OWNER'S MANUAL
NEW TYPE CYCLONE
VACUUM CLEANER
This information contains important instructions for the safe use and
maintenance of the vacuum cleaner. Especially, please read all of the
information on page 3, 4, 5 for your safety. Please keep this manual in
an easily accessible place and refer to it anytime.
VK8914DCAQ
P/No.: MFL62076033
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VK8914DCAQ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG VK8914DCAQ

Summary of Contents for LG VK8914DCAQ

  • Page 1 This information contains important instructions for the safe use and maintenance of the vacuum cleaner. Especially, please read all of the information on page 3, 4, 5 for your safety. Please keep this manual in an easily accessible place and refer to it anytime. VK8914DCAQ www.lg.com P/No.: MFL62076033...

  • Page 2: Table Of Contents

    Table of contents Important safety instructions ................. 3~5 How to use ......................6~19 Assembling vacuum cleaner ........................ 6~7 Operating vacuum cleaner ........................8 Using carpet and floor nozzle / Hard floor nozzle ..................9 Using the accessory nozzles ........................10 Using the power punch nozzle ......................

  • Page 3: Important Safety Instructions

    Personal injury or product damage could result. In these • Keep children away and beware of obstructions cases, contact LG Electronics Service Agent to avoid when rewinding the cord to prevent personal injury hazard. The cord moves rapidly when rewinding.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS WARNING • When cleaning the exterior of the nozzle, always <Using Power punch nozzle, Warning> unplug the power and do not use volatile substance. • Please use the product for bedclothes, mattresses, It can cause electric shock and exterior damage. pillows, sofa fabrics.
  • Page 5 • Store the vacuum cleaner indoors. • If the power cord is damaged, it must be replaced by Put the vacuum cleaner away after use to prevent tripping an approved LG Electronics Service Agent to avoid a over it. hazard.

  • Page 6: How To Use

    How to use Assembling vacuum cleaner Hose Handle Spring latch Telescopic pipe ➊ Carpet and floor nozzle ➋ Telescopic pipe Push the nozzle into the telescopic pipe. • Push telescopic pipe firmly into hose handle. • Grasp the spring latch to expand. •...
  • Page 7 Click! Fitting pipe Flexible Hose Button Attachment Point ➌ Connecting the hose to the vacuum cleaner • Push the fitting pipe on the flexible hose into the attachment point on the vacuum cleaner. • To remove the flexible hose from the vacuum cleaner,press the button situated on the fitting pipe, then pull the fitting pipe out of the vacuum cleaner.

  • Page 8: Operating Vacuum Cleaner

    How to use Operating vacuum cleaner Indicator Plug Cord reel button Control button BEDDING ➊ How to operate ➋ Indicator and alarm sound ➌ Park mode ➍ Storage • Pull out the power cord to the • The indicator light of the •...

  • Page 9: Using Carpet And Floor Nozzle / Hard Floor Nozzle

    How to use Using carpet and floor nozzle / Hard floor nozzle Carpet Pedal Floor ➊ Carpet and floor nozzle ➋ Hard floor nozzle • Two position nozzle • Efficient cleaning of hard floors This is equipped with a pedal which allows you to (wood, linoleum, etc) alter its position according to the type of floor to be cleaned.

  • Page 10: Using The Accessory Nozzles

    How to use Using the accessory nozzles Upholstery nozzle Dusting brush Crevice tool ➌ Upholstery nozzle ➍ Dusting brush ➎ Crevice tool Upholstery nozzle is for Dusting brush is for vacuuming Crevice tool is for vacuuming picture frames, furniture frames, in those normally hard-to-reach vacuuming upholstery, mattresses, etc.

  • Page 11: Using The Power Punch Nozzle

    How to use Using the power punch nozzle Features How to use This nozzle picks up even dust inside through beating. Follow the directions below for proper use. The bottom part can be separated to be cleaned. Assembly Since the bottom does not stick to the surface, vacuuming is Connect the nozzle to the telescopic tube.
  • Page 12 This power punch nozzle is for effective cleaning of beds and blankets to remove mites and dust. Effective cleaning Bed & blanket Light blanket & sheet Bulky & heavy blanket When using on the bed When using on the floor Lay out the blanket and vacuum it on the bed It is easier to clean a light blanket or sheet by pushing the nozzle in the direction of the arrow.
  • Page 13 Follow the instruction below for through washing. (Do not soak the entire body of the vacuum nozzle in water, it may cause the vibrator to malfunction) Bottom plate Pushing button Bottom plate Punch bar Combination groove Combination Punch bar projection ➊...
  • Page 14 Projection ➊ Push a button for 5 seconds if ➋ When the dust is fully filled after there is a lot of dust in extra cleaning, take the bin and turn it dust tank. counterclockwise to disconnect. (Dust will be eliminated.) ➌...

  • Page 15: Emptying Dust Tank

    How to use Emptying dust tank Indicator on hose is flickering for 1 minute, it sounds “ding~ding” like a buzzer from vacuum body. In 30 seconds, suction power will decrease, it stops operating automatically. Tank separation lever Indicator Pull out Tank handle Dust tank cap The dust tank needs emptying when indicator light is on.

  • Page 16: Cleaning Dust Tank

    How to use Cleaning dust tank Tank separation lever Pull out Tank handle • Press tank separation button and pull out dust tank. NOTICE • Raise dust tank cap • Dry fully in shade so that moisture is entirely removed. If suction power decreases or Indicator on hose flickers after cleaning dust tank, clean air filter and motor safety filter.

  • Page 17: Cleaning Air Filter And Motor Safety Filter

    Air filter and motor safety filter are located at the up of vacuum cleaner If filters are damaged, do not use them. in the above figure. In this cases, contact LG Electronics • Push the vacuum cover button, open the body cover. Service Agent.

  • Page 18: How To Assemble Dust Separator

    How to use How to assemble dust separator CAUTION Assembling will be conducted in opposite order of separation. Use the vacuum after assembling the dust separator fully. Click Click Click • Insert the air filter and motor safety CAUTION filter. •...

  • Page 19: Cleaning Exhaust Filter

    How to use Cleaning exhaust filter Exhaust filter cover Exhaust filter Button Lever Exhaust filter cover Click • The exhaust filter is reusable. • To clean the exhaust filter, remove the exhaust filter cover on the body by pulling it out. •...

  • Page 20: What To Do If Your Vacuum Cleaner Does Not Work

    What to do if your vacuum cleaner does not work Check that the vacuum cleaner is plugged in correctly and that the electrical socket is working. What to do when suction performance decreases • Turn off the vacuum cleaner and unplug it. •...
  • Page 21 Note...
  • Page 22 Note...
  • Page 23 Note...
  • Page 24 Made in Korea...
