DESi Utopic 2 User Manual

Wireless motorized cylinder with remote controller
Hide thumbs Also See for Utopic 2:

Advertisement

Quick Links

Download this manual See also: User Manual
Wireless Motorized Cylinder
With Remote Controller
USER
MANUAL
URC 60

Advertisement

loading
Need help?

Need help?

Do you have a question about the Utopic 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DESi Utopic 2

Summary of Contents for DESi Utopic 2

  • Page 1 Wireless Motorized Cylinder With Remote Controller USER MANUAL URC 60...
  • Page 2 We would like to thank you for choosing this patented product. We hope you to enjoy it. DES Alarm and Secur ty System Inc. 1. GENERAL INFORMATIONS and WARNINGS - We recommend you to put the keys to an accessible place (like car, bag etc.) in an emergancy condition.
  • Page 3 5x 1,5 V AA size Alkaline or Lithium batteries. Remote Access Module Device is suitable to use with rechargable batteries. According to tests done in DESi labratories, battery life of the 1.2. BOX CONTENT (may vary according to model number) device is measured as follows:...
  • Page 4 2. PARTS OF REMOTE CONTROLLED MOTORIZED CYLINDER and INSTALLATION Handle Handle Screw Cylinder Metal Extending Parts (used if needed) The hole Hex Screw for hex key DEMOUNTING OF MOTOR AND CYLINDER - Open “handle screw” and remove the handle by pulling. - Remove the batteries.
  • Page 5 EXTENDING INSIDE PART OF THE CYLINDER (if needed) 26 10 If the door thickness is not suitable to the cylinder of the device, inside part of the cylinder may be extended up to 6 mm by 2 mm steps. To extend the cylinder’s inside part, follow the instructions below: - Open “handle screw”...
  • Page 6 2.1. INSTALLATION OF MOTORIZED CYLINDER 2.1.1. Installing The Device Without Plastic Cover (Recommended for ordinary people) This is the easiest installation. It is suitable for all kind of doors. 1.STEP 2. STEP That’s Remove Install existing motorized cylinder. cylinder and tighten the screw Old Cylinder...
  • Page 7 2.1.2. Installing The Device With Plastic Cover (For professional installers only) If the cover of the door is not a part of cylinder defender (if it is used just to cover the disturbancies around the cylinder hole) follow the instructions below to install the device: 1.STEP 2.
  • Page 8 This installation is recommended for porfessional installer only, due to needed technical knowladge about door and lock. 1.STEP 2.STEP 3.STEP Remove Remove the cover Adjust the length the old of the door, of two screws cylinder. metal out of holder of the box.
  • Page 9 Before using your motorized cylinder, Direction of locking/unlocking (p.10) and Number of turns (p.10) should be adjusted. 3. ADMINISTRATIVE ACTIONS / SETTINGS 3.1. ENROLLING NEW REMOTE CONTROLLER - Press 3rd button of master rc till “0" flashes on the display. - Press 2nd button of master rc three times.
  • Page 10 3.3. ADJUSTING THE DIRECTION OF LOCKING / UNLOCKING - Press 3rd button of master rc till “0" flashes on the display. - Press 1st button of master rc one time. “1" will be flashing on the display. - Press 3rd button of master rc. Either “r” or “L” will be shown on the display. - For counter-clockwise locking, choose “L”...
  • Page 11 3.5. REPORTING NUMBER OF REMOTE CONTROLLERS IN THE MEMORY - Press 3rd button of master rc till “0" flashes on the display. - Press 2nd button of master rc one time. “8" will be flashing on the display. - Press 3rd button of master rc. “C” will be shown on the display. - Press 1st button of master rc.
  • Page 12 3.7. NIGHT MODE AVAILABILITY (For detailed information about Night Mode see 4.2.a) - Press 3rd button of master rc till “0" flashes on the display. - Press 1st button of master rc four times. “4" will be flashing on the display. - Press 3rd button of master rc.

  • Page 13: Locking The Door

    4. USAGE 4.1. UNLOCKING AND OPENING THE DOOR If you press the 2nd button of rc, system automatically unlocks and opens the door. You can unlock/open the door by using the knob or the key as well. If semi-automatic working is enabled (see 3.8), when you rotate the knob or the key to unlocking way, it will sense the movement and continue automatically.

  • Page 14: Maintenance

    To shift the motorized cylinder to night mode: - Close the door and turn the knob through locking way. The motorized cylinder will lock the door one turn. - Turn the knob again through locking way. It will lock all the turns. In this way, the motorized cylinder will shift to Night Mode.
  • Page 15 5.2. REPLACING REMOTE CONTROLLER’S BATTERY If the controlling range of rc is getting shorter, battery of rc need to be changed. To change the battery, untighten battery screws and open the cover carefully. Change the battery by watching polarities, close the cover and tighten the screws. It is recommended to change the battery by a professional technician.
  • Page 16 Desi Alarm and Security Systems Inc. MANUFACTURER Topkapı Maltepe Cd. Anadolu Sk. N:1 Bayrampaşa, İstanbul / TURKEY T. +90212 501 72 72 F. +90212 576 64 77...
