Omron E5CN-HT Instruction Manual

E5CN-HT
Digital Controller
EN
Instruction Manual
Thank you for purchasing the OMRON E5CN-HT Digital
Controller. This manual describes the functions, performance,
and application methods needed for optimum use of
the product.
Please observe the following items when using the product.
• This product is designed for use by qualified personnel with
a knowledge of electrical systems.
• Before using the product, thoroughly read and understand
this manual to ensure correct use.
• Keep this manual in a safe location so that it is available for
reference whenever required.
OMRON CORPORATION
©All Rights Reserved
For detailed operating instructions, refer to the E5CN-HT/E5AN-HT/E5EN-HT
Digital Controllers User's Manual (Cat. No. H169).
Significance of WARNINGs and CAUTIONs
Safety Precautions
Key to Warning Symbols
Indicates a potentially hazardous situation which, if
not avoided, is likely to result in minor or moderate
injury or property damage. Read this manual
CAUTION
carefully before using the product.
2152761-5A
CHT1
Wiring
Dimensions
6 91
Dimensions (mm)
78
1.5
×
48 48
Watertight Adapter Terminal
cover
packing
* The main unit can be removed for maintenance without disconnecting the terminal wiring.
* Do not remove the terminal block. Doing so may result in failure or malfunction.
* A Setup Tool port is provided on the bottom of the product. Use this port to connect a personal computer to the
product when using the Setup Tool. E58-CIFQ1 USB-Serial Conversion Cable is required to connect the personal
computer to the product. (Do not use the product with the USB-Serial Conversion Cable left permanently connected.)
Refer to the instruction manual provided with the USB-Serial Conversion Cable for details on connection methods.
Names of parts on front panel
•
Level key
Use this key to change levels:
• Press the O key and the M key
together for at least 3 seconds
to switch to protect level.
• Mode key
Press this key to change the
contents of the display.
Press this key for 1 s or longer
for reverse scroll.
The function that is set for the PF
Setting parameter will operate when
the M Key and U Key are pressed
at the same time for at least one
second.
Operation menu
Input type
Input type Input Setting Input setting range
−200.0 to 850.0 ( / −300.0 to 1500.0 (
0
°C)
−199.9 to 500.0 ( / −199.9 to 900.0 (
Platinum Pt100 1
°C)
resistance 2
0.0 to 100.0 ( °C) / 0.0 to 210.0 (
thermometer −199.9 to 500.0 (
/ −199.9 to 900.0 (
3 °C)
JPt100
4 0.0 to 100.0 ( °C) / 0.0 to 210.0 (
−200.0 to 1300.0 ( / −300.0 to 2300.0 (
K 5 °C)
−20.0 to 500.0 (
/ 0.0 to 900.0 (
6 °C)
Thermocouple
−100.0 to 850.0 ( / −100.0 to 1500.0 (
J 7 °C)
−20.0 to 400.0 (
8 °C) / 0.0 to 750.0 (
−200.0 to 400.0 (
/ −300.0 to 700.0 (
T 9 °C)
−199.9 to 400.0 ( / −199.9 to 700.0 (
10 °C)
−200.0 to 600.0 ( / −300.0 to 1100.0 (
E 11 °C)
−100.0 to 850.0 ( / −100.0 to 1500.0 (
12
L °C)
−200.0 to 400.0 ( / −300.0 to 700.0 (
13
U °C)
−199.9 to 400.0 ( / −199.9 to 700.0 (
14
°C)
−200.0 to 1300.0 (
15 / −300.0 to 2300.0 (
N °C)
16
R 0.0 to 1700.0 ( °C) / 0.0 to 3000.0 (
S 17 0.0 to 1700.0 ( °C) / 0.0 to 3000.0 (
B 18 100.0 to 1800.0 ( °C) / 300.0 to 3200.0 (
19 0.0 to 2300.0 ( / 0.0 to 3200.0 (
°C)
W
20 0.0 to 1300.0 (
°C) / 0.0 to 2300.0 (
PLII
−50.00 to 200.00 ( / −50.00 to 200.00 (
21
°C)
K
−50.00 to 200.00 (
22 / −50.00 to 200.00 (
°C)
J
23 −50.00 to 200.00 ( / −50.00 to 200.00 (
°C)
T
Platinum
−50.00 to 200.00 (
24 / −50.00 to 200.00 (
resistance Pt100 °C)
thermometer
25 One of the following ranges is used depending on scaling.
4 to 20mA
Current input
26 −19999 to 32400
0 to 20mA
−1999.9 to 3240.0
1 to 5V 27
Voltage input −199.99 to 324.00
0 to 5V 28
−19.999 to 32.400
0 to 10V 29
*The default is"5".
*s. e rr will be displayed when a platinum resistance thermometer is mistakenly connected while
input type is not set for it. To clear the s.err display, correct the wiring and cycle the power supply.
Alarms
Alarm output function
Setting Alarm type
Positive alarm value (X) Negative alarm value (X)
Output off
No alarm function
0
Deviation upper/lower limit
*1 1
X
ON
2
Deviation upper limit
OFF
SP
X
ON
3
Deviation lower limit
OFF
SP
L H
*1 4 ON
Deviation upper/lower range
OFF
SP
L H
Deviation upper/lower limit
5 ON
*1
standby sequence ON OFF
SP
X
Deviation upper limit
ON
6
standby sequence ON
OFF
SP
X
Deviation lower limit
ON
7
standby sequence ON OFF
SP
X
ON
8 Absolute value upper limit
OFF
0
X
ON
9 Absolute value lower limit
OFF
0
Absolute value upper limit X
ON
10
standby sequence ON
OFF
0
Absolute value lower limit X
ON
11
standby sequence ON
OFF
0
12 LBA (only for alarm 1)
13
PV change rate alarm
*1: Upper and lower limits can be set for parameters 1, 4 and 5 to provide for
different types of alarm. These are indicated by the letter "L" and "H".
• The default alarm type is "2"
Error display (trouble shooting)
When an error has occurred, the No.1 display shows the error code. Take
necessary measure according to the error code, referring the table bellow.
No.1 display Meaning Action
Check the setting of the Input Type parameter,
s.err Input error
(S. Err) check the input wiring, and check for broken or
*2
shorts in the temperature sensor.
After the correction of A/D converter error, turn the
power OFF then back ON again. If the display
A/D converter error
remains the same, the controller must be repaired.
e333
(E333) If the display is restored to normal, then a
*2
probable cause can be external noise affecting the
control system. Check for external noise.
Turn the power OFF then back ON again. If the
display remains the same, the controller must be
e111
Memory error repaired. If the display is restored to normal, then
(E111)
a probable cause can be external noise affecting
the control system. Check for external noise.
If the input value exceeds the display limit ( -19999 to 32400), though it is within the control
range, [[[[ will be displayed under -19999 and ]]]] above 32400. Under these conditions,
control output and alarm output will operate normally.
For information on the controllable range, refer to the E5CN-HT/E5AN-HT/E5EN-HT Digital Controllers
User's Manual (Cat. No. H169).
*2: Error shown only for "Process value / Set point". Not shown for other status.
Warning Symbols
CAUTION
Do not touch the terminals while power is being supplied.
Doing so may occasionally result in minor injury due to electric shock.
Do not allow pieces of metal, wire clippings, or fine metallic shavings or filings from installation to
enter the product. Doing so may occasionally result in electric shock, fire, or malfunction.
Do not use the product where subject to flammable or explosive gas. Otherwise, minor injury from
explosion may occasionally occur.
Never disassemble, modify, or repair the product or touch any of the internal parts. Minor electric
shock, fire, or malfunction may occasionally occur.
CAUTION - Risk of Fire and Electric Shock
a) This product is UL listed as Open Type Process Control Equipment. It must be mounted in an enclosure that
does not allow fire to escape externally.
b) More than one disconnect switch may be required to de-energize the equipment before servicing.
c) Signal inputs are SELV, limited energy.
d) Caution: To reduce the risk of fire or electric shock, do not interconnect the outputs of different Class 2 circuits.
If the output relays are used past their life expectancy, contact fusing or burning may occasionally occur. Always
consider the application conditions and use the output relays within their rated load and electrical life expectancy.
The life expectancy of output relays varies considerably with the output load and switching conditions.
Tighten the terminal screws to between 0.74 and 0.90 N•m. Loose screws may occasionally result in fire.
Set the parameters of the product so that they are suitable for the system being controlled. If they are not suitable,
unexpected operation may occasionally result in property damage or accidents.
A malfunction in the Digital Controller may occasionally make control operations impossible or prevent
alarm outputs, resulting in property damage. To maintain safety in the event of malfunction of the Digital
Controller, take appropriate safety measures, such as installing a monitoring device on a separate line.
Suitability for Use
OMRON shall not be responsible for conformity with any standards, codes, or regulations that
apply to the combination of the products in the customer's application or use of the product.
Take all necessary steps to determine the suitability of the product for the systems, machines,
and equipment with which it will be used.
Know and observe all prohibitions of use applicable to this product.
NEVER USE THE PRODUCTS FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE
OR PROPERTY WITHOUT ENSURING THAT THE SYSTEM AS A WHOLE HAS BEEN
DESIGNED TO ADDRESS THE RISKS, AND THAT THE OMRON PRODUCT IS PROPERLY
RATED AND INSTALLED FOR THE INTENDED USE WITHIN THE OVERALL EQUIPMENT
OR SYSTEM.
See also Product catalog for Warranty and Limitation of Liability.
Installation
In the pack:
Individual mounting (mm) Side-by-side mounting (waterproof not possible) (mm)
*Main unit
*Watertight packing
*Adapter
*Instruction manual
*Terminal cover (Provided only for models with "-500"
suffix only)
+0.6
45
0
Solderless terminal size: M3.5
Terminal cover: E53-COV17
• Insert the controller through the hole in the panel. Push the adapter on from the rear and
USB-Serial Conversion Cable
fasten temporarily, removing any gap between the controller, panel and adapter. Finally,
(Sold Separately)(E58-CIFQ1)
secure two fixing screws alternately keeping the torque to between 0.29 to 0.39 N•m.
• Make sure that the surrounding temperature does not exceed the allowable operating
temperature given in the specifications especially when two or more controllers are
mounted.
• No.1 display
Operation indicators
Process value or set data symbol
• SUB1: Auxiliary output 1 indicator
Lit when the function assigned to
• auxiliary output 1 is ON.
No.2 display
• SUB2: Auxiliary output 2 indicator
Set point, set data read-out value or
Lit when the function assigned to
changed input value
auxiliary output 2 is ON.
• SUB3: Auxiliary output 3 indicator
Lit when the function assigned to
auxiliary output 3 is ON.
• Up and Down keys
• HA: Heater burnout alarm/Heater short
Use the keys to change the values
alarm/Heater overcurrent alarm indicator
displayed on the No.2 display. Lit when a heater burnout alarm, heater
Each press of U key increments or advances short alarm, or heater overcurrent alarm
has occurred.
the values displayed on the No.2 display.
• WAIT: Lit while the program is in wait
Each press of D key decrements or returns
status.
the values displayed on the No.2 display.
Operation stopped.
Initial Setting Level
(Control/alarm are both stopped.)
°F)
in-t
°F)
Input Type *3
5
°F)
°F)
in-h
°F)
Scaling Upper Limit
*6
°F)
(only when setting analog input)
100
°F)
°F)
in-l
°F) Scaling Lower Limit
*6
°F) (only when setting analog input)
0
°F)
°F)
dp
Decimal Point
°F)
*6
(only when setting analog input)
0
°F)
°F) c
Temperature Unit ° C =
°F) d-u f
° F =
°F) *6
c
(C stands for Celsius,
°F)
F for Fahrenheit)
°F)
sl-h
°F)
SP Upper Limit
°F) 1300.0
°F)
°F)
sl-l
°F)
SP Lower Limit
-200.0
°F)
PID/ONOFF
: cntl
onof
In ON/OFF control =
pid pid
In 2-PID control =
Standard or Heating/Cooling
stnd
s-hc
Standard control =
h-c
Heating and cooling control =
stnd
(Select standard control or heating
and cooling control as required)
cp
*6 Control Period
20
(Heating)(Unit: Seconds)
c-cp
Control Period (Cooling)(Unit:
*6
20 Seconds)
orev Direct/Reverse OperationIn
or-r
Reverse operation (Heating) =
or-r
or-d
In Direct operation (Cooling) =
Vary with "L", "H" values
alt1
*3
Alarm 1 Type:
*6
X
2 *4
ON
OFF
SP
X alh1
ON
Alarm 1 Hysteresis
*6
OFF
SP 0.2
Vary with "L", "H" values
alt2
*3
*6 Alarm 2 Type:
*4
2
Vary with "L", "H" values
alh2
X
ON
*6 Alarm 2 Hysteresis
OFF
0.2
SP
X
ON
tr-t
OFF
SP
*6 Transfer Output Type
off
X
ON
OFF
0
tr-h
X
ON *6 Transfer Output Upper Limit
100.0
OFF
0
X
ON
tr-l
OFF
*6 Transfer Output Lower Limit
0
0.0
X
ON
OFF
0
o1-t
*6 Linear Current Output
4-20
sqr
Extraction of Square Root Enable
*6
(Only when analog input is set)
off
t-u
Program Time Unit
h-m
t-pr
Time Setting/Slope Setting
time
Status at error
pru
*6
Control Slope Time Setting Unit
Alarm
m
output
Operates
OFF
as above the
rtsm
upper limit.
Reset Operation
stop
OFF OFF
p-on
Operation after Power ON
cont
eset
OFF OFF Operation at End of Operation
rst
pvst
*6 PV Start
sp
amov
Move to Advanced Function
*6
0 Setting Level
Initial setting level enables users to specify their
preferred operating conditions
(input type, alarm type, control method, etc.)
Precautions for Safe Use
Observe the following precautions to prevent failure to operate, malfunctions, or undesirable effects on
product performance and functions. Problems may occasionally occur. Do not handle the Controller in ways
that exceed product specifications.
(1) This product is designed for indoor use only. Do not use or store the product in any of the following
places.
•Places directly subject to heat radiated from heating equipment.
•Places subject to splashing liquid or oil atmosphere.
•Places subject to direct sunlight.
•Places subject to dust or corrosive gas (in particular, sulfide gas and ammonia gas).
•Places subject to intense temperature change.
•Places subject to icing and condensation.
•Places subject to vibration and large shocks.
(2) Use/store within the rated temperature and humidity ranges.
Provide forced-cooling if required.
(3) To allow heat to escape, do not block the area around the product.
Do not block the ventilation holes on the product.
(4) Be sure to wire properly with correct polarity of terminals.
(5) Use specified size (M3.5, width 7.2 mm or less) crimped terminals for wiring. To connect bare wires to
the terminal block, use copper braided or solid wires with a gage of AWG24 to AWG14 (equal to cross-
sectional area of 0.205 to 2.081 mm2). (The stripping length is 5 to 6 mm.) Up to two wires of same
size and type, or two crimped terminals can be inserted into a single terminal.
(6) Do not wire the terminals which are not used.
(7) Allow as much space as possible between the controller and devices that generate a powerful high-
frequency or surge.
Separate the high-voltage or large-current power lines from other lines, and avoid parallel or common
wiring with the power lines when you are wiring to the terminals.
(8) Use this product within the rated load and power supply.
(9) Make sure that the rated voltage is attained within two seconds of turning ON the power using a switch
or relay contact. If the voltage is applied gradually, the power may not be reset or output malfunctions
may occur.
(10) Make sure that the Digital Controller has 30 minutes or more to warm up after turning ON the power
before starting actual control operations to ensure the correct temperature display.
(11) A switch or circuit breaker should be provided close to this unit.
The switch or circuit breaker should be within easy reach of the operator, and must be marked as a
disconnecting means for this unit.
(12) Always turn OFF the power supply before pulling out the interior of the product, and never touch nor
apply shock to the terminals or electronic components. When inserting the interior of the product, do
not allow the electronic components to touch the case.
(13) Do not use paint thinner or similar chemical to clean with. Use standard grade alcohol.
(14) Design system (control panel, etc) considering the 2 second of delay that the controller's output to be
set after power ON.
(15) The output may turn OFF when shifting to certain levels. Take this into consideration when performing
control.
(16) The number of non-volatile memory write operations is limited. Therefore, use RAM write mode when
frequently overwriting data during communications or other operations.
(17) Always use suitable tools to dismantle the product for disposal.
(18) Do not continue to use the product if the front surface peels or becomes cracked.
Connections
The E5@N-HT is set for a K thermocouple (input type of 5) by
default. If a different sensor is used, an input error (s.err) will
occur. Check the setting of the Input Type parameter.
+1
(48 x number of units - 2.5)
0
Relay output
250VAC 3A
(resistive load)
Voltage output
(for driving SSR)
12 VDC 21 mA
When waterproofing is required, be sure to mount the
Linear voltage output
controller separately.
0-10 VDC
Load: 1 kΩ min.
Attach the waterproof packing from the terminal side and
Current output
then insert the controller to the panel. Recommended panel
0-20 mADC
thickness is 1 to 5 mm.
4-20 mADC
Load 600 Ω max
• A heater burnout alarm, heater short alarm, heater overcurrent alarm, or input alarm is output to the output to which the alarm 1 function is assigned.
• The voltage output (control output) is not electrically insulated from the internal wiring. When using a grounded thermocouple thermometer, one or the other
of the control output terminals must not be grounded. (If both terminals are grounded, measurements will be unreliable due to sneak current.)
• The last character of the lot number "R" indicates that reinforced insulation is provided between input power supply, relay outputs, and between other
terminals.
• OUT1: Control output 1 indicator
Lit when control output 1 is ON and not lit
when it's OFF.
For a current output, lit except for a 0% output.
• OUT2: Control output 2 indicator
Lit when control output 2 is ON and not lit
when it's OFF.
• CMW: communications writing enable/ disable
indicator
Lit when communications writing is
"enabled" and is out when it is "disabled".
• FSP: Lit during Constant-value SP Mode.
Settings shown below are the parameters displayed for the models without options.
(Options include heater burnout detection, communications, event inputs, and
control output 2.)
*5
Check the wiring before turning ON the power supply.
Program Setting Level
POWER ON
Hold O down for at least 1 second d.prg
d.prg
Hold O down for at
Press O
least 3 seconds
Key for
less than
Operation Level
1 s.
PV/SP
25.0
s.err is displayed when s-no
connected sensor is
0.0
8
different from input type.
a-m
Auto/Manual Switch
d.seg
*6
d.seg
end
prg
Program Number
0
seg
Segment No. Monitor
0
hold
pid
Hold
*6
off
1
adv
al-1
*6 Advance
*6
off
0.0
stbm
Remaining Standby
al1h
*6
Time Monitor
*6
0.00
0.0
prgt
Elapsed Program
*6 al1l
0.00 Time Monitor *6
0.0
rptm
Program Execution
*6 al-2
Repetition Monitor
*6
0
0.0
Run/Reset
At start of program operation:
r-r
run
al2h
*6
rst
At end of program operation:
0.0
rst
al2l
Operation level should normally be
*6
used during operations.
0.0
al-3
Hold O and M Hold O and M *6
0.0
keys down for keys down for
at least 1 second at least 3 seconds
al3h
*6
Protect Level 0.0
al3l
*6
oapt 0
Operation / Adjustment
Protect
0
rpt
0
icpt
Initial Setting /
Communication Protect
0
In this level, the SPs and times
wtpt
are input for the programs.
Setting Change Protect
off
AT (auto-tuning)
prlp
Password to Move
AT in Adjustment level
*
to Protect Level
0
Designate "at-2: 100% AT execute" or
"at-1: 40% AT execute" to execute AT and
"off: AT cancel" to cancel AT.
Restricts which settings can be displayed
or changed, and restricts change by key
"100%AT Execute"
operation.
at
off
*3: Refer to the adjoining tables for details of input
types and alarm types.
"AT cancel"
*4: Applicable only to models with alarm functions.
Also when AT execution ends, the
*5: Operation is stopped when moved to the initial
display automatically returns to "off".
setting level.
(Control/alarm are both stopped.)
Protection function
*6: The grayed-out setting items may not be
Protection function, to prevent unwanted settings,
displayed according to the models and setting.
restricts the setting items to be used or designates
if operation of the key is valid or invalid.
Advanced Function
Setting Level Other functions
For parameters in the Advanced Function Setting
init
Level, PID Setting Level, Monitor/Setting Item
Parameter
Hold O down
off Initialization Level, and Manual Control Level and for other
for at least
information, refer to the
1 second
For other information, refer to the
E5CN-HT/E5AN-HT/E5EN-HT User's Manual
User's Manual (Cat. No. H169).
(Cat. No. H169).
Moving to the next level is
For information on communications, refer to the
possible when the password
E5CN-HT/E5AN-HT/E5EN-HT Communications
(-169) is input.
Manual (Cat. No. H170).
Specifications
Power supply voltage
Operating voltage range
Power consumption
Indication accuracy
(Ambient temperature: 23°C)
Event input
Contact input
No-contact input
Control output 1
Control output 2
Control method
Auxiliary outputs
Ambient temperature
Ambient humidity
Storage temperature
Altitude
Recommended fuse
Weight
Degree of protection
Installation environment
Memory protection
Transfer output
(The applicability of the electric terminals varies with the type of machine.)
+
C C ontrol outpu trol output
1
−
Auxiliary output 1
+
A
DO NOT DO NOT
mA USE USE
− − B
Control output 1
−
V
DO NOT B
+
USE +
Communications
Communications Event inputs and p p
Control output 2
( (RS-485) ) and
(RS-485) ( and and 2 CTs control output 2
control output 2
2 CTs
B(+) +
B(+)
11 11 11
11
Control output 2 rol output p p p
RS-485
RS-485
12VDC,21 mA A DC,21 m
12 12 12 12
EV1
A(−) -
A(−)
DO NOT USE 13 13 13
13
EV2
+
+
CT2
CT2 14 14 14
14
Control output 2 ol output 2 p p p Control output 2 rol output p p p
CT1
. CT1
12VDC,21 mA DC,21 mA 12VDC,21 mA A DC,21 m
15 15 15 15
-
-
•
°C / °F : Temperature unit
The temperature unit is displayed
when the displayed value
temperature.
When this parameter is set to"°C",
"C" is displayed, and when set to
"°F", "F "is displayed.
•
:Protection indicator
Lit when Setting Change Protect is
ON (disables the Up and Down Keys).
MANU: Manual output indicator
•
Lit when the Auto/Manual Mode is set
to Manual Mode.
RST: Lit while the program is being reset.
•
Only the value set to the ins: temperature input shift parameter is applied to
the entire temperature input range. When the process value is 200°C, the
Adjustment Level
process value is treated as 201.2°C after input shift if the input shift value is
set to 1.2°C. The process value is treated as 198.8°C after input shift if the
Press O Key for input shift value is set to -1.2°C.
less than 1 s.
l.adj
Adjustment Level
Display Program Selection
0 AT Execute / Cancel
at
d.prg
1 *6 100%AT Execute
off
40%AT Execute
2
d.prg
spmd
7
*6
SP Mode
psp
Number of Segments fsp
Constant SP
Used, 1 to 32
0.0
Display Segment Selection,
ins
Temperature Input Shift
END or 0 to Number of *6
(Unit: °C or °F)
0.0
Segments − 1
d.seg
0
Upper Limit Temperature
insh
1 Input Shift Value
*6
d.seg 0.0 when 2 point input shift
is selected
7
Lower Limit Temperature
insl
*6 Input Shift Value
0.0
when 2 point input shift
is selected
p
*6 Proportional Band
styp
PID Set Segment
8.0
*6
No. n Format
ramp
i
Integral Time
*6
sp
(Unit: secs)
Alarm Segment 233.0
*6
n SP
Value 1
0.0
d
Derivative Time
*6
Alarm
pr (Unit: secs)
Segment 40.0
Upper
*6
n Slope
0.0
Limit 1
c-sc
*6 Cooling Coefficient
Alarm
time
Segment 1.00
Lower
*6
n Time
0.00
Limit 1
PID Setting Level
Alarm
Value 2
link
Program Link
O
Press Key for
Destination
end
less than 1 s.
Alarm
Upper
ts1s Operation/Adjustment protection
Limit 2 Time Signal 1
*6
Set Segment
0 The following table shows the relationship between settings and
Alarm
protect limits related to Operation level and Adjustment level.
Lower
on1
Limit 2 Time Signal 1
*6
Level
ON Time
0.00
Alarm
Process value
Value 3
of1
Time Signal 1
PV/SP
*6
OFF Time
0.00
Others
Alarm
Upper
Program Setting Level
t525
Limit 3 Time Signal 2
*6
Adjustment level
Set Segment
0
Alarm
PID Setting Level
Lower
on2
Limit 3 Time Signal 2
Initial setting/Communications protection
*6
ON Time
0.00 This protect level restricts movement to the initial setting level,
Program communications setting level and advanced function setting level.
Repetitions
of2
Time Signal 2
Initial setting
*6
Set value
OFF Time
0.00 level
0
1
2 ×
: Change to other levels possible
Default setting : 0
Setting change protection
Setting changes by key operation are restricted.
OFF off: Setting can be changed by key operation
ON on
: Setting cannot be changed by key operation ("
"at" flashes
(Protect level settings can all be changed.)
PF key protection
U at
Protection can be set for the PF Key operation. The PF Key operation is
at-2
D executed by pressing the M and U Keys at the same time.
OFF "off": PF Key enabled.
ON "on" : PF Key disabled.
OMRON EUROPE B.V.
Wegalaan 67-69, NL-2132 JD Hoofddorp The Netherlands
Phone 31-2356-81-300
FAX 31-2356-81-388
OMRON ELECTRONICS LLC
One Commerce Drive Schaumburg, IL 60173-5302 U.S.A
Phone 1-847-843-7900
FAX 1-847-843-7787
OMRON ASIA PACIFIC PTE. LTD.
No. 438A Alexandra Road # 05-05/08 (Lobby 2),
Alexandra Technopark, Singapore 119967
Phone 65-6835-3011
FAX 65-6835-2711
OMRON Corporation
Shiokoji Horikawa, Shimogyo-ku, Kyoto 600-8530 JAPAN
100 to 240 VAC, 50/60 Hz or
24 VAC, 50/60 Hz /24 VDC
85 to 110% of the rated voltage
Approx. 8.5 VA (100 to 240 VAC)
Approx. 5.5 VA (24 VAC) /
Approx. 3.5 W (24 VDC)
Thermocouple:
(±0.1 % of indication value or ±1°C,
whichever is greater) ±1 digit max.
Platinum resistance thermometer:
(±0.1 % of indication value or ±0.5°C,
whichever is greater) ±1 digit max.
Analog input: ±0.1 % FS ±1 digit max.
Output current: approx. 7 mA per contact.
ON:1 kΩ max., OFF: 100 kΩ min.
ON: residual voltage 1.5 V max.,
OFF: leakage current 0.1 mA max.
Relay output :SPST-NO
250VAC, 3A(resistive load)
Voltage output (for driving SSR):
12 VDC, 21 mA
Current output: 4 to 20 mADC, 0 to 20 mADC
Load: 600 Ω max.
Linear voltage output 0 to 10 VDC
Load: 1 kΩ min.
Electrical life of relay: 100,000 operations
(Long-life model: 1 million operations)
Voltage output (for driving SSR): 12 VDC, 21 mA
ON/OFF or 2-PID control
Relay outputs: 250 VAC, 3 A (resistive load),
Electrical life of relay:
100,000 operations
-10 to 55°C
(With no condensation or icing)
25 to 85%
-25 to 65°C
(With no condensation or icing)
Max. 2,000m
T2A, 250 VAC, time-lag,
low-breaking capacity
Approx. 150 g (main unit only)
Front panel: IP66
Rear case: IP20, Terminal section: IP00
Installation category II, pollution
degree 2 (as per IEC61010-1)
Non-volatile memory
(Number of write operations: 1,000,000
at an ambient temperature of 25°C)
4 to 20 mA DC, Load : 600 Ω max.
Auxiliary output
Auxiliary output ( Relay outputs)
( Relay outputs)
250 VAC 3A
Auxiliary output 2
(resistive load)
Input power supply
• 100-240V AC Type
• 24V AC/DC Type (no polarity)
Communications Control output 2 and Event inputs and
(RS-232C) and CT transfer output
transfer output
RS-232C
SD
+
11 11
11
Control output 2 ol output 2 p p p
RD
12VDC,21 mA DC,21 m
12 12 12
- EV1
SG
DO NOT
13 13
13
USE EV2
+ +
14 14 14 4-20 mADC
4-20 mADC
Transfer Transfer
CT1 (Load: 600 Ω max.)
(Load: 600 Ω max.)
output
output
15 15 15
- -
Conformance to EN/IEC Standards
is a
This is a class A product.
In residential areas it may cause radio
interference, in which case the user may
be required to take adequate measures
to reduce interference.
Conformance to Safety Standards
Reinforced insulation is
provided between input power
supply, relay outputs, and
between other terminals.
c-db
*6 Dead Band
0.0
of-r
at-2 Manual Reset Value
*6
at-1 50.0 (Unit: %)
hys
Hysteresis
*6
1.0 (Heating)
chys
Hysteresis
*6
(Cooling)
1.0
wt-b
*6 Wait Band
off
ol-h
*6
MV Upper Limit
105.0
ol-l
*6
MV Lower Limit
-5.0
orl
MV Change
*6
0.0 Rate Limit
sqrp
Extraction of Square
*6
Root Low-cut Point
0.0
stb
Standby Time
0.00
Adjustment level is for
entering set values and shift
values for control.
d.pid O
Press
Display PID
Selection Key for less
1
than 1 s.
For other information, refer to the
User's Manual (Cat. No. H169).
: Can be displayed
Set value
and changed
: Can be displayed
× : Display or shifting to
another level is not
possible.
Default setting : 0
Communications Advanced function
setting level setting level
×
× ×
× : Change to other levels not possible
" will light.)
