- Page 1 7000 ACI PLUS EN INSTALLATION, OPERATION AND MAINTENANCE MANUAL...
- Page 2 MODEL CODE and safe service and to provide comfort in the home for many RIELLO 7000 ACI 60 PLUS 20090056 years to come. Arrange for your buffer tank to be serviced...
-
Page 3: Table Of Contents
CONTENTS GENERAL General Safety Information ..... . 4 Precautions ........4 Description of the appliance . -
Page 4: General
GENERAL GENERAL GENERAL SAFETY INFORMATION 2 PRECAUTIONS The operation of any appliance that uses electrical power demands that a number of fundamental safety precautions be Check that the product is complete, undamaged and as respected. In particular: ordered as soon as you receive it. Report any discrepancies or damage to the dealer who sold it. -
Page 5: Description Of The Appliance
GENERAL 3 DESCRIPTION OF THE APPLIANCE Mod. 200 ÷ 500 7000 ACI PLUS buffer tanks can be used in conjunction with chiller systems, solar panels, heat pumps and wood burning Data plate boilers but are not designed to produce domestic hot water. -
Page 6: System Layout
Fitting for electrical heating element Central heating return Temperature sensor sockets Return to boiler Temperature gauge socket Drain Central heating flow 6 TECHNICAL SPECIFICATIONS 7000 ACI PLUS DESCRIPTION Type of buffer tank Non vitrified Tank layout Vertical Diameter with insulation Height with insulation... -
Page 7: Water Circuit
GENERAL GENERAL 7 WATER CIRCUIT 7000 ACI PLUS buffer tanks can be connected even to previously installed hot water sources, provided care is taken to ensure correct water flow directions. TYPICAL WATER SYSTEM SCHEMATIC Isolating valve 12 Flow temperature sensor... -
Page 8: Location Of Sensors
GENERAL 8 LOCATION OF SENSORS 7000 ACI PLUS buffer tanks incorporate sockets for temperature control sensors. The actual positioning of sensors depends on what components, water connections and control device are installed. The installer is responsible for making all necessary connections to the boiler and solar collectors. Installers must use their expertise to ensure proper installation and functioning in compliance with all applicable legislation. -
Page 9: Overall Dimensions And Water Fittings
GENERAL GENERAL 9 OVERALL DIMENSIONS AND WATER FITTINGS 7000 ACI PLUS DESCRIPTION Polyurethane insulation Vent valve fitting 1" 1"1/4 Ø Sensor sockets 1/2" F Ø Fitting for electrical heating element (not 1 1/2” F Ø supplied) CH flow 1"1/4 F 1"1/4 F... -
Page 10: Installer
INSTALLER 10 UNPACKING THE PRODUCT 11 HANDLING 7000 ACI PLUS buffer tanks are delivered in a single package, Once you have removed the outer packaging, proceed as follows protected by a plastic bag and secured to a wooden pallet. to unpack and handle the buffer tank. -
Page 11: Wall Mounting
13 PLACE OF INSTALLATION (Only for models 7000 ACI PLUS 60-120) 7000 ACI PLUS buffer tanks can be installed in any room where there is no specific requirement for an electrical − Mark the fixing points on the wall using the brackets to protection rating higher than IP X0D. -
Page 12: Technical Assistance Service
TECHNICAL ASSISTANCE SERVICE TECHNICAL ASSISTANCE SERVICE 15 PUTTING INTO SERVICE 16 MAINTENANCE It is essential to perform the following checks before starting up Scheduled maintenance is essential for the safety, efficiency and or testing the functioning of the storage cylinder. In particular, long working life of your buffer tank. -
Page 13: Recycling And Disposal
TECHNICAL ASSISTANCE SERVICE TECHNICAL ASSISTANCE SERVICE 18 RECYCLING AND DISPOSAL At the end of its useful working life, do not abandon the buffer tank in the environment, but dispose of it through the proper channels in accordance with applicable legislation. 19 TROUBLESHOOTING FAULT CAUSE... -
Page 14: End User
END USER END USER END USER INSTRUCTIONS Refer to the GENERAL SAFETY INFORMATION and PRECAUTIONS section for safety-related information. 20 START-UP 21 TEMPORARY SHUTDOWN The buffer tank must be put into service for the first time by To reduce impact on the environment and save energy, before personnel from the manufacturer’s Technical Assistance Service. - Page 15 END USER END USER...
- Page 16 The manufacturer strives to continuously improve all products. Appearance, dimensions, technical specifications, standard equipment and accessories are therefore liable to modification without notice.
