Roller misfeed

1. Open the scanner lid.
2. Seize the misfeed paper, and remove the paper from the feed area by
carefully pulling it to the right using both hands.
3. Close the scanner lid. Then load the removed pages back into the ADF.

CLEARING PAPER JAMS

When a paper jam occurs, the warning message appears on the display
screen. Refer to the table below to locate and clear the paper jam.
MESSAGE LOCATION OF JAM
Paper Jam 0 In the paper feed area
and inside the machine
Open/Close Door
Paper Jam 1 Inside the machine
Check Inside
Paper Jam 2 Inside the machine and
in the fuser area
Check Inside
Some messages may not appear in the display depending on options
or models.
To avoid tearing the paper, pull the jammed paper out gently and
slowly. Follow the instructions in the following sections to clear the
jam.
In the tray 1
1. Open and close the front cover. The jammed paper is automatically
2. Pull the tray 1 out of the machine.
3. Remove the jammed paper by gently pulling it straight out.
GO TO
See "In the tray 1" on
page 71, "In the fuser
unit area" on page 71.
See "In the tray 1" on
page 71, "In the fuser
unit area" on page 71.
4. Insert the tray 1 into the machine until it snaps into place. Printing
See "In the tray 1" on
page 71, "In the fuser
unit area" on page 71.

In the fuser unit area

If paper is jammed in the fuser unit area, follow the next steps to release the
jammed paper.
1. Open the scan unit.
ejected from the machine.
If the paper does not exit, go to the next step.
If the paper does not move when you pull, or if you do not see the paper
in this area, check the paper exit area. (See "In the paper exit area" on
page 72.)
automatically resumes.
Troubleshooting_ 71
