Connections
USB USB 2.0 port on back of machine,
Note: Any hardware expansion to the system will require the use of USB devices.
More USB connections are available by adding a self-powered USB hub.
Wired Network 10/100 Ethernet with medical grade isolation: The Intel Ethernet adapter is part of
the 945GSE chipset. Intel 82562 physical layer interface
Driver available at: www.intel.com
IEEE802.11b/g, supports 64/128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK.
Wireless
RT73/RT257x USB chipset.
Network
Or
(one of the
IEEE802.11b/g/n dual band, supports 64/128-bit WEP, WPA, WPAPSK, WPA2,
following)
WPA2-PSK. RT3572 USB chipset.
Driver available at: www.mediatek.com
COM1: Connects to the 2008T functional processor board to support data transfer
Serial
from the 2008T hemodialysis machine to the CDX PC.
COM2: For use with the touchscreen
Additional Drivers
Most operating systems will install the necessary hardware drivers automatically.
Drivers are also available at: www.aaeon.com, under the XTX-945GSE product
CDX PC Specifications for the Intel N3060 Processor
Operating System
Operating User installed (shipped with a Linux OS password = password)
system
The CDX system supports 32 and 64 bit operating systems (Windows 7, Windows
10, and Linux)
BIOS Boot from USB storage
Boot from mSATA flash device
Boot from compact flash device
Boot support for PXE boot (network boot)
Processor Intel N3060 @ 1.6Ghz
Memory 4GB
RAM DDR3 Memory, 4GB installed
SO-DIMM module.
Optional 8GB available as a spare part (P/N 362557-16).
Hard drive space Removable 64GB flash-based memory for data storage of the operating system and
other files.
Video Display
Display size 15"
Display 1024 x 768, 18bits per pixel, LVDS output
resolution
Video controller: Intel N3060 chipset
Chipset Intel N3060 chipset, driver available at: www.intel.com
