Pepwave MAX 600 User Manual

Max series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Pepwave MAX Series:
MAX 600 / 700 / HD2
Document Rev. 5.2
September-11
C
& T
OPYRIGHT
RADEMARKS
Specifications are subject to change without notice. Copyright © 2011 Pepwave Ltd. All Rights Reserved. Pepwave and the
Pepwave logo are trademarks of Pepwave Ltd. Other brands or products mentioned may be trademarks or registered
trademarks of their respective owners.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAX 600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pepwave MAX 600

Summary of Contents for Pepwave MAX 600

  • Page 1 OPYRIGHT RADEMARKS Specifications are subject to change without notice. Copyright © 2011 Pepwave Ltd. All Rights Reserved. Pepwave and the Pepwave logo are trademarks of Pepwave Ltd. Other brands or products mentioned may be trademarks or registered trademarks of their respective owners.

  • Page 2: Table Of Contents

    PRODUCT FEATURES ....................... 6 ......................6 UPPORTED ETWORK EATURES ......................7 THER UPPORTED EATURES PEPWAVE MAX MOBILE ROUTER OVERVIEW ..............8 MAX 600 ............................. 8 MAX 700 ............................. 8 MAX HD2 ..........................10 INSTALLATION ....................... 14 ..........................14 REPARATION ......................14 ONSTRUCTING THE ETWORK ..................
  • Page 3 WINS C ..........................93 LIENT 18.5 VPN ......................... 93 18.6 P / NAT-PMP ........................94 18.7 ..........................94 VENT 18.8 ..........................95 ANDWIDTH APPENDIX A. RESTORATION OF FACTORY DEFAULTS ............. 99 APPENDIX B. DECLARATION....................100 http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 4: Introduction And Scope

    3G HSDPA, EVDO, Wi-Fi, external WiMAX dongle, and Satellite to be utilized to connect to the Internet. This manual presents how to set up the Pepwave MAX Mobile Router and provides an introduction to the features and usage of Pepwave MAX Mobile Router.

  • Page 5: Glossary

    Transmission Control Protocol User Datagram Protocol Virtual Private Network VRRP Virtual Router Redundancy Protocol Wide Area Network Trademark of Wi-Fi Alliance for certified products based on IEEE 802.11 Wi-Fi standards WiMAX Worldwide Interoperability for Microwave Access http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 6: Product Features

    Product Features Pepwave MAX enables all LAN users to share broadband Internet connections, and provide advanced features to enhance Internet access. The following is the list of supported features on Pepwave MAX Mobile Router: Supported Network Features 3.1.1 WAN ...

  • Page 7: Other Supported Features

    Syslog  SIP passthrough  PPTP packet passthrough  Event Log  Active Sessions  Client List  WINS Client List  UPnP / NAT-PMP  Real-Time, Daily and Monthly Bandwidth Usage reports and charts http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 8: Pepwave Max Mobile Router Overview

    Pepwave MAX Mobile Router Overview MAX 600 4.1.1 Front Panel Appearance Wi-Fi WAN Connector PC Card Slot Express Card Slot USB Ports Wi-Fi LAN Connector Ethernet WAN Port Wi-Fi AP LED LAN Ports Wi-Fi WAN LED Status LED Power LED Reset Button 4.1.2 LED Indicators...
  • Page 9 100 Mbps Green LED 10 Mbps Solid Port is connected without traffic Yellow LED Blinking Data is transferring Port is not connected Port Type Auto MDI/MDI-X ports 4.1.3 Rear Panel Appearance Power Connector Terminal Block http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 10 Trying to connect but not connected to any wireless network Wi-Fi WAN Connected to wireless network(s) without traffic Continuous Blinking Transferring data Disabled Intermittent Blinking Enabled but no client associated Wi-Fi AP Client(s) associated to wireless network Continuous Blinking Transferring data to wireless network http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 11 Green LED 10/100 Mbps Solid Port is connected without traffic Yellow LED Blinking Data is transferring Port is not connected Port Type Auto MDI/MDI-X ports 4.2.3 Rear Panel Appearance Power Connector USB Ports Kingston Lock http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 12: Max Hd2

    Continuous Blinking Transferring data LAN and Ethernet WAN Ports 1000 Mbps Green LED 10/100 Mbps Solid Port is connected without traffic Yellow LED Blinking Data is transferring Port is not connected Port Type Auto MDI/MDI-X ports http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 13 4.3.3 Rear Panel Appearance Power Connector Cellular Antenna Connectors Kingston Lock Cellular SIM Slots http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 14: Installation

    Repeat with different cables for up to 4 computers to be connected. With another Ethernet cable or a USB modem / Wi-Fi antenna / PC Card / Express Card, connect it to one of the WAN ports on the Pepwave MAX. Repeat the same procedure for other WAN ports.

  • Page 15: Configuring The Network Environment

    Mounting the Unit 5.4.1 Wall Mount Pepwave MAX can be mounted on the wall by screwing. After adding the screw on the wall, slide the MAX in the screw hole socket as indicated below. Recommeneded Screw Specification: M3.5 x 20mm, Head Diameter 6mm, Head Thickness 2.4mm...
  • Page 16 5.4.2 Car Mount Pepwave MAX can be mounted on a flat surface using the included car mounting plate. Place the car mount according the label’s direction, and screw it onto the device. Mounting Plate Screw Holes After mounting the plate on the back of the device, add screw on the plate on the flat surface.

  • Page 17: Connecting To Web Admin Interface

    Connecting to Web Admin Interface Start a web browser on a computer that is connected with Pepwave MAX through LAN. To connect to Web Admin Interface of Pepwave MAX, enter the following LAN IP address in the address field of the web browser: http://192.168.50.1...
  • Page 18 Configuration changes (e.g. WAN, LAN, Admin settings, etc.) will only take effect after clicking the Save button at the bottom of each page. The Apply Changes button causes the changes to be saved and applied. http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 19: Configuration Of Lan Interface(S)

    Configuration of LAN Interface(s) Basic Settings The LAN Interface settings are located in Network > LAN > Basic Settings: http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 20 Advertise Speed checkbox. DHCP Server Settings When this setting is enabled, the DHCP server of Pepwave MAX automatically assigns an IP address to each computer that is connected via LAN and is DHCP Server configured to obtain an IP address via DHCP.
  • Page 21 This table is for defining custom local DNS records. A static local DNS record consists of a Host Name and an IP Address. When Local DNS looking up the Host Name from the LAN to LAN IP of Pepwave MAX, the Records corresponding IP Address will be returned.

  • Page 22: Wi-Fi Ap

    This field allows you to specify the transmit rate to be used for sending multicast network traffic. Multicast Rate By default, Multicast Rate is set to 1M. Wireless Security Settings This setting specifies which security policy will be used for this wireless network. Security Policy Available options: http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 23 • 802.1X • Static WEP Access Control Settings Restriction Mode This option allows you to perform access control through MAC address filtering. Available options are None, Deny all except listed, and Accept all except listed. http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 24: Configuration Of Wan Interface(S)

    You can also do the above priority setting on the Dashboard, please refer to Section 7 for information. Click the Details button in the corresponding row of connection to modify the connection setting. Important Note Connection Details will be changed and become effective right AFTER clicking the Save and Apply button. http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 25: Ethernet Wan

    Ethernet WAN http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 26 This option allows you to enable bandwidth usage monitoring on this WAN Bandwidth connection for each billing cycle. When this is not enabled, bandwidth usage of Allowance each month is still being tracked but no action will be taken. Monitor See Section 9.5 for configuration details. http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 27 This setting specifies port speed and duplex configurations of the WAN Port. By default, Auto is selected and the appropriate data speed is automatically detected by Pepwave MAX. Port Speed In the event of negotiation issues, the port speed can be manually specified to circumvent the issues.
  • Page 28 If your service provider's DHCP server requires you to supply a hostname value Hostname upon acquiring an IP address, you may enter the value here. If your service (Optional) provider does not provide you with the value, you can safely bypass this option. http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 29 DNS Servers You can input the ISP provided DNS server addresses into the DNS server 1 and DNS server 2 fields. If no address is entered here, this link will not be used for DNS lookups. http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 30 WAN IP address assigned from the PPPoE server.) When Use the following DNS server address(es) is selected, you can put custom DNS server addresses for this WAN connection into the DNS server 1 and DNS server 2 fields. http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 31 IP address of each WAN connection can be associated with a host name. Either upon a change in IP address or every 23 days without link reconnection, Pepwave MAX will connect to the dynamic DNS service provider to perform an IP address update within the provider’s records.

  • Page 32: Express Card / Pc Card / Usb1 / Usb2

    DNS (Domain Name System) Servers are currently effective when a DNS lookup is routed through this connection. DNS Servers This information is obtained from the carrier automatically or can be entered manually by users. http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 33 GSM900 / GSM1800 / GSM2100 is used in Europe, Middle East, Africa, Asia, Band Oceania, and Brazil. If All Bands is chosen, the appropriate frequency band will be used automatically. The default GSM Frequency Band is All Bands. http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 34: Wi-Fi Wan

    This is the Wi-Fi connection name broadcast from the Wi-Fi access point. (SSID) MAC Address This field shows the MAC address of the device at the Wi-Fi access point. (BSSID) Signal Strength This field shows the signal strength of the Wi-Fi connection. http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 35 Open Mode AP access point it finds. By default, this is disabled. If this field is disabled, the WAN connection will not respond to ICMP PING Reply to ICMP requests. PING By default, this is enabled. http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 36 This option allows you to select which security policy is used for this wireless network. Available options: • Open • • WPA/WPA2 – Personal Security • WPA/WPA2 – Enterprise The settings to be displayed under this row will vary depending on the selected security policy. http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 37: Wan Health Check

    WAN Health Check To ensure traffic is routed to healthy WAN connections only, Pepwave MAX provides the functionality to periodically check the health of each WAN connection. The Health Check settings for each WAN connection can be independently configured via Network >...
  • Page 38 Default Health Check Interval is 5 seconds. This setting specifies the number of consecutive ping/DNS lookup timeouts after which Pepwave MAX is to treat the corresponding WAN connection as down. Health Check Default Health Retries is set to 3.

  • Page 39: Bandwidth Allowance Monitor

    Start Day This option allows you to define which day in the month each billing cycle begins. Monthly This field is for defining the maximum bandwidth usage allowed for the WAN Allowance connection each month. http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 40: Wi-Fi Settings

    802.11b Only, and 802.11g Only. By default, 802.11b/g is selected. Operating Country This option set the country whose regulations the Pepwave MAX follows. This option allows you to select which 802.11 RF channel will be utilized. Channel Channel 1 (2.412 GHz) is selected by default.
  • Page 41 By default, this field is set to 48 µs. This field is for specifying the timeout interval for the unit to wait for a CTS response in the RTS/CTS handshake. CTS Timeout By default, this field is set to 48 µs. http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 42: Stp (Spanning Tree Protocol)

    Bridge Priority By default, it is set to 32768. This parameter specifies the preference to provide the best path from the switch to the root switch. Ethernet Path Cost By default, it is set to 100. http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 43: Site-To-Site Vpn

    Pepwave MAX can aggregate all WAN connections’ bandwidth for routing Site-to-Site VPN traffic. Unless all the WAN connections of one site are down, the Pepwave MAX can still maintain VPN up and running. VPN Bandwidth Bonding is supported in firmware 5.1+. All available bandwidth will be utilized to establish the VPN tunnel, and all traffic will be load balanced at packet level across all links.
  • Page 44 Pepwave MAX supports making two Site-to-Site VPN connections with a remote Pepwave MAX unit or a Peplink Balance 210/310/380/390/580/710/1350. The local LAN subnet and subnets behind the LAN (defined under Static Route in the LAN settings page) will be advertised to the VPN. All VPN members (branch offices and headquarters) will be able to route to the local subnets.

  • Page 45: Link Failure Detection

    Important Note to Users Upgrading to Firmware 5.1+ The Site-to-Site VPN in firmware 5.1+ requires the same firmware version for all devices in the VPN network. Please make sure that both ends of the Pepwave MAX (or Peplink devices) are running with the same firmware version.
  • Page 46 WAN connection only. • Pepwave proprietary Site-to-Site VPN used TCP and UDP port 32015 for establishing VPN connections. If you have a firewall in front of the devices, you will need to add firewall rules for these port and protocols which will allow inbound and outbound traffic pass-through the firewall.

  • Page 47: Pepwave Max Behind Nat Router

    10.3 Pepwave MAX Behind NAT Router The Pepwave MAX supports establishing Site-to-Site VPN over WAN connections which are behind a NAT (Network Address Translation) router. To be able for a WAN connection behind a NAT router to accept VPN connections, you can configure the NAT router in front of the WAN connection to forward TCP port 32015 to it.

  • Page 48: Vpn Status

    IP subnets must be unique among VPN peers The entire inter-connected Site-to-Site VPN network is one single non-NAT IP network. No two subnets in two sites shall be duplicated. Otherwise, connectivity problems will be experienced in accessing those subnets. http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 49: Management Of Outbound Traffic To Wan

    11 Management of Outbound Traffic to WAN Pepwave MAX provides the functionality to flexibly manage and load balance outbound traffic among the WAN connections. Important Note Outbound Policy is applied only when more than one WAN connection is active. settings...

  • Page 50: Outbound Policy

    11.1 Outbound Policy There are three main selections for the Outbound Policy for Pepwave MAX:  High Application Compatibility  Normal Application Compatibility  Managed by Custom Rules The selections are explained as follows: Outbound Policy Settings With the selection of this policy, outbound traffic from a source LAN device is...

  • Page 51: Custom Rules For Outbound Policy

    Algorithm to be used. Please refer to the upcoming sections for the details of the available algorithms. To create a custom rule, click Add Rule at the bottom of the table, and the following window will be displayed: http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 52 Enable are taken, by Pepwave MAX based on the other parameters of the rule. With an Enable value of No, the rule does not take effect: Pepwave MAX disregards the other parameters of the rule. This setting specifies the source IP Address, IP Network or MAC Address for Source outbound traffic that matches the rule.
  • Page 53 Matching traffic distributed to USB1 is 40% = (10 / 25) x 100% Matching traffic distributed to USB2 is 0% = (0 / 25) x 100% Matching traffic distributed to Wi-Fi WAN is 20% = (5 / 25) x 100% http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 54 Internet using three different IP addresses. With the algorithm Persistence of Pepwave MAX, rules can be configured to enable client computers to persistently utilize the same WAN connections for e-banking and other secure websites. As a result, a client computer will communicate with the other end using one IP address and eliminate the issues.
  • Page 55 Starting from firmware 5.2, outbound traffic can be prioritized to go through Site-to-Site VPN connection(s). By default, VPN connections are not included in the priority list. (This applies only to Peplink Balance 210 or above) Configure multiple distribution rules to accommodate different kinds of services. http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 56 WAN connection to determine its latency value. The latency of a WAN is the packet round trip time of the WAN connection. Additional network usage may be incurred as a result. http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 57 That means traffic for remote VPN subnets will be routed to its corresponding VPN peer. You can create custom Priority or Enforced rules and move them above the bar to override the Site-to-Site VPN Routes. Upon disabling the Expert Mode, all rules above the bar will be deleted. http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 58: Port Forwarding

    Port Forwarding 12.1 Port Forwarding Service Pepwave MAX can act as a firewall that blocks, by default, all inbound access from the Internet. By using Port Forwarding, Internet users can access the servers behind Pepwave MAX. Inbound Port Forwarding rules can be defined at Advanced > Port Forwarding:...
  • Page 59 Any Port, Single Port, Port Range and Port Map Any Port: All traffic that is received by Pepwave MAX via the specified protocol is forwarded to the servers specified by the Servers setting.

  • Page 60: Ettings

    Check the corresponding box(es) to enable UPnP and/or NAT-PMP. Enable these features only if you trust the computers on the LAN. A table listing all the forwarded ports under these two protocols can be found at Status > UPnP / NAT- PMP. http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 61: Nat Mappings

    IP address. The settings to configure NAT Mappings are located at Advanced > NAT Mappings: To add a rule for NAT Mappings, click Add NAT Rule, upon which the following screen will be displayed: http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 62 Outbound Policy section. Click Save to save the settings when configuration has been completed. Important Note Inbound firewall rules override the Inbound Mapping settings. http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 63: Qos

    This field is to define which User Group the specified Subnet / IP Address Group belongs to. Once users have been assigned to a user group, their internet traffic will be restricted by rules defined for that particular group. Please refer to the following two sections for details. http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 64: Bandwidth Control

    You can define a maximum download speed (over all WAN connections) and upload speed (for each WAN connection) that each individual Staff and Guest member can consume. No limit can be imposed on individual Manager members. By default, Download and Upload Bandwidth Limits are set to unlimited (set as 0). http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 65: Application

    When enabled, voice and video traffic of Skype, Google Talk, RealVideo RealVideo, and Windows and Windows Streaming Media will be prioritized. Streaming Media Secure Web (HTTPS) When enabled, HTTPS (TCP port 443) traffic will be prioritized. http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 66 The DSL/Cable Optimization can relieve such issue. When it is enabled, the download speed will become less affected by the upload traffic. By default, this feature is enabled. http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 67: Firewall

    LAN side of the network. It can protect the local network from potential hacker attacks, offensive Web sites, and/or other inappropriate uses. The firewall functionality of Pepwave MAX supports the selective filtering of data traffic in both directions:  Outbound (LAN to WAN) ...
  • Page 68 Protocol/IP/Port, actions will be taken by Pepwave MAX based on the Enable other parameters of the rule. When No is selected, the firewall rule does not take effect. Pepwave MAX will disregard the other parameters of the rule. This setting is applicable to Inbound Firewall Rules only.
  • Page 69 In addition, a single port, or a range of ports, can be specified for the Source IP & Port setting. This setting specifies the action to be taken by Pepwave MAX upon encountering traffic that matches the both of the following: •...
  • Page 70 If the default inbound rule is set as Allow for NAT enabled WANs, no inbound Allow firewall rules will be required for inbound Port Forwarding and inbound NAT Mapping rules. However, if the default inbound rule is set as Deny, a corresponding Allow firewall rules will be required. http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 71: Intrusion Detection And Dos Prevention

    , check the box Enable for the Intrusion Detection and DoS Prevention and press the Save button. When this feature is enabled, the Pepwave MAX will detect and protect the network from the following kinds of intrusions and denial-of-service attacks.

  • Page 72: Miscellaneous Settings

    The miscellaneous settings include configuration for PPTP Server, Service Forwarding, and Service Passthrough. 16.1 PPTP Server Pepwave MAX has a built-in PPTP Server, which enables remote computers to conveniently and securely access the local network. PPTP server setting is located at Advanced > Misc. Settings > PPTP Server.

  • Page 73: Service Forwarding

    Some ISPs require their users to send e-mails via the ISP’s SMTP server. All outgoing SMTP connections are blocked except those connecting to the ISP’s. The Pepwave MAX supports intercepting and redirecting all outgoing SMTP connections (destined for TCP port 25) via a WAN connection to the WAN’s corresponding SMTP server.
  • Page 74 Outbound Policy (see section 12.1). 16.2.2 Web Proxy Forwarding When this feature is enabled, the Pepwave MAX will intercept all outgoing connections destined for the proxy server specified in Web Proxy Interception Settings, choose a WAN connection with reference to the Outbound Policy, and then forward them to the specified web proxy server and port number.

  • Page 75: Service Passthrough

    Service Passthrough settings can be found in Advanced > Misc. Settings > Service Passthrough: Some Internet services required to be specially handled in a multi-WAN environment. The Pepwave MAX supports handling such services correctly such that Internet applications do not notice it is behind a multi- WAN router.

  • Page 76: System Settings

    For security reasons, after logging in to the administration interface at the first time, changing the administrator password is recommended. Configuring the administration interface to be accessible only from the LAN can further improve system security. Administrative Settings configuration is located at System > Admin Security: http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 77 Admin Settings Router Name This field allows you to define a name for this Pepwave MAX unit. Admin User Name It is set as admin by default and is not customizable. Admin Password This field allows you to specify a new administrator password.
  • Page 78 This option is for specifying the network interfaces through which the Web Admin Interface can be accessible: LAN only Web Admin Access LAN/WAN If LAN/WAN is chosen, a WAN Connection Access Settings form will be displayed. http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 79 To define multiple subnets, separate each IP subnet one in a line. For example: 192.168.0.0/24 10.8.0.0/16 This is to choose which WAN IP address(es) the web server should listen on. Allowed WAN IP Address(es) http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 80: Firmware Upgrade

    Upgrade to send the firmware to Pepwave MAX. Pepwave MAX will then automatically initiate the firmware upgrade process. Please note that all Pepwave devices are equipped to be able to store two different firmware version in two different partitions. A firmware upgrade preformed will always replace the inactive partition. If you want to keep the inactive firmware, you can simply reboot your device with the inactive firmware and then perform the firmware upgrade.

  • Page 81: Time

    17.3 Time The Time Server functionality enables the system clock of Pepwave MAX to be synchronized with a specified Time Server. The settings for Time Server configuration are located at System > Time: Time Server Settings This specifies the time zone (along with the corresponding Daylight Savings Time scheme) in which Pepwave MAX operates.

  • Page 82: Email Notification

    The settings for configuring Email Notification are found at System > Email Notification: Email Notification Settings This option is for enabling Email Notification. If the box Enable is checked, Pepwave MAX sends email messages to a System Email Notification Administrator when the WAN status changes, or when new firmware is available.
  • Page 83 This setting specifies the sender email address reported by the email messages Address sent by Pepwave MAX. This setting specifies the email addresses to which Pepwave MAX should send Recipient’s Email the email messages to. You may enter multiple recipients’ email addresses in Address this field.

  • Page 84: Remote Syslog

    17.5 Remote Syslog The Remote Syslog functionality of Pepwave MAX enables event logging at a specified remote Syslog server. The settings for configuring Remote System Log are found at System > Remote Syslog: Remote Syslog Settings This setting specifies whether or not to log events at the specified remote Syslog Remote Syslog server.

  • Page 85: Snmp

    17.6 SNMP SNMP, or Simple Network Management Protocol, is an open standard that can be used to collect information from the Pepwave MAX Mobile Router. SNMP configuration is located at System > SNMP: SNMP Settings SNMP Device This field shows the router name defined in System > Admin Security.
  • Page 86 This setting specifies via a drop-down menu the one of the following valid privacy protocols: Privacy Protocol • NONE • This setting specifies the privacy password, and is applicable only if the DES Privacy Password privacy protocol is selected. http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 87: Configuration

    17.7 Configuration Backing up the Pepwave MAX settings immediately after successful completion of the initial setup is strongly recommended. The functionality to download and upload Pepwave MAX settings is found at System > Configuration: 17.7.1 Restore Configuration to Factory Settings The Restore Factory Settings button is to reset the configuration to the factory default settings.

  • Page 88: Reboot

    17.8 Reboot This page provides a Reboot button for restarting the system. For highest reliability, Pepwave MAX is equipped with two copies of firmware of different version. You can select the firmware version you would like the device to reboot with.

  • Page 89: Ping Test

    17.9 Ping Test The Ping Test tool in Pepwave MAX performs Pings through a specified Ethernet interface or a Site-to- Site VPN connection. You can specify the number of pings in the field Number of times to a maximum of 10 times, and Packet Size can be specified in the field Packet Size to a maximum of 1472 bytes.

  • Page 90: Traceroute Test

    17.10 Traceroute Test The Traceroute Test tool in Pepwave MAX traces the routing path to the destination through a particular Ethernet interface or a Site-to-Site VPN connection. The Traceroute Test utility is located at System > Tools > Traceroute, illustrated as follows: A System Administrator can use the Traceroute utility to analyze the connection path of a LAN/WAN connection.

  • Page 91: Status

    18 Status This section displays the information of Pepwave MAX on the Device, Active Sessions, Client List, WINS Client List, Site-to-Site VPN, UPnP / NAT-PMP, Event Log, and Bandwidth. 18.1 Device System information is located at Status > Device: System Information This is the name specified in the field Router Name located in System >...

  • Page 92: Active Sessions

    (retrieved from DHCP reservation table or defined by users), current Download and Upload rate and MAC addresses that the Pepwave MAX has offered IP addresses to since it is powered up. Network Name (SSID) and Signal refers to the information about Wi-Fi AP, which is the name of the Network and its signal strength.

  • Page 93: Wins Client

    Click the button Flush All to flush all WINS client records. 18.5 Site-to-Site VPN This is a page showing the current status of Site-to-Site VPN, located at: Status > Site-to-Site VPN Details about peer’s WAN connections would be listed as below. http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 94: Upnp / Nat-Pmp

    Event Log information is located at Status > Event Log: The log section displays a list of events that has taken place on the Pepwave MAX unit. Click the Refresh button to retrieve log entries again. Click the Clear Log button to clear the log. Select 50, 100, or all to show the corresponding number of events in the log.

  • Page 95: Bandwidth

    Click on a date to view the client bandwidth usage of that specific date. This feature is not available if you have selected to view the bandwidth usage of only a particular WAN connection. The Scale of the graph can be set to show in Megabyte (MB) or Gigabyte (GB). http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 96 All WAN Daily Bandwidth Usage Ethernet WAN Daily Bandwidth Usage http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 97 WAN connection. The Scale of the graph can be set to show in Megabyte (MB) or Gigabyte (GB). All WAN Daily Bandwidth Usage http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 98 Ethernet WAN Daily Bandwidth Usage By default, the scale of data size is in MB. 1GB equals to 1024MB. http://www.pepwave.com Copyright @ 2011 Pepwave...

  • Page 99: Appendix A. Restoration Of Factory Defaults

    Restoration of Factory Defaults Appendix A. To restore the factory default settings on a Pepwave MAX unit, follow the steps below: Locate the reset button on the front panel of Pepwave MAX unit. With a paper clip, press the reset button and hold it for at least 10 seconds until the unit reboots itself.

  • Page 100: Appendix B. Declaration

    This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The availability of some specific channels and/or operational frequency bands are country dependent and are firmware programmed at the factory to match the intended destination. http://www.pepwave.com Copyright @ 2011 Pepwave...
  • Page 101 Visit Our YouTube Channel! http://www.youtube.com/PeplinkChannel Contact Us: Address: Hong Kong Office Sales United States Office 17/F, Park Building, http://www.pepwave.com/contact/sales/ 800 West El Camino Real, 476 Castle Peak Road Mountain View Support Cheung Sha Wan CA 94040 http://www.pepwave.com/contact/ Hong Kong United States...
