A flash that was not scanned and found when the Transmitter Pro was switched ON cannot be added with the
Refresh feature.
If a flash is added, select SETUP and SCAN in the setup menu or switch the Transmitter Pro OFF and ON
again.
The refresh can take several seconds, depending on how many flash units are found and operated by the
Transmitter Pro.
Note:
To update the display information after flash power changes have been applied directly at the flash unit, please
EN
press the REFRESH button. Changes are not automatically updated, to avoid interferences with the flash
triggering.
ROTATION RING
Turn the rotation ring to select various functions (up & down) and change power levels of the EL flashes.
SET / CONFIRMATION BUTTON (ROTATION RING)
Press to confirm a modification made in the Setup menu.
Press to switch on the display illumination.
Press to return to normal operation when the Transmitter Pro has switched to Standby mode.
Press 2s to lock all functions and settings. Press again to unlock.
The locking feature blocks the function of the dial and other buttons to prevent unwanted change of settings
while carrying the Transmitter Pro.

SETUP MENU

SCAN
When the Transmitter Pro is switched ON, it will automatically search for Elinchrom flash units with built-in or
plug-in EL-Skyport Transceiver modules.
The Scan feature is also available in the Setup Menu. A re-scan is required, when new flash units have been
added to the lighting setup.
To find EL flash units,
• all EL flash units must be switched on and the Skyport Receiver must be activated.
• all flashes must have a built-in or plug-in Skyport Transceiver RX module.
• the Transmitter Pro and the EL flash unit must have the same frequency channel settings.
FREQUENCY CHANNELS
Up to 20 Skyport frequency channels can be selected.
Note:
• Only the latest Elinchrom flash units (ELC and ELB) will support up to 20 frequency channels.
• All "RX" flash units will support up to 8 channels and some older Elinchrom flash units support
up to 4 channels.
14
