Summary of Contents for Riello 7200/2 HV PLUS
- Page 1 Solar storage cylinders 7200/2 - 1500-2000 HV PLUS EN INSTALLATION INSTRUCTIONS...
-
Page 2: Table Of Contents
Dear Installer, thank you for choosing a Riello 7200/2 HV PLUS solar stor- age cylinder, a modern high quality product, providing you with the utmost wellbeing and with a high level of reliability and safety. This instruction booklet contains important information... -
Page 3: Safety Precautions
Agency that sold you the appliance. The installation of the Riello 7200/2 HV PLUS solar Children and non-assisted disabled people are not storage cylinder should be carried out by a company allowed to use the storage cylinder. -
Page 4: Product Description
3 Product description - the use of the flange to facilitate cleaning and mainte- The solar storage cylinders Riello 7200/2 HV PLUS can be nance, and the magnesium anode with an "anti-corro- integrated into solar systems for the production of do- sion"... - Page 5 Riello 7200/2 HV PLUS Pressure drop TOP COIL Mod. 2000 Mod. 1500 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000 PORTATA (l/h) FLOW RATE (l/h) Pressure drop BOTTOM COIL Mod. 2000 Mod. 1500 1000 1500 2000 2500...
-
Page 6: Water Circuit
SOLAR R - Return The solar storage cylinder Riello 7200/2 HV PLUS is not equipped with load circulators which should be appropriately sized and installed on the system. For the recommended flow rate of the solar heating circuit, see the instructions for assembling the solar collector and the Riello operation and... -
Page 7: Dimensions And Connections
Riello 7200/2 HV PLUS 6 Dimensions and connections (SB) MODELLO 7200/2 DESCRIPTION 1500 HV PLUS 2000 HV PLUS UAC - DHW outlet 1”1/2 F 1”1/2 F Ø MC - Boiler flow 1”1/4 F 1”1/4 F Ø RC - Boiler return 1”1/4 F... -
Page 8: Receiving The Product
NOTE: Tighten to a torque of 25 Nm. Model Riello 7200/2 2000 HV PLUS are supplied in two sep- arate packages: - the first package is composed of the painted tank, pro- tected by a nylon bag and put on wooden pallets. -
Page 9: Installations On Appliances That Are Old Or Need To Be Updated
Riello 7200/2 HV PLUS 9 Installation on appliances that are old or that need to be updated When the solar storage cylinders Riello 7200/2 HV PLUS are REFERENCE VALUES installed on appliances that are old or that need to be... -
Page 10: Deactivation For Long Period
Riello 7200/2 HV PLUS 11 Deactivation for long periods Not using the solar storage cylinder for a long period of time requires that the following operations be carried out: - Empty the solar heating circuit - Close the intercept devices of the sanitary system... -
Page 11: Cleaning The Storage Cylinder And Dismantling The Internal Components
Riello 7200/2 HV PLUS 13 Cleaning the storage cylinder and dismantling the internal components OUTSIDE Cleaning the cover of the storage cylinder should be car- ried out with damp cloths and water and soap. In the case of stubborn stains dampen the cloth with a mix- ture of 50% water and methylated spirit or with specific products for the marks. - Page 12 RIELLO S.p.A. 37045 Legnago (VR) Tel. 0442630111 - Fax 044222378 - www.riello.it The manufacturer strives to continuously improve all products. Appearance, dimensions, technical specifications, standard equipment and accessories are therefore liable to modification without notice.
