SENSIT Technologies ULTRA-TRAC APL Quick Start Instructions

HINTS:

Prepare the area by creating a grid pattern
prior to testing.
Perform all Scans on like-surfaced areas
such as asphalt, concrete, rock, grass.
Do not test on expansion joints or cracks in
the surface.
Be sure rubber pads on actuator and
accelerometers are in place.
Patterns in the markings indicate likely pipe
location.
A minimum of 5 slices must be taken and 3
rows must be scanned to indicate a pattern.

TERMS:

Slice – individual test point
Scan – A series of slices along a single line
Plot – the results of a single scan
CAUTION:
Always setup a grid at a 90-degree angle
from the suspected path of the target line.
The APL must be scanned in a perpendicular
direction to the target line.
Consult instruction manual for product
specifications regarding pipe detection
limits.
851 Transport Drive Phone: 219 465 2700
Valparaiso, IN 46383-8432 Web: www.gasleaksensors.com
Innovative Detection Solutions
MADE IN THE USA
WITH GLOBALLY SOURCED COMPONENTS
Distributed by:
Quick-Start Instructions
This is not a substitute for the
instruction manual. It is for
reference only.
Read and understand the
instruction manual before use.
