Siemens Energy & Automation, Inc.
Bellefontaine, OH 43311 U.S.A.

Installation Instructions

SAFETY INSTRUCTIONS

NOTE: These instructions outline the recommended in-
stallation procedure. The term circuit breaker used in
these instructions, also includes molded case switches
and motor circuit interrupters.
1. Turn power off supplying device before installing kit.
A complete installation requires two plug-in adapter as-
semblies. Each assembly consists of a mounting block,
tulip connectors and attachment hardware. The complete
assembly is attached to an optional switchboard mount-
ing plate (see table) or to other mounting means to suit
customer requirements.
NOTE: Type CJD6, SCJD6, CLD6, and SCLD6 Current
Limiting Circuit Breakers require use of a special end shield
assembly for the load side terminals. These shields must
be ordered using Catalog Number CLTCJL2 for 2-Pole or
CLTCJL3 for 3-Pole.
MOUNTING PREPARATION: (Fig. 1 & 2)
2. If the switchboard plate (PL5796 or PL5697) is to be
CIRCUIT BREAKER
TYPE
JXD2(-A), JXD6(-A), JXD6(-A)ETI, HJXD6(-A),
HHJXD6, SJD6(-A), SHJD6(-A), JFC, JFF
LXD6(-A), LXD6(-A)ETI, HLXD6(-A),
HHLXD6(-A), SLD6(-A), SHLD6(-A), LFC, LFF
CJD6(-A), CJD6(-A)ETI,
SCJD6(-A), JDFP(-A)
CLD6(-A), CLD6(-A)ETI,
SCLD6(-A), LDFP(-A)
used, provide mounting holes as shown in Fig. 1.
Hazardous Voltage.
Will cause death or severe
injury.
Turn power off supplying
device before installing.
PLUG-IN
NO. OF
ADAPTER
POLES
CAT. NO.
2
PC5777
3
PC5778
2
PC5660
3
PC5661
2
PC5777
3
PC5778
2
PC5660
3
PC5661
Item: Cat. No. PC5777, PC5778, PC5660, and
PC5661 Plug in Adapters
For Use With: SIEMENS
Frame Circuit Breakers, Molded Case Switches,
& Motor Circuit Interrupters. Types listed below.
Page 1 of 3
Pc. No. 61423A02
.375 [9.53] Dia. (4 Holes)
Mounting Holes
For Plug-In Adapters
6.00
[152.4]
1.88
2.25
[47.7]
[57.2]
.50
[12.7]
1.75
2.50
.344 x .75
[44.5]
[63.5]
[8.73 x 19.0]
4 Slots
Mounting Holes
For Switchboard
Mounting Pan
Drilling Switchboard
Mounting Plate
Figure 1
BREAKER TYPE A
CJD6(-A), CLD6(-A),
CJD6(-A)ETI,
CLD6(-A)ETI
All Other Types
SWITCH-
END
BOARD
SHIELD
MTG. PLATE
ASSEMBLY
CAT. NO.
PL5796
CLTCJL2
CLTCJL3
PL5797
CLTCJL2
CLTCJL3
®
JD, LD, JF, & LF
2.50
2.50
[63.5]
[63.5]
1.75
(1)
[44.5]
[44.5]
1.125
[28.58]
1.75
1.25
[31.8]
1.25
[31.8]
Locations
of Terminal Studs
Drilling and Cutouts
for Adapter Block
Figure 2
Dimensions
Inches
[Millimeters]
B
C
D
13.11 12.11 9.86 15.61
[333.0] [307.6] [250.4] [396.5]
6.25
5.25
3.00
8.75
[158.8] [133.4] [76.2]
[222.3]
Breaker
Outline
1.125
[28.58]
Typ.
.375[9.53] Dia.
(4 Holes)
Mounting Holes
For Plug-In
Adapters
1.18
[29.9]
R Typ.
MTG. PLATE
CAT. NO.
PL5797
PL5796
