AirMaid 200 W Operating Instructions Manual

Ozone generator
Hide thumbs

Advertisement

Quick Links

Download this manual
200W
Operating instructions for
AirMaid® 200 W ozone generator
A
M
®
I R
A I D
O Z O N E C L E A N I N G S Y S T E M
I
A
T
N N O V A T I V E
I R
R E A T M E N T
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 200 W and is the answer not in the manual?

Questions and answers

Related Manuals for AirMaid 200 W

Summary of Contents for AirMaid 200 W

  • Page 1 200W Operating instructions for AirMaid® 200 W ozone generator ® A I D O Z O N E C L E A N I N G S Y S T E M N N O V A T I V E...
  • Page 3 This manual describes a typical installation of an AirMaid® 200 W ozone generator. The installation can vary depending on local rules and regulations for building materials, ventilation systems or building/ room design.

  • Page 4: Table Of Contents

    PRODUCT WARRANTY LIMITED WARRANTY FOR INTERZON’S EQUIPMENT This guarantee is subject to the following conditions. A new product is guaranteed to be free from damage and/or workmanship fault for a period of 3 years from the original purchase date. The ceramic elements effect will decrease eventually and you will have to replace them. This also means that ceramic elements do not fall within the scope of the 3-year warranty.

  • Page 5: Inspect The Product

    AirMaid® ozone generator 200 W (optional) Motion sensor (optional) 2. SYSTEM OVERVIEW Below are some examples of where you can use AirMaid® 200 W ozone generator. Moreover, AirMaid® 200 W can be used in the following applications: Offices Environmental stations Kitchens Basements...

  • Page 6: Installation Guide

    3. INSTALLATIONS GUIDE It is important to remember that the product’s ambient temperature must not exceed 40 °C and the air from which the generator draws air must be clean in order to minimise service intervals. The generator should be placed high and close an air intake, if available. The generator should be placed on a flat surface, preferably 2 metres above the floor.

  • Page 7: System Testing

    5. SYSTEM TESTING 1. Turn on the generator by setting the generator switch to ”I” position. The red light on the safety switch turns on, you can hear the fan. Make sure there is an arc over the ceramic elements. a.

  • Page 8: Service And Maintenance

    6. SERVICE AND MAINTENANCE The ceramic elements should be cleaned if necessary. Air filters should be replaced at least once a year. After the installation, it is recommended to inspect the filters after three months. Always wear protective gloves and goggles. Cleaning the ceramic elements 1.

  • Page 9: Technical Specification

    7. TECHNICAL SPECIFICATION AirMaid Ozone capacity Output Voltage Weight Fuse 200 W 0-200 mg/h 30 watt 230V/50-60 Hz 2 kg 315mA Material: Stainless steel AISI 304 Temperature range: From -25 to +40°C Dimensions WxLxH: 274x97x118 mm Fan capacity: 70 m3/h (free blowing)
