Summary of Contents for Friedrich DVKA
- Page 1 Installation Manual Ventilation Kit Model : DVKA / DVKB 960-912-11...
-
Page 2: Table Of Contents
VENTILATION KIT INSTALLATION MANUAL TABLE OF CONTENTS 1. Safety Precautions ......................3 2. Included Items........................4 3. Assembly Diagram ......................5 4. Ventilation Kit Installation (DVKA) ...................6 5. Flange Installation (DVKB) ....................7 6. Front Panel Installation.....................9 7. Electrical Wiring To The Indoor Unit ................13... -
Page 3: Safety Precautions
1. Safety Precautions 1. Safety Precautions To prevent injury to the user or other people and property damage, the following instructions must be followed. n Incorrect operation due to ignoring instruction will cause harm or damage. The seriousness is classified by the following indications. WARNING This symbol indicates the possibility of death or serious injury. -
Page 4: Included Items
2. Included Items 2. Included Items ※ Provided by LG. DVKA ¿ Ventilation kit ¡ Bolt ¬ Bolt √ Insulation Item Q’ty ¿ ¡ ¬ √ Figure DVKB Item Flange Screw Q’ty ƒ ≈ Figure M4 x 10... -
Page 5: Assembly Diagram
3. Assembly Diagram 3. Assembly Diagram Installation Manual 5... -
Page 6: Ventilation Kit Installation (Dvka)
4. Ventilation Kit Installation (DVKA) 4. Ventilation Kit Installation (DVKA) 4.1 Cut the styrofoam's groove for ventilation kit(¿) 4-1 and 4-2 are intended to obtain the air inflow path for ventilation. Caution If not used, do not cut the styrofoam. -
Page 7: Flange Installation (Dvkb)
5. Flange Installation (DVKB) 5. Flange Installation (DVKB) 5-1. Use screws (≈) to fix 3 points on the side of the flange (ƒ). Flange 5 Screw 6 5-2. Use screws (≈) to fix 4 points on the upper surface of the flange (ƒ). Screw 6 Flange 5 Installation Manual 7... - Page 8 5. Flange Installation (DVKB) 5-3. Remove four screws which bond drain pan. Indoor Drain pan X bond screw Drain pan 5-4. Attach ventilation kit (¿) to air conditoner with bolt (¡) Indoor Bolt( 2 ) Ventilation Kit ( 1 )
-
Page 9: Front Panel Installation
6. Front Panel Installation 6. Front Panel Installation ※ Part of this instruction is the same as the installation manual. 6-1. Disassemble the front panel packing and remove the front grill and checking edge cover from the front panel. Front grill Edge cover Installation Manual 9... - Page 10 6. Front Panel Installation 6-2. Attach the front panel to the assembly(¿ + ƒ + ≈ + indoor unit) and use bolt(¡) to fix both the front panel and the assembly to the indoor unit. When attaching, get the bracket of the front panel to the hanger of the ventilation kit(¿).[Fig.2] Be sure to assemble the bolts tightly, so that they are tightened to the upper part of the indoor unit.
- Page 11 6. Front Panel Installation 6-3. Close the checking edge. 6-4. Loosen 2 screws and open the cover of the control box. Screw point Screw 6-5. Connect 1 display connector connected to the front panel and 2 wind direction adjusters to the specified area of the indoor unit PCB.
- Page 12 6. Front Panel Installation Ø5.9 ¿Ventilation Kit (DVKA) ¡Ventilation Kit connection flange (DVKB) Supplies Purchased ¬Duct √Hood ƒFilter ≈Fan motor items 1. Ventilation duct(¬) Diameter, Ø5.9 inch and length, 4 m is the requirement and middle duct bending should be less than once.
-
Page 13: Electrical Wiring To The Indoor Unit
7. Electrical Wiring To The Indoor Unit Case I . Acceptable Case II . Not acceptable Room1 Room1 Indoor Unit 1 Indoor Outside Outside Unit 1 Indoor Unit 2 Unit Room2 Room2 Indoor Indoor Unit 3 Unit 2 7. Electrical Wiring To The Indoor Unit 7-1. - Page 14 P/NO : MFL69495701...
