Parts List

Part No. Description
EL489 Tube; Spacer; Steering Head
R5009 Grip; Hand; Joystick
R5012 Pad; Rubber; Foot Pedal
R5013 Lever; Spiker Handle
R5014 Grip; Lever; Spiker Handle
R5016 Rubber; Cover; Transmission & Seat
R5025B Plug, Square
R5031 Coupling; Rubber
R5033 Fan
R5039A Bush; Taper Lock
R5046 Rod Unit; Connecting Arm; Foot Pedal to Yoke
R5049 Spring; Steering Return
R5054 Arm; Spiker Engaging
R5055 Bearing; 6201; Arm; Spiker Engaging
R5056 Frame; "H" Spiker
R5057 Arm; Bearing Carrier; Spiker Frame
R5058 Bearing; B4
R5059 Spring; Return; Spiker Frame
R5060 Housing; P204; for B4
R5061 Strap; Mud Flap
R5062 Shaft; Hexagon; Spiker
R5064 Spacer; Set; Spiker Shaft
R5065 Spring; Spiker Spacer; fi ts on Hex Shaft
R5066 Roller; Drive
R5067 Housing; F205; 4 hole; for R5070 Bearing
R5068 Housing; LFL5J; 2 hole for R5070 Bearing
R5069 Bearing; 6006; Fits R5057
R5070 Bearing; B5
R5071 Mud Flap
R5073 Rod Unit; Steering Arm to Smoothing Head
R5075 Bush; Nylon; Black
R5077 Housing; LFL6J; for R5078 B6 Bearings
R5078 Bearing; B6
R5085 Shim; Honda; 1.0 mm Thick
R5087 Key, Woodruff 8x30
R5089 Key; Woodruff 3/16"
R5094 Spring; Arm; Chain Tensioner
R5095 Washer; Capped
R5099 Bush; Bronze; for Chain Tensioner Arms
R5108 Ball Fitting; Small Flange
R5112 Circlip; External 25mm
R5113 Washer, Flat, 24x44x2 mm
27
Page Part No.
21 R5118A Rod End
13, 23 R5129 Meter; Hour/Tach
14 R5131 Bracket; Transmission; Eaton 11
14, 15 R5132 Arm; Chain Tensioner
14, 15, 19, 23 R5133 Transmission; Eaton 11
13, 16, 22 R5139 Coupling; Transmission; Eaton 11 Honda 6.5hp
20 R5140 Coupling; Engine; Honda 6.5hp
17, 22 R5142 Cushion; Rubber; for Engine Base Plate
17 R5143 Tank; Stainless Steel; Transmission Oil
19 R5144 Breather; Tank; Transmission Oil
17 R5145 Plug; Drain; Tank; Transmission Oil
21, 23, 24 R5147 Cartridge; Filter; Tank; Transmission Oil
19 R5148 Gauge; Sight; Tank; Transmission Oil
19 R5149 Plate; Mounting; Engine
19 R5152 Pipe; Oil
19 R5153 Pipe; Oil
19 R5154 Pipe; Oil
19 R5156 Key; Woodruff ; 1/8" x 5/8"
19 R5159 Rubber Strip; Rest; Trailer
14 R5164 Key; Woodruff ; 4 x 6.5mm
19 R5171 Yoke; Eaton 11 Transmission
19 R5173 Strut; connects to R5171 Yoke
19 R5178 Pipe; Oil
14, 19 R5184 Rod; Connects Transmission Yoke – Foot Pedal Arm
21 R5189 Spiker Blades, 8 point
19 R5195 Key Honda 32.5 x 5 x 5mm
19 R5197 Pad; Rubber Oil Tank
19, 21 R5208 Bolt, 3/8" x 1" NF
14 R5209 Spring Washer 3/8"
20 R5210 Kit; Strut; 32mm dia. Body complete
14 R5211 CSK Screw 3/8" x 1"
19 R5226 Oil; Transmission; 6Lt Containers
19 R5227 Fitting; 90 deg Elbow; M-10 ORB to M-8 JIC
22 R5228 Fitting; Straight M-12 BSPP-ORR to M-8 JIC with Dowty Seal 16
19 R5229 Fitting; 90 deg Elbow M-12 BSPP-ORR to M-8 JIC with Dowty Seal 16
17 R5230 Fitting; Straight M-10 ORB to M-8 JIC (S90-1214); Transmission 15
18 R5231 Fitting; Straight M 1/2" NPT to M-8 JIC (A-G-0812)
18 R5232 Fitting; 90 deg Elbow M-8 JIC to M 1/2" NPT (A-G-90-0812)
18 R5233 Fitting; 90 deg Elbow M-6 ORB to M-8 JIC (G-NP-90-1209) 15, 16
17 R5234 Fitting; 90 deg Elbow F-8 JIC SWIVEL to M-8 JIC (G-J-90-1212)
14 R5236 Plug; Plastic 1"x1"
14 R5238 Plug; Plastic 1 1/4" x 1 1/4"; Trailer
Description
TRU-TURF RS48-11C USA Roll 'n' Spike Golf Greens Roller Manual
Page
17
15
17, 18
15, 18
17, 18
17
17, 22
14, 22
15
15
15
15
15
22
16
16
16
14, 17, 18, 23
14
19
17
17
16
17
19
22
15
21
21
24
21
25
16
15
15
15
19
19, 20
