRS Assembly Manual Page -27 Mounting the YZ-Car and adjusting its lower wheel bearings Place YZ-Car on the X-Car The YZ-Car is a single piece that is ready to be placed onto the rails that cross the face of the X-Car beam.

  • Page 28: Attach The Lower Wheel Bearings On The Yz-Car

    ShopBot PRS Assembly Manual Page -28 Attach the Lower Wheel Bearings on the YZ-Car With the YZ-Car in position riding on its upper wheel bearings, you can install the lower bearings. Study the diagram below because the parts in this assembly need to be installed exactly as indicated.

  • Page 29: Adjust The Lower Wheel Bearings On The Yz-Car

    ShopBot PRS Assembly Manual Page -29 Adjust the Lower Wheel Bearings on the YZ-Car The lower bearing is adjusted tight by rotating the eccentric bushing. It has an off-center hole so that rotating the bushing moves the wheel into and out of contact with the rail. The adjustment is done most easily with a 9/16”...

  • Page 30: Attaching The Motors

    ShopBot PRS Assembly Manual Page -30 Attaching the Motors Put the Pinion Gears on the Motors Locate the X and Y motors. These motors will already be fitted to a blue mounting bracket and have a long cable attached. Also find the bag with your pinion gears.

  • Page 31: Mount The Motors

    ShopBot PRS Assembly Manual Page -31 Mount the Motors Since the motor cables (of correct lengths and motor direction orientation) have already been attached to the motors, it is important that the motors and brackets be mounted in the correct location. The mounting hardware for each motor (4 bolts) is already fitted to the tool in the locations where the motors will be mounted.
  • Page 32 ShopBot PRS Assembly Manual Page -32 We recommend applying grease to the rack and pinions. A good quality bearing, lithium, or Teflon grease will work well. The grease will keep the rack motion smooth and reduce gear wear. (Surprisingly little debris actually collects in the grease.) Apply it by squeezing a little into the rack every few inches.

  • Page 33: Set The Mechanical End Stops For The X Axis

    ShopBot PRS Assembly Manual Page -33 Set the Mechanical End Stops for the X Axis The Mechanical End Stops are aluminum blocks that limit the movement of the car on the axis by stopping the pinion motion for the X-axis (The Y stops are already positioned). The blocks are locked into the slotted track just under the gear rack by two set screws.

  • Page 34: Run The X-2 Motor Cable Through The Aluminum Beam

    Run the X-2 Motor Cable through the Aluminum Beam The X-2 cable from the motor on the front side of your ShopBot runs through the X-Car aluminum beam to the back side of your ShopBot before going to the Control Box.

  • Page 35: Mounting The Router Or Spindle

    Control Box depending on which cutter you specified at the time you placed your order. They are not interchangeable. Before retro-fitting your tool from a router to a spindle or vice-versa, please call ShopBot to discuss the changes you will need to make to reconfigure your tool.

  • Page 36: If You Have A High Frequency Spindle

    ShopBot PRS Assembly Manual Page -36 If You Have a High Frequency Spindle: The spindle will come fitted with a custom aluminum backing plate. This plate attaches to the pre-drilled holes at the bottom of the Z axis using 6, 5/16” socket-head bolts. These bolts pass through the beam and into the plate.

  • Page 37: After Mounting The Router/Spindle

    ShopBot PRS Assembly Manual Page -37 After Mounting the Router/Spindle Now you will run the wire for motors and accessories and do a little tidying up, then you’ll be ready to plug in your tool, test it out, and put it to use. We will use a lot of wire-ties in this step, so in addition to your other tools, get the wire-tie bag handy and a set of nippers to trim them with.

  • Page 38: Proximity Switches

    ShopBot PRS Assembly Manual Page -38 Proximity Switches You’ll find the Proximity/Limit Switches, targets and mounting hardware bagged together. These switches are used to set the zero location for the X- and Y-axes, and also serve to signal the end of the axis to the tool and limit its motion. They switches look like a piece of threaded rod with a wire exiting from one side.

  • Page 39: Y-Axis Targets

    ShopBot PRS Assembly Manual Page -39 • Mount the second Proximity Switch (for the Y Axis) through a hole on the left side of the YZ-Car. • • Y-axis Targets Look at the front side of the Y-Axis Beam on the X Car. You will see t two bolt heads sticking up in the grooves between the two rails.

  • Page 40: X-Axis Targets

    ShopBot PRS Assembly Manual Page -40 • Push the Proximity Switch over these targets and check the spacing. You want about a 2mm gap (.08”) between the target and the Proximity Switch. After you get your tool connected, you can check and adjust these targets.

  • Page 41: Prs Y-Axis Echain Installation

    This document shows how to install the Energy chain (Echain) on the Y-axis on ShopBot PRS and PRS BT models. Note that the dust collection hose from the ShopBot Dust Skirt must be routed overhead when an Echain is installed; the Y-upper Echain bracket has a fixed attachment point for the dust collection hose.
  • Page 42 ShopBot PRS Assembly Manual Page -42 The Echain comes in the length to match the width of the Y-axis of the ShopBot ordered. These Echains are center mounted so the Echain itself will not physically extend from the end plate to the Y-upper Echain bracket.
  • Page 43 Y-upper Echain bracket will be located on the back left side of the YZ car and the Echain will loop to send the cables toward the back of the ShopBot. Step 1: Installing the Y-upper Echain bracket. •...
  • Page 44 ShopBot PRS Assembly Manual Page -44 Step 2: Mounting the Echain to Y-upper bracket • (1) Echain • (2) 10-32 flat head screws • (2) #10 flat washers • (2) #10 lock washers • (2) 10-32 hex nuts Position the Echain so that it loops towards the right when you are facing the front of the YZ car.
  • Page 45 ShopBot PRS Assembly Manual Page -45 Chart showing distance from End Plate to edge of Y-Lower Bracket Cutting width in Y-axis Distance between end plate and Y-lower (Beam length) bracket 32in (47.992in or 1219mm) 22.50in (572mm) 48in (66.338in or 1685mm) 31.50in (800mm)

  • Page 46: Secure Cables And Wiring

    ShopBot PRS Assembly Manual Page -46 Secure cables and wiring Use a chained wire tie (link 3 standard wire ties together) and secure the X-2 Motor Cable to the base of the X-2 Motor. Run the cable to the back side of the front End Plate, and secure it with two wire ties behind the back lip of the plate.
  • Page 47 ShopBot PRS Assembly Manual Page -47 Opening the Echain Move the YZ-car to the far end of the Y-axis so that the motor is not over the Echain. This keeps the motor from interfering with the hinged access bars. With a flat head screw driver, insert the tip into either side of the hinged access bar.
  • Page 48 Neither the hose nor the dust collection system is provided by ShopBot. Extend the length of the overhead dust hose to the ShopBot dust skirt and connect the dust skirt. For more information about the installation and use of the dust skirt, please see Installing the PRS Dust Skirt (SBG00326DustSkirtPRS).

  • Page 49: Run The Yz Wiring

    You’ve now completed assembly of your PRS CNC Tool and are ready to connect it to the Control Box and try it out. The instructions for hooking up to your Control Box are different for PRSalpha and PRSstandard tools. Make sure to use the correct section that describes the connection process for your specific tool.

  • Page 50: Hooking Up To The Control Box

    Do’s and Don’ts DO contract with a licensed electrician experienced with industrial equipment to wire the power to the PRSalpha control box, a spindle/VFD and for a displacement or regenerative vacuum blower system for hold-down. Documentation provided with spindles and blowers details their power requirements.

  • Page 51: Hooking Up Your Prsalpha

    Hooking Up Your PRSalpha Powering the PRSalpha Control Box The power to the PRSalpha Control Box should be wired into a fused disconnect by a licensed electrician familiar with industrial equipment. The Power Requirements for the PRSalpha Control Box and Router/Spindle vary according to your configuration.

  • Page 52: Mount The Prsalpha Control Box

    Mount the PRSalpha Control Box Mount the PRSalpha Control Box in a location so that the operator can reach the front of the Box each time a file is run because it is necessary to hit the start button to engage the safety contactors.

  • Page 53: Explore The Prsalpha Control Box

    Refer to the labeled picture of the PRSalpha Control Box on the next page. The Contactors, located at the top of PRSalpha Control Box, are the large relays that control power to the equipment. They are controlled by the e-Stop and by software. The size of the contactor may vary with the power requirements of the device it is powering.

  • Page 54: Inside The Prsalpha Control Box

    ShopBot PRS Assembly Manual Page -54 Inside the PRSalpha Control Box Your box may not be exactly the same as illustrated depending on the model. 1. Disconnect switch 2. Grounding strip 3. Fuses 4. 24v Power Supply 5. 12v Power Supply 6.

  • Page 55: Open The Roxtec Fixture

    Open the Roxtec Fixture You will be routing cables through the Roxtec Wire Management Fixture attached to the side of the PRSalpha Control Box. This device gives all wires a tight entry and will seal your PRSalpha Control Box against dust and debris.

  • Page 56: Connect The Emergency Stop Switch And The 3-Button Pendant

    PRSalpha Control Box. Your PRSalpha Control Box may differ slightly from pictures in the manual depending on which model you have. If you have a 3-Button Pendant, your PRSalpha Control Box will not have Start/Reset buttons.

  • Page 57: Installation

    ShopBot PRS Assembly Manual Page -57 Installation Run the cables from the 3-Button Pendant and the separate E-stop switch into the PRSalpha Control Box through the Roxtec opening and plug in the terminal blocks as shown below. Below: The PRSalpha Control Box before the terminal block from the 3-Button Pendant is attached.

  • Page 58: Connect Cables From The Proximity Switch And Z-Zero Plate

    Note that the terminal blocks can be removed to make wire insertion easier. When the PRSalpha Control Box is powered up a red LED in the body of the proximity switch out on the tool will stay bright until it is triggered by coming near a target.

  • Page 59: Seal The Cable Entry

    USB cable into your computer at this point. Seal the Cable Entry When you have attached all the cables in the PRSalpha Control Box, it’s time to put the gaskets around them and close up the Roxtec fixture. The Roxtec system is designed to keep dust out of the PRSalpha Control Box. Take a moment to fit each of the cables into a gasket so that the cables fit snugly and the two halves of the gasket close well.

  • Page 60: Connect The Usb Cable From Prsalpha Control Box To Computer

    On many computers, there are multiple slots for the USB cable. Once you have decided on the one you are going to use, always plug the ShopBot USB cable into the same slot. Plug the USB cable into the USB port on your computer.

  • Page 61: Hooking Up Your Prsstandard

    The white wire from the Remote-Stop is connected to the Ground connection at the left side of the Input connector. The Black wire is connected to Input terminal #4, which corresponds to Input Switch #4 in your ShopBot Software. Using a tiny screw driver, snug up the wires into the correct location.

  • Page 62: Connect The Cables From The Proximity Switch And Z-Zero Plate

    Standard Control Box to your computer. It is a short cable that exits on the right side of the Control Board. Plug the longer 10ft cable supplied with your ShopBot into this connector. Do not plug the USB cable into your computer at this point.

  • Page 63: Connect The Usb Cable From Prs Standard Control Box To The Computer

    On many computers, there are multiple slots for the USB cable. Once you have decided on the one you are going to use, always plug the ShopBot USB cable into the same slot. Plug the USB cable into the USB port on your computer.

  • Page 64: Mission Accomplished

    ShopBot PRS Assembly Manual Page -64 Mission Accomplished! You might have thought you'd never get here, but: “Mission Accomplished!” PRSAssembly080922.doc Copyright 2007,2008 ShopBot Tools, Inc...
  • Page 65 PRS Assembly Appedix Page -1- Assembly Appendix Stopping the ShopBot Test Spin Surfacing the Table Squaring and Adjusting the X-Car Table Drawings AssemblyAppendixintro.doc Copyright 2008 ShopBot Tools, Inc...
  • Page 66 PRS Assembly Appedix Page -2- AssemblyAppendixintro.doc Copyright 2008 ShopBot Tools, Inc...
  • Page 67 • Release the red button on the E-Stop by rotating it • Press the RESET button on the PRSalpha Control Box to send power to the spindle/router and motors on your tool. • Clear the message box in the control software by pressing “Quit”.
  • Page 68 The presence of a Remote Stop Switch does not alter the need to good safety procedures for operating your ShopBot. You should always stand clear of the tool when it is in movement, preferably positioning yourself near the computer controlling the operation. A Personal Robotic Tool can be a very safe power tool as long as all safety procedures are followed.
  • Page 69 Run Your ShopBot Now and Check out Some of its Basic Functions. Start the Control Box. If your tool is a PRSalpha, also hit the blue “Reset” button on the box (this activates the relay systems). Your first moves will just be 'air' cuts, so you do not need to have a bit.
  • Page 70 Locations Display for your tool. The second screen is the Control Console which is the place you to enter Commands to tell your ShopBot what you would like it to do. You can use the keyboard or mouse to select commands from the Main Menu bar, or you can enter two letter ShopBot Commands right into the Command Box on the Console.
  • Page 71 • If all has worked well so far, jog back to the starting point using both axes. Use: [J2] 0, 0. Your tool should move rapidly back to where you last zeroed it. TestSpinPRS080916 Copyright 2008 ShopBot Tools, Inc...
  • Page 72 ENTER twice again to start air-cutting the file. • This file cuts the ShopBot logo (normally you would use a 'V' bit), and you can cut it in all different sizes using the proportion feature in the [FP] Command. Note that the underline portion of the logo cuts first, followed by the letters.
  • Page 73 This can be installed on a separate design computer if you wish. Tutorials will be copied to your computer as part of the installation process. Go to Start > All Programs > ShopBot > Tutorials to open them. The accompanying videos are available for download at www.shopbottools.com >...
  • Page 74 This page left blank.
  • Page 75 Surfacing Table Page -1- Surfacing Your Table One of the first things you'll want to do after getting your ShopBot together and running is to smooth your work surface. Here are a set of general procedures for surfacing your table.
  • Page 76 NOTE: the space after the M2 and the COMMA are very important. Send the router to the lower right corner [M2] 96, 0 to Move 2 Dimensions (the SurfacingTable080916 Copyright 2008 ShopBot Tools, Inc...
  • Page 77 Lower the Z to that point. [K] and PageDown. Read the Z location on the screen on the ShopBot Position screen (red)… it should be a negative number if this point is lower than your original start point.
  • Page 78 Accept [Enter] then [Enter] again to run it. Tools > TS There is also a Table Surfacing Tool in the ShopBot Software under Tools. This is a simplified version of what you’ve just done and will be useful for routine re-surfacings. SurfacingTable080916...
  • Page 79 X axis by moving The X-Car up and down the rails, checking the position of the sheet at the tip of the cutter. SquaringXCar080916 Copyright 2008 ShopBot Tools, Inc...
  • Page 80 Then, when you’ve got it square, turn the power to on to the Control Box, and if a PRSalpha, hit the Reset Button. The motors will power on and lock into position. Your tool is now square in X and Y, and it will remain square whenever it moves until the power is removed.
  • Page 81 Note that as a cutter becomes dull, it will require more force to push through the material and thus will also generate more side force. SquaringXCar080916 Copyright 2008 ShopBot Tools, Inc...
  • Page 82 Making an Adjustment for Wheel Bearing Alignment or Square The X-Car of your PRS ShopBot is the primary structural component of the tool. We build the X-Car in a precision fixture that exactly spaces the wheel bearings and that assures a perfectly square and true gantry.
  • Page 83 Table Drawings PRS Table Drawings ShopBot Tools, Inc 3333B Industrial Dr Durham, NC 27704 919-680-4800 or 888-680-4466 www.shopbottools.com TablePlansCover.doc Copyright 2007 ShopBot Tools, Inc...
  • Page 84 DECK MATERIAL. .000 Durham, North Carolina TITLE TABLE 48-48-8S DRAWN DATE CHECKED APPROVED 06/20/07 SIZE DRAWING NUMBER 10630-00 06/20/07 INITIAL PRODUCTION RELEASE SCALE PART NUMBER NONE 10630-01 CHG NOTICE DATE REVISION DESCRIPTION APVD ©2004, SHOPBOT TOOLS, INC., ALL RIGHTS RESERVED...
  • Page 85 OF DECK MATERIAL. .000 Durham, North Carolina TITLE TABLE 48-60-8S DRAWN DATE CHECKED APPROVED 06/20/07 SIZE DRAWING NUMBER 10631-00 06/20/07 INITIAL PRODUCTION RELEASE SCALE PART NUMBER NONE 10631-01 CHG NOTICE DATE REVISION DESCRIPTION APVD ©2004, SHOPBOT TOOLS, INC., ALL RIGHTS RESERVED...
  • Page 86 OF DECK MATERIAL. .000 Durham, North Carolina TITLE TABLE 60-60-8S DRAWN DATE CHECKED APPROVED 06/20/07 SIZE DRAWING NUMBER 10634-00 06/20/07 INITIAL PRODUCTION RELEASE SCALE PART NUMBER NONE 10634-01 CHG NOTICE DATE REVISION DESCRIPTION APVD ©2004, SHOPBOT TOOLS, INC., ALL RIGHTS RESERVED...
  • Page 87 Item No. Qty Part Number Description 000925-01 TABLE SIDE 96E 000919-01 TABLE LEG 6E 000770-01 TABLE GUSSET 000915-01 TABLE SUPPORT UPPER 48E 64.500 000921-01 TABLE SUPPORT LOWER 48E 48.0 000926-01 TABLE SUPPORT CROSS 48E 000661-01 MACHINE GLIDE 000160-01 NUT HEX 5/8-11 Z5 72 000727-01 NUT T HEAVY DUTY 5/16-18 72 000529-01...
  • Page 88 Item No. Qty Part Number Description 000925-01 TABLE SIDE 96E 000919-01 TABLE LEG 6E 000770-01 TABLE GUSSET 001486-01 TABLE SUPPORT UPPER 60E 001487-01 TABLE SUPPORT LOWER 60E 76.500 18.0 001485-01 TABLE SUPPORT CROSS 60E 000661-01 MACHINE GLIDE (60.0) 000160-01 NUT HEX 5/8-11 Z5 72 000727-01 NUT T HEAVY DUTY 5/16-18 42.0...
  • Page 89 OF DECK MATERIAL. .000 Durham, North Carolina TITLE TABLE 120-48-8S DRAWN DATE CHECKED APPROVED 06/20/07 SIZE DRAWING NUMBER 10635-00 06/20/07 INITIAL PRODUCTION RELEASE SCALE PART NUMBER NONE 10635-01 CHG NOTICE DATE REVISION DESCRIPTION APVD ©2004, SHOPBOT TOOLS, INC., ALL RIGHTS RESERVED...
  • Page 90 OF DECK MATERIAL. .000 Durham, North Carolina TITLE TABLE 120-60-8S DRAWN DATE CHECKED APPROVED 06/20/07 SIZE DRAWING NUMBER 10636-00 06/20/07 INITIAL PRODUCTION RELEASE SCALE PART NUMBER NONE 10636-01 CHG NOTICE DATE REVISION DESCRIPTION APVD ©2004, SHOPBOT TOOLS, INC., ALL RIGHTS RESERVED...
  • Page 91 OF DECK MATERIAL. .000 Durham, North Carolina TITLE TABLE 120-72-8S DRAWN DATE CHECKED APPROVED 03/02/07 SIZE DRAWING NUMBER 10625-00 05/08/07 INITIAL PRODUCTION RELEASE SCALE PART NUMBER NONE 10625-01 CHG NOTICE DATE REVISION DESCRIPTION APVD ©2004, SHOPBOT TOOLS, INC., ALL RIGHTS RESERVED...
  • Page 92 OF DECK MATERIAL. .000 Durham, North Carolina TITLE TABLE 144-48-8S DRAWN DATE CHECKED APPROVED 06/20/07 SIZE DRAWING NUMBER 10637-00 06/20/07 INITIAL PRODUCTION RELEASE SCALE PART NUMBER NONE 10637-01 CHG NOTICE DATE REVISION DESCRIPTION APVD ©2004, SHOPBOT TOOLS, INC., ALL RIGHTS RESERVED...
  • Page 93 OF DECK MATERIAL. .000 Durham, North Carolina TITLE TABLE 144-60-8S DRAWN DATE CHECKED APPROVED 06/20/07 SIZE DRAWING NUMBER 10638-00 06/20/07 INITIAL PRODUCTION RELEASE SCALE PART NUMBER NONE 10638-01 CHG NOTICE DATE REVISION DESCRIPTION APVD ©2004, SHOPBOT TOOLS, INC., ALL RIGHTS RESERVED...
