Summary of Contents for SMA SUNNY BOY STORAGE 3.7-10
- Page 1 Service Manual for Installers Functional test of the CAN interface SUNNY BOY STORAGE 3.7-10 / 5.0-10 / 6.0-10 ENGLISH SBSx.x-10-CAN-SG-en-10 | Version 1.0...
-
Page 2: Table Of Contents
Table of Contents SMA Solar Technology AG Table of Contents Information on this Document..................... Validity ................................Target Group ..............................Content and Structure of this Document......................IMPORTANT SAFETY INSTRUCTIONS..................Background Information ......................CAN bus functional test ....................... Assembling the test cable.......................... -
Page 3: Information On This Document
The tasks described in this document must only be performed by qualified persons. Qualified persons must have the following skills: • Knowledge of how to safely disconnect SMA inverters • Knowledge of how batteries work and are operated • Training in how to deal with the dangers and risks associated with installing, repairing and using electrical devices, batteries and installations •... -
Page 4: Important Safety Instructions
2 IMPORTANT SAFETY INSTRUCTIONS SMA Solar Technology AG 2 IMPORTANT SAFETY INSTRUCTIONS Keep the manual for future reference. This section contains safety information that must be observed at all times when working. DANGER Danger to life due to electric shock when live components or cables of the inverter are touched High voltages are present in the conductive components or cables of the inverter. - Page 5 2 IMPORTANT SAFETY INSTRUCTIONS SMA Solar Technology AG WARNING Danger to life due to fire or explosion when batteries are fully discharged A fire may occur due to incorrect charging of fully discharged batteries. This can result in death or serious injury.
- Page 6 2 IMPORTANT SAFETY INSTRUCTIONS SMA Solar Technology AG NOTICE Damage to the enclosure seal in subfreezing conditions If you open the product or disconnect the Power Unit and Connection Unit when temperatures are below freezing, the enclosure seals can be damaged. Moisture can penetrate the product and damage it.
-
Page 7: Background Information
3 Background Information SMA Solar Technology AG 3 Background Information Sometimes, during commissioning of the Sunny Boy Storage, the CAN interface of the Sunny Boy Storage fails to detect the connected batteries or the backup box (depending on the system configuration). -
Page 8: Can Bus Functional Test
4 CAN bus functional test Assembling the test cable SMA recommends creating a test cable from new components, as described below. For one-time use, the plugs already present at the inverter and the existing communication cable can be used. Required materials ☐... - Page 9 You can find information on the firmware version at the bottom left in the status bar of the user interface of the inverter. You can find the current firmware versions at https://www.sma.de/service/downloads.html. Please read the accompanying Readme files before updating.
- Page 10 4 CAN bus functional test SMA Solar Technology AG 6. Remove the cover of the inverter and remove the test cable from battery interfaces BAT1 and BAT2. 7. Check battery interfaces BAT3 and BAT4: • Now use the test cable to connect BAT3 and BAT4 on the battery interface module.
-
Page 11: Contact
5 Contact SMA Solar Technology AG 5 Contact https://go.sma.de/service Service Manual for Installers SBSx.x-10-CAN-SG-en-10... - Page 12 www.SMA-Solar.com...
