Whittier Wood 1242DUETa Assembly Instructions

Addison upholstered bench

Advertisement

Quick Links

Model #
1242DUETa
Addison
Upholstered
Bench
DUET finish
Thank you for allowing us to help you furnish your
home. We are certain you will be delighted with
your new furniture for many years to come.
If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a
replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you
cannot order replacement parts through your dealer, please contact our customer service department.
Customer Service: 800-653-3336 • Outside the U.S.: 541-687-0213
CUSTOMER SERVICE
Hours: Our friendly customer service staff can be reached:
Monday-Friday 8:00 a.m. to 5:00 p.m. (Pacific Time).
You may leave a message 24 hours a day, seven days a week.
Fax: 541-687-2060• Email: info@whittierwood.com
P.O. Box 2827
Eugene, OR 97402 USA
IMPORTANT NOTES:
 Wood can be susceptible to changing color over time when exposed to
strong sunlight. Use window shades, drapes or blinds to protect your
furniture. To help the surface age evenly and avoid dark and light
spots, periodically move items to expose the entire surface to an even
amount of light so it may develop a uniform patina.
 For normal household use only. Not recommended for commercial use.
 Do not climb or stand on or in this piece of furniture.
 This assembly requires two people.
Drilling, sawing, sanding or machining wood products can expose you to
wood dust, a substance known to the state of California to cause cancer.
Avoid inhaling wood dust or use a dust mask or other safeguards for
personal protection.
For more information go to: www.p65warnings.ca.gov/wood
This product can expose you to chemicals, including formaldehyde,
which are known to the State of California to cause cancer.
For more information go to: www.p65warnings.ca.gov/furniture
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
Production Code:
VN
WARNING
08/18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1242DUETa and is the answer not in the manual?

Questions and answers

Summary of Contents for Whittier Wood 1242DUETa

  • Page 1 If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you cannot order replacement parts through your dealer, please contact our customer service department.
  • Page 2 3/8" x 2-1/2" Hex Bolt 1/4" x 20mm Insert Nut (inserted) 1/2" x 2-1/4" Wood Dowel (inserted) 3/8" x 1-1/2" Wood Dowel (inserted) Adjustable Glide (installed in Legs) #8 x 1-1/4" Pan Head Screw 1242DUETa — Page 2 — 08/18...
  • Page 3 Insert the Center Seat Support (D) using the dowel and the dowel hole at the center of the Side Frame Assembly (B) as shown in Figure 2a. Secure with a #8 X 1-1/4" Pan Head Screw (M). See Figures 2 and 2a. Fig. 2 Fig. 2a 1242DUETa — Page 3 — 08/18...
  • Page 4 Fig. 3 Using the pocket holes as guides, secure the Leg Frame Assembly to the Upholstered Seat (A) with eleven #8 x 1-1/4" Pan Head Screws (M). See Figure 4. x 11 Fig. 4 1242DUETa — Page 4 — 08/18...
  • Page 5 See Figure 5. Fig. 5 Please note: Our upholstered seat is covered in Bonded Leather. To clean it, simply use a soft cloth, mild soap and water. DO NOT use alcohol based cleaning agents. 1242DUETa — Page 5 — 08/18...
