Model #
2401AUFd
McKenzie
4-Drawer Desk
Assembly Instructions
Thank you for allowing us to help you furnish your
home. We are certain you will be delighted with
your new furniture for many years to come.
If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a
replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you
cannot order replacement parts through your dealer, please contact our customer service department.
Customer Service: 800-653-3336 • Outside the U.S.: 541-687-0213
CUSTOMER SERVICE
Hours: Our friendly customer service staff can be reached:
Monday-Friday 8:00 a.m. to 5:00 p.m. (Pacific Time).
You may leave a message 24 hours a day, seven days a week.
Fax: 541-687-2060• Email: info@whittierwood.com
P.O. Box 2827
Eugene, OR 97402 USA
IMPORTANT NOTES:
• For normal household use only. Not recommended for commercial use.
• Do not climb, sit or stand on this piece of furniture.
• Use a protective pad when you use the top of this piece as a writing
surface.
• Do not overload the drawers.
• Unload items before you move this unit.
• Before you begin your project, completely read the Assembly
Instructions and Finishing Hints.
• This assembly requires two people.
Drilling, sawing, sanding or machining wood products can expose you to
wood dust, a substance known to the state of California to cause cancer.
Avoid inhaling wood dust or use a dust mask or other safeguards for
personal protection.
For more information go to: www.p65warnings.ca.gov/wood
This product can expose you to chemicals, including formaldehyde,
which are known to the State of California to cause cancer.
For more information go to: www.p65warnings.ca.gov/furniture
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
Production Code:
VN
WARNING
03/17
Advertisement
Related Manuals for Whittier Wood 2401AUFd
Summary of Contents for Whittier Wood 2401AUFd
- Page 1 If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you cannot order replacement parts through your dealer, please contact our customer service department.
- Page 2 Small Knob (attached) 4 x 35mm Machine Screw (installed) Twin Push Latch (attached) #8 x 7/8" Black Lo-Profile Screw (inserted) #8 x 1-1/4" Pan Head Screw (inserted) #8 x 1-3/4" Pan Head Screw (inserted) 2401AUFd — Page 2 — 03/17...
- Page 3 5/16" Flat Washer 3/8" x 2-1/2" Hex Bolt Adjustable Glide (installed) #6 x 1/2" Undercut Screw (inserted) 3mm x 12mm Pan Head Screw (inserted) 1/4" x 20mm Insert Nut (inserted) #8 x 1-3/8" Lo-Profile Screw (inserted) 2401AUFd — Page 3 — 03/17...
- Page 4 Insert eight 3/8" x 2-1/2" Hex Bolts (ZF) with eight 5/16" Flat Washers (ZE) through the corner blocks and into the Legs (C). Fasten securely. See Figures 2 and 2a. Fig. 2a Fig. 2 2401AUFd — Page 4 — 03/17...
- Page 5 See Figures 4b and 4c. (To hang letter-sized files parallel to the drawer face.) Fig. 4 Fig. 4a (To hang letter-sized files perpendicularly.) (To hang legal-sized files perpendicularly.) Fig. 4c Fig. 4b 2401AUFd — Page 5 — 03/17...
- Page 6 Place the desk at its final destination. To level the unit, rotate the Adjustable Glides (ZG) found on the bottoms of the legs. See Figure 6. Use a protective pad when you use the top of this piece as a writing surface. 2401AUFd — Page 6 — 03/17...
- Page 7 Whittier Finishing Hints instructions call for a slow drying glue. Carefully read the Checklist of materials □ □ □ label and instructions of the glue manufacturer. Your unit Rubber gloves Tack cloth #220 & #320 may not need glue. □ □...
-
Page 8: Preparing The Surface
Whittier Finishing Hints Preparing the surface apply additional coats. Lightly sand and wipe surface with a lint-free rag or tack cloth between coats. Sand each piece with #220 grit sandpaper. Sand with the grain of the wood on flat surfaces and opposite the Some finishes tend to slightly raise the grain.
