- Page 1 Communication interface for SMA inverters SMA WEBCONNECT DATA MODULE Installation Manual WebconnectDM-IA-IEN122510 | 98-0051210 | Version 1.0...
-
Page 3: Table Of Contents
Product Description ......12 Webconnect Data Module......12 Type Label . - Page 4 Packaging the Webconnect Data Module for Shipping..23 Disposing of the Webconnect Data Module ....23 Troubleshooting ....... . . 24 Technical Data .
-
Page 5: Information On This Document
SMA Solar Technology AG 1 Information on this Document Information on this Document Validity This document is valid for device type "SWDM-10" as of firmware version 1.00.00.R. Target Group This document is intended for skilled persons. Only skilled workers are allowed to perform the tasks set forth in this document (see Section 2.2 "Qualification of Skilled Persons", page 9). - Page 6 SMA Solar Technology AG Nomenclature Complete designation Designation in this document Electronic Solar Switch PV plant Plant SMA Speedwire Speedwire SMA Webconnect Data Module Webconnect Data Module SMA Webconnect function Webconnect function SMA inverter Inverter Abbreviations Abbreviation Description Explanation Alternating Current...
-
Page 7: Safety
2 Safety Safety 2.1 Intended Use The Webconnect Data Module is a Webconnect communication interface for inverters based on the SMA Speedwire technology. Speedwire is a cable-based type of communication based on the Ethernet standard and the communication protocol SMA Data2+. This enables inverter-optimised 100 Mbit data transmission between Speedwire devices in PV plants. - Page 8 PV plant with a Speedwire network in star topology (example) The Webconnect Data Module is provided as a retrofit kit or is pre-installed in the inverter. The Webconnect Data Module must only be installed in the following inverters as of firmware version 2.51:...
-
Page 9: Qualification Of Skilled Persons
SMA Solar Technology AG 2 Safety 2.2 Qualification of Skilled Persons The tasks described in this document are intended for skilled persons only. Skilled persons must have the following qualifications: • Training in the installation and commissioning of electrical devices and plants •... -
Page 10: Scope Of Delivery
Check the delivery for completeness and any visible external damage. Contact your specialist dealer if the delivery is incomplete or you find any damage. Figure 3: Components included in delivery: Webconnect Data Module pre-installed in the inverter Position Quantity Designation Installation manual... -
Page 11: Order Option: Webconnect Data Module As Retrofit Kit
Check the delivery for completeness and any visible external damage. Contact your specialist dealer if the delivery is incomplete or you find any damage. Figure 4: Components included in delivery: Webconnect Data Module as retrofit kit Position Quantity Designation Webconnect Data Module... -
Page 12: Product Description
• Set-up of a Speedwire network • Data exchange with the Internet portal Sunny Portal and Sunny Explorer via a router The Webconnect Data Module is provided as a retrofit kit or is pre-installed in the inverter. Figure 5: Product description: Webconnect Data Module... -
Page 13: Type Label
SMA Service Line. The type label must be permanently affixed to the Webconnect Data Module. The type label is located in the right-hand top corner on the front of the Webconnect Data Module. You can identify the module by the type label. You will find the following information on the type label: •... -
Page 14: Connection
SMA Solar Technology AG Connection 5.1 Device Overview Figure 7: Overview of the connection area Position Designation Display with screw Cable route to network sockets Opening in the inverter enclosure with filler-plug Mounting position of the Webconnect Data Module in the inverter WebconnectDM-IA-IEN122510 Installation Manual... -
Page 15: Cabling Of The Local Speedwire Network
Cable type: 100BaseTx, CAT5 with shielding S-UTP, F-UTP or higher UV-resistant if used outdoors Type of plug: RJ45 SMA Solar Technology AG recommends the following cable types: • For outdoor use: SMA COMCAB-OUTxxx • For indoor use: SMA COMCAB-INxxx available in the following lengths: xxx=100 m, 200 m, 500 m and 1,000 m 5.3 Installing the Webconnect Data Module in the Inverter... - Page 16 5. Attach the cable gland to the enclosure opening with the counter nut. 6. Insert the Webconnect Data Module and slide the ribbon cable upwards behind the display. The key on the top edge of the Webconnect Data Module must fit into the hole in the plastic retainer in the inverter.
-
Page 17: Connecting The Webconnect Data Module
5 Connection 9. Plug the ribbon cable plug onto the centre connector strip. 5.4 Connecting the Webconnect Data Module Requirements: The network cables must be pre-assembled according to the plant topology and the cable requirements (see 5.2 "Cabling of the Local Speedwire Network", page 15). - Page 18 5 Connection SMA Solar Technology AG 5. Remove one of the filler-plugs from the seal for each network cable. 6. Insert the network cables into the seal. Route the network cable plugs into the inverter to the network sockets. 7. Push the seal into the cable gland. Make sure that any unused cable openings are sealed with filler-plugs.
-
Page 19: Commissioning
6 Commissioning Commissioning 6.1 Commissioning the Plant Requirements: The Webconnect Data Module must be installed in the inverter (see Section 5.3 "Installing the Webconnect Data Module in the Inverter", page 15). The Webconnect Data Module must be connected (see 5.4 "Connecting the Webconnect Data Module", page 17). -
Page 20: Connection To Sunny Explorer
6 Commissioning SMA Solar Technology AG 6.2.2 Connection to Sunny Explorer Requirements: The plant must be commissioned (see Section 6.1 "Commissioning the Plant", page 19). 1. Connect the computer to the plant router with a network cable. 2. Start Sunny Explorer and create plant (see Sunny Explorer user manual). -
Page 21: Registering The Plant In Sunny Portal
Sunny WebBox, you will still need to create a separate plant with Webconnect Data Module. It is not possible to combine the Webconnect Data Module and other communication devices within one plant in Sunny Portal. Sunny Portal treats the existing plant and the new plant with Webconnect Data Module as independent plants. -
Page 22: Decommissioning
7. Unscrew the counter nut of the cable gland. 8. Pull the cable gland and network cables out of the inverter. 9. Release the screw of the Webconnect Data Module and remove it. 10. Flip down the display and fasten the display screw hand-tight. -
Page 23: Packaging The Webconnect Data Module For Shipping
7.2 Packaging the Webconnect Data Module for Shipping • Pack the Webconnect Data Module using either the original packaging or other packaging suitable for the weight and size of the Webconnect Data Module (see Section ) 9 "Technical Data", page 25. 7.3 Disposing of the Webconnect Data Module •... -
Page 24: Troubleshooting
Corrective measures: • Adjust firewall or IP filter settings (see firewall or router manual). The Webconnect Data Module does not have a valid IP address. Corrective measures: • Check whether DHCP is activated in the router or assign a manual IP address to the Webconnect Data Module. -
Page 25: Technical Data
SMA Solar Technology AG 9 Technical Data Technical Data General Data Mounting location in the inverter Voltage supply via inverter Mechanical Data Width x height x depth 73 mm x 88 mm x 34 mm Communication Communication interface Webconnect/Speedwire Maximum cable length... -
Page 26: Contact
SMA Solar Technology AG 10 Contact If you have technical problems concerning our products, contact the SMA Service Line. We need the following data in order to provide you with the necessary assistance: • Type, serial number and firmware version of the inverter •... - Page 27 Legal Restrictions The information contained in this document is the property of SMA Solar Technology AG. Publishing its content, either partially or in full, requires the written permission of SMA Solar Technology AG. Any internal company copying of the document for the purposes of evaluating the product or its correct implementation is allowed and does not require permission.
