Whittier Wood 2420DUETa Assembly Instructions

Addi writing desk

Advertisement

Model #
2420DUETa
Addi Writing Desk
Duet = Natural finish
Thank you for allowing us to help you furnish your
home. We are certain you will be delighted with
your new furniture for many years to come.
If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a
replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you
cannot order replacement parts through your dealer, please contact our customer service department.
Customer Service: 800-653-3336 • Outside the U.S.: 541-687-0213
CUSTOMER SERVICE
Hours: Our friendly customer service staff can be reached:
Monday-Friday 8:00 a.m. to 5:00 p.m. (Pacific Time).
You may leave a message 24 hours a day, seven days a week.
Fax: 541-687-2060• Email: info@whittierwood.com
P.O. Box 2827
Eugene, OR 97402 USA
IMPORTANT NOTES:
 Wood can be susceptible to changing color over time when exposed to
strong sunlight. Use window shades, drapes or blinds to protect your
furniture. To help the surface age evenly and avoid dark and light
spots, periodically move items to expose the entire surface to an even
amount of light so it may develop a uniform patina.
 For normal household use only. Not recommended for commercial use.
 Do not climb, sit or stand on this piece of furniture.
 Do not overload the drawer.
 Unload items before you move this unit.
 Use a protective pad when you use the top of this piece as a writing
surface.
 This assembly requires two people.
Drilling, sawing, sanding or machining wood products can expose you to
wood dust, a substance known to the state of California to cause cancer.
Avoid inhaling wood dust or use a dust mask or other safeguards for
personal protection.
For more information go to: www.p65warnings.ca.gov/wood
This product can expose you to chemicals, including formaldehyde,
which are known to the State of California to cause cancer.
For more information go to: www.p65warnings.ca.gov/furniture
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
Production Code:
VN
WARNING
08/18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2420DUETa and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Whittier Wood 2420DUETa

  • Page 1 If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you cannot order replacement parts through your dealer, please contact our customer service department.
  • Page 2 5/16" x 30mm Hex Bolt Small Adjustable Glide (installed) Z Hex Wrench 5mm (included) 1/4" x 13.5mm Insert Nut (inserted) #8 x 2" Black Screw (inserted) 5/16" x 10mm T-Nut (inserted) Straight Hex Wrench 5mm (included) 2420DUETa — Page 2 — 08/18...
  • Page 3 (B) and place it off to the side. See Figure 1. Fig. 1 Attach four Legs (C) to the Top Assembly (Aa) with sixteen 5/16" x 30mm Hex Bolts (J). See Figure 2. x 16 Fig. 2 2420DUETa — Page 3 — 08/18...
  • Page 4 This item includes an adjustable drawer stop to allow for adjusting the alignment of the profile of the drawer front to the profile of the Top Assembly. To adjust the alignment rotate the Adjustable Glide (K) as needed. See Figures 4 and 4a. Fig. 4 (Bottom view) Fig. 4a 2420DUETa — Page 4 — 08/18...
