- Page 1 Wireless Motorized Cylinder USER MANUAL...
- Page 2 GENERAL INFORMATIONS and WARNINGS - We recommend you to put the keys to an accessible place (like car, bag etc.) in an emergancy condition. - If there is any problem with door or locking mechanism, first of all, those problems need to be solved.
-
Page 3: Features Of The Device
1. FEATURES OF THE DEVICE Controlling Options and Compatible Accessories Structure Wireless Fingerprint Readers Engraved Aluminum, ABS Plastic, Zamak Wireless Keypad Wireless Auto-Locking Module Cylinder Length Wireless Home Automation Interface (outside) 31 mm x 37 mm (inside) Remote Controllers Inside part can extensile up to 43 mm Remote Access Module (Different cylinder lengths are available) Batteries and Battery Life... - Page 4 2. PARTS OF DEVICE and INSTALLATION Handle Handle Screw Cylinder Metal Extending Parts (used if needed) The hole Hex Screw for hex key DEMOUNTING OF MOTOR AND CYLINDER - Open “handle screw” and remove the handle by pulling. - Remove the batteries. - Rotate “hex screw”...
- Page 5 EXTENDING INSIDE PART OF THE CYLINDER (if needed) 26 10 If the door thickness is not suitable to the cylinder of the device, inside part of the cylinder may be extended up to 6 mm by 2 mm steps. To extend the cylinder’s inside part, follow the instructions below: - Open “handle screw”...
-
Page 6: Mobile Application
MOBILE APPLICATION In this section, you can find details about usage of Mobile Application If there is no controller with your motorized cylinder and if you enroll your smart phone as first controller, it will be master controller of your motorized cylinder. Before you use your motorized cylinder, you should adjust it properly according to the lock which motorized cylinder will work together. - Page 7 3.1. ENROLLING A MOBILE PHONE AS MASTER CONTROLLER - Search “Desi Utopic” on stores. Download, install and run the application. - Choose desired language and define a password. - Touch “+” on the top left corner to see the list of Utopic motorized cylinders around.
-
Page 8: Application Settings
3.2. APPLICATION SETTINGS If you touch to menu button on the top right corner when it is not connected to motorized cylinder, you will reach to settings menu of application. Related menu items are as follows: PASSWORD: You can disable, enable or change the password of application. Menu LANGUAGES: You can change language of the application. -
Page 9: Device Info Tab
3.3. MOTORIZED CYLINDER SETTINGS / ADMINISTRATION MENU If you touch to menu button on the top right corner when the application is connected to motorized cylinder as master controller, you will reach to settings menu of connected motorized cylinder. You can change settings of your motorized cylinder and perform administrative activities via this menu. - Page 10 3.3.2. KNOB SETTINGS TAB Menu In this tab, there are following menu items: Button BUZZER OF KNOB: You can enable / disable activation sounds coming from motorized cylinder. NIGHT MODE AVAILABILITY: Night mode is a security option which temporarily disables all controllers of motorized cylinder. In this way, the door can only be opened by knob or the key.
- Page 11 You can use the slider to adjust latch retraction period in 4 different way: From left to right; short (around half second), 3 seconds, 6 second and 9 seconds. Latch Retraction Period adjustment is not available for Utopic 2.
-
Page 12: Users Tab
EDIT / DELETE ENROLLED CONTROLLERS: If you touch to Controllers title, you can see enrolled controllers of motorized cylinder. If you touch any users, you can reach dedicated page to edit name or delete the controller. Edit / Delete Enrolled Controller is not available for Utopic 2. Menu... - Page 13 ENROLL NEW REMOTE CONTROLLER: Your motorized cylinder may learn up to 40 di erent controllers. To shift your motorized cylinder to enrolling new controller mode, touch to “Green Plus” button. In this way, motorized cylinder will shift to enrolling new controller mode with a long warning tone. After that tone, you need to send locking or unlocking signal via the new controller that you want to enroll to the motorized cylinder in following ways: - For fingerprint reader, wake it up and touch to lock button.
-
Page 14: Report Tab
In this tab, you can see which user unlocked or locked the device. For Button mobile devices, you can see date and time but for controllers like fingerprint reader, remote controller, keypad etc. you cannot see date and time. Reporting feature is not available for Utopic 2. Reports Tab... - Page 15 - With NEW MOBILE PHONE , search “Desi Utopic” on stores. Download, install and run the application. - Choose desired language and define a password. - Touch “+” on the top left corner to see the list of Utopic motorized cylinders around.
-
Page 16: Locking The Door
4. USAGE 4.1. UNLOCKING AND OPENING THE DOOR If you touch to Unlock button on application screen, system automatically unlocks and opens the door. You can unlock/open the door by using the knob or the key as well. If semi-automatic working is enabled, when you rotate the knob or the key to unlocking way, it will sense the movement and continue automatically. -
Page 17: Maintenance
In this way, the motorized cylinder will shift to Night Mode. To exit from night mode, turn the knob through unlocking way. It will automatically unlock the door and shift to normal working mode. You can shift to or exit from night mode by using key as well. - Page 18 - In this way, motorized cylinder will be reset and all the controllers, including master controller, enrolled to the device will be deleted. Set / Reset Button Desi Alarm and Security Systems Inc. www.desi.com.tr Topkapı Maltepe Cd. Anadolu Sk. N:1 Bayrampaşa - İstanbul / TURKEY...
