Assembly
Assembly Procedure
Step 1: Mounting the seat to the seat base.
• Use the four 5/16" x ³/4" UNC bolts to fasten the seat to
the seat base.
• Remove armrest screws from the seat, position left
and right side armrest, fasten and tighten.
Step 2: Mount the steering joystick to the steering
shaft.
• Select the steering joystick.
• Remove the two bolts in the top of the steering shaft.
• Slide the joystick into the slot on the top of the
steering shaft, already installed in the steering
column directly in front of the foot pedal controls,
insert the ³/8" bolt into the bottom bolt hole, select
a comfortable operating position, joystick forward
for extra operating room or back for less, once
determined insert the other ³/8" bolt into the upper
hole and tighten both bolts securely.
Step 3: Attaching the left-hand trailer arm to machine
body.
• Locate the trailer arm support axle 25mm in diameter
(1") which extends out on the left side of the machine,
remove the circlip from the support axle. Oil machined
portion. Slide the left hand side trailer arm, onto the
axle, replace the circlip, ensuring the circlip is located
in the groove correctly.
TRU-TURF RS48-11C USA Roll 'n' Spike Golf Greens Roller Manual
Step 4: Attaching dampener strut and right hand
trailer arm.
• Locate the trailer arm support axle 25mm in diameter
(1") which extends out on the right side of the
machine, remove the circlip from the axle. Hold the
right side trailer arm in the vertical position and slide it
part way onto the axle. Locate dampener strut, remove
packing from the unattached end.
• Apply thread lock "Loctite" to the M10 bolt attached to
the dampener strut. Screw the M10 bolt into the strut
support on the trailer arm.
• If necessary use a soft headed hammer and tap the
trailer arm onto the axle until the circlip groove is
revealed, fi t the circlip, ensuring it is located in the
groove correctly.
Step 5: Attaching draw bar to trailer arms.
• Locate the draw bar assembly.
• Gather the ends of the right and left trailer arms.
• Place the draw bar assembly between the trailer arms
and align the holes, ensure the bend is upwards.
• Place one 21/2" x 3/8" bolt through each hole, fi t 3/8"
Nyloc nut to each bolt and tighten securely.
• Test to ensure the trailer catch is correctly locking the
trailer arms in the down position and the catch locking
pin fi ts correctly when transporting the roller, for
safety.
Step 6: Attaching wheels to trailer arms.
• Locate the two wheels for the left and right side trailer
arms.
