Tru-Turf RS48-11C User Manual page 30

Parts List
Part No.
R5239 Catch; Steel; Transmission/Seat
R5240 Tube; Spiker Shaft; Locking Collar
R5241 Black; Mini Pinch weld
R6001 Catch; Trailer
R6004 Smoothing Head; Front
R6005 Smoothing Head; Rear
R6006 Lever; Emergency & Park Brake
R6007 Plate; Brake
R6009 Shaft; Steering
R6011 Spring; Compression Brake
R6012 Arm; Steering
R6013 Stop; Rubber, Smoothing Head
R6015 Plate, Footrest, Checker
R6017 Pin; Safety, Drawbar
R6019 Drawbar
R6022 Plate; Spiker Lever
R6023 Plate; Emergency & Park Brake
R6024 Plate; Move Right
R6025 Plate; Move Left
R6039 Wheel / Tire 4 Stud
R6040 Sticker; Sloping Greens
R6041 Sticker; Danger, Cover Removal
R6048 Scraper; Rod
R6056 Joystick
R6057 Sticker; Tru-Turf
R6058 Sticker; Tire Pressure
R6059 Sticker; PGA
R8000 RS48-11C Body
R8001 Foot Pedals Tapered
R8002 Trailer Arm LH
R8003 Smoothing Head Pivot Frame
R8004 Smoothing Head Pivot Bush Holder
R8005 Foot Pedal Arm Tapered
R8006 Bush Bronze Smoothing Head Pivot 20x26x30
R8007 RS48-11C Transmission Cover
R8008 Trailer Arm RH
R8009 Bush Bronze Trailer Arms 25x32x30
R8010 Naming Plate RS48-11C
R8013 Housing; Filter; Tank; Transmission Oil
R8018 Bearing
R8024 Seat; Michigan
R8025 Armrest RH
TRU-TURF RS48-11C USA Roll 'n' Spike Golf Greens Roller Manual
Description Page
13, 16
19
13
23, 24
20, 21
20, 21
14,15, 23
23
23
23
14, 23
13, 15, 20
13, 15
23
13, 23, 24
26
26
26
26
24
26
26
21
13, 23
26
26
26
14
14
24
20
20
14, 17
20
13
24
24
26
15
23
13, 22
13, 22
Part No. Description
R8026 Armrest LH
R8047 5/16" Washer
R8055 Nyloc Nut 3/8"
R8060 Nut Nyloc, 1/2 " UNC
R8210 Ball Fitting; Large Flange
R8218 Washer Nylon
R8220 Tube, Steering
R8223 Tube Tie Rod
R8256 Nyloc Nut M8
R8274 Seat; Frame
R8275 Plate; Seat Base; Michigan Seat
R8285 Rod End 1/2"
R8286 Rod, Steering
R8287 Rod End Studded
R8288 Rod 2" x 570mm; Connects L & R Smoothing Heads
R8289
Rod Unit; Connecting Smoothing Heads, complete
R8290 Rod; Connects Steering Arm to Smoothing Head
R8299 RS48-11C Slicer Assembly
R9001 Engine Honda 6.5HP; with Flywheel & Lighting Coil
R9002 Sprocket; 27 tooth; Duplex; Drive Roller; Eaton 11 Trans. ANSI 14, 19
R9003 Sprocket; 11 Tooth; Duplex; ANSI
R9004 Chain, Duplex; Eaton 11 Transmission; ANSI
R9005 Joiner; Chain; Duplex Eaton 11 Transmission; ANSI
R9007 Sprocket Kit; Simplex; ANSI
R9017 Steering Arm 1/2" bolt
R9028 Spacer Stainless Steel Yoke
R9029 Seal; Hub Inner
R9030 Bearing; Hub Inner
R9030 Bearing; Hub Outer
R9032 Washer; Hub
R9033 Nut; Stub
R9034 Pin; Cotter, Stub
R9035 Cap; Hub
R9036 Nut; Wheel, Hub
R9037 Hub; Wheel Complete
Options
E7045 Light 2 Off LED
E7067 Switch; Light
R8270 Harness; Wire
R8029 Brush, Nylon 1000mm x 100mm
R8292 LED Light Kit if fi tted with R8275 Seat Base Plate
Page
13, 22
17
18
14, 17, 23
17
17
20, 21, 23
21
17
13, 14, 15
13, 22
20, 21, 23
20, 21, 23
20, 21
21
21
20
14
22
18
18
18
18
17
24
24
24
24
24
24
24
24
24
25
25
25
25
25
28
