16013805000
TREADMILL DESK
OWNER'S MANUAL
PLEASE CAREFULLY READ THIS ENTIRE MANUAL BEFORE OPERATING YOUR NEW TREADMILL DESK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 16013805000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sole Fitness 16013805000

Summary of Contents for Sole Fitness 16013805000

  • Page 1 16013805000 TREADMILL DESK OWNER’S MANUAL PLEASE CAREFULLY READ THIS ENTIRE MANUAL BEFORE OPERATING YOUR NEW TREADMILL DESK...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Product Registration Important Safety Instructions Important Electrical Instructions Grounding Instructions Important Operation Instructions Treadmill Desk Assembly Instructions Folding Instructions Transport Instructions Console Operation Setting Stride Length for Step Count General Maintenance Service Checklist – Diagnosis guide Exploded View Diagram Parts List Warranty customerservice@dyaco.ca...

  • Page 3: Product Registration

    CONGRATULATIONS ON YOUR NEW TREADMILL DESK AND WELCOME TO THE SOLE FAMILY! Thank you for your purchase of this quality SOLE treadmill from Dyaco Canada Inc. Your new treadmill has been manufactured by one of the leading fitness manufacturers in the world and is backed by one of the most comprehensive warranties available.
  • Page 4 BEFORE YOU BEGIN Thank you for choosing the SOLE Treadmill Desk. We take great pride in producing this quality product and hope it will provide many hours of quality exercise to make you feel better, look better, and enjoy life to its fullest. It's a proven fact that a regular exercise program can improve your physical and mental health.

  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS WARNING - Read all instructions before using this equipment. DANGER - To reduce the risk of electric shock disconnect your SOLE treadmill from the electrical outlet prior to cleaning and/or service work. WARNING - To reduce the risk of burns, fire, electric shock, or injury to persons, install the treadmill on a flat level surface with access to a 120-volt, 15-amp grounded outlet with only the treadmill plugged into the circuit.

  • Page 6: Important Electrical Instructions

    IMPORTANT ELECTRICAL INSTRUCTIONS WARNING! NEVER use a ground fault circuit interrupt (GFCI) wall outlet with this treadmill. As with any appliance with a large motor, the GFCI will trip often. Route the power cord away from any moving part of the treadmill including the elevation mechanism and transport wheels.

  • Page 7: Important Operation Instructions

    Do not use excessive pressure on console control keys. They are precision set to function properly with little finger pressure. If you feel the buttons are not functioning properly with normal pressure contact your Authorized SOLE Fitness dealer. SAFETY TETHER CORD A safety tether cord is provided with this unit.
  • Page 8 PREVENTATIVE MAINTENANCE CHART Vacuum Under Clean&Inspect Lubricate Deck Motor Deck for Inspect Belt (Every 90 hours Cover&Check Lubrication Tracking(Monthly) Date of use or sooner Wiring (Every (Every Other Adjust if necessary if dry) Other Month) Month) customerservice@dyaco.ca Dyaco Canada Inc. 2018...
  • Page 9 WARNING DECAL REPLACEMENT The decal shown below has been placed on the treadmill. If the decal is missing or illegible, please call our Customer Service Department toll-free at 1-888-707-1880 to order a replacement decal. customerservice@dyaco.ca Dyaco Canada Inc. 2018...

  • Page 10: Treadmill Desk Assembly Instructions

    TREADMILL DESK ASSEMBLY INSTRUCTIONS !!ATTENTION: IMPORTANT UNPACKING INSTRUCTIONS. PLEASE READ BEFORE UNPACKING YOUR TREADMILL DESK!! Serious injury could occur if this treadmill is not unpacked properly. There is a Velcro strap installed around the treadmill base that prevents the treadmill from unfolding accidentally during shipping.
  • Page 11 Connect the Fixed Upright Assembly (113) with the Frame Base Tube (L.R) (116) and use L Allen Wrench (141) to tighten 16pcs of 3/8" × UNC16 × 1/2"_Button Head Socket Bolts (135). HARDWARE #135. 3/8" × 1/2" Button Head Socket Bolt (16 pcs) customerservice@dyaco.ca Dyaco Canada Inc.
  • Page 12 Lay the Desk Board (120) on the Sliding Upright Assembly (114). Use two Nuts (121) to secure with Desk Board Stand (115). Secure the Desk Board Stand (115) onto the Sliding Upright Assembly (114) by using the open end of the wrench (140) and the Allen wrench (141) to tighten 2pcs of 3/8"...
  • Page 13 1. Slide the Computer Cable Upper (46) into the console Bracket assembly (106) to connect to the Console assembly (66). Use the Phillips Head Screwdriver (139) to tighten 4pcs of M5 × P0.8 × 12L_Phillips Head Screw (112) to secure the Console assembly (66) with the Console Bracket Assembly (106).
  • Page 14 Use the Allen wrench (142) and the Wrench (140) to tighten 4pcs of 5/16" × UNC18 × 2" Button Head Socket Bolts (70), together with 4pcs of 5/16" × UNC18 × 7T(mm) Nyloc Nuts (79) to secure the two Limit Brackets (R.L) (118.119) through both Frame Base Tubes (116).
  • Page 15 To adjust the distance between the desk and the treadmill, the user can adjust the position of the treadmill by moving the unit on the limit brackets to the desired position. The console assembly can be secured on the desk after positioning the treadmill. customerservice@dyaco.ca Dyaco Canada Inc.
  • Page 16 TREADMILL DESK FOLDING INSTRUCTIONS Do not attempt to move the unit unless it is in the folded and locked position. Be sure the power cord and console cable are secured to avoid possible damage. Use both handrails to maneuver the unit to the desired position.

  • Page 17: Folding Instructions

    FOLDING INSTRUCTIONS ■TO FOLD THE TREADMILL Disconnect the power cord and computer cable from the desk board stand. Move the unit backward or fold the desk board then fold up the treadmill deck. Lift the treadmill running deck until it is secured by the locking telescoping tube assembly in center back of base.

  • Page 18: Console Operation

    OPERATION OF YOUR TREADMILL Getting familiar with the treadmill console controls GETTING STARTED: Power the treadmill on by plugging it into an appropriate wall outlet, then turn on the power switch located at the front of the treadmill below the motor hood. Ensure that the Safety Key is installed, as the treadmill will not operate without it.
  • Page 19 PAUSE/STOP/RESET FEATURE When the treadmill is running the pause feature may be utilized by pressing the STOP key once. This will slowly decelerate the tread-belt to a stop. The Time, Distance and Calorie readings will hold while the unit is in the pause mode. After five minutes the display will reset and return to the start up screen. To resume your exercise, when in Pause mode, press the START key.
  • Page 20 (SL.) DISPLAY: To show workout information time, distance...etc.. SAFETY KEY: Attach the safety key in its position to power on the computer. When safety key is pulled away from its position, the computer will shut down automatically. DIRECT SPEED KEYS: 3 preset buttons for direct speed: 1kph/1mph, 2kph/2mph, 3kph/3mph.

  • Page 21: Setting Stride Length For Step Count

    SETTING STRIDE LENGTH (S.L.): Use the chart below for a quick guide to determine your stride length by using your height. While this is not as accurate as some other methods, it can give you a close estimate of your stride length. For a more accurate stride length, measure your walking step from toe to toe in CM.

  • Page 22: General Maintenance

    GENERAL MAINTENANCE WARNING: Always unplug your treadmill prior to cleaning in order to avoid electrical hazard or shock. BELT & DECK Your treadmill uses a very high-efficient low-friction deck. Performance is maximized when the deck is kept as clean as possible. Use a soft, damp cloth, or paper towel to wipe the edge of the belt and the area between the belt edge and the frame.
  • Page 23 When an adjustment is made to the belt tension, you must also make a tracking adjustment to compensate for the change in belt tension. This is accomplished by turning both the tension and tracking Allen bolts an equal amount. This adjustment should be made by turning both bolts clockwise by no more than a 1/4 turn at a time.
  • Page 24 BELT/DECK LUBRICATION First, you want to clean between the belt and deck to remove any debris that may be trapped. Use a clean, non-fraying rag, t-shirt, or light towel. Halfway between the end of the treadmill and motor cover, shove the garment under the belt until you can grasp it on both sides of the belt. Drag the garment the length of the entire belt 1-2 times.

  • Page 25: Service Checklist - Diagnosis Guide

    SERVICE CHECKLIST – DIAGNOSIS GUIDE Before contacting your dealer for aid, please review the following information. It may save you both time and expense. This list includes common problems that may not be covered under the treadmill’s warranty. PROBLEM SOLUTION/CAUSE Display does not light up 1.
  • Page 26 CALIBRATION PROCEDURE Remove the Safety Key. Press and hold down the Start and Fast buttons and replace the Safety Key, then press the Enter key. 3. You will now be able to set the display to show mile or km settings (Miles vs. Kilometers). To do this, press the Fast /Slow key to show which you want, then press Enter.

  • Page 27: Exploded View Diagram

    EXPLODED VIEW DIAGRAM customerservice@dyaco.ca Dyaco Canada Inc. 2018...

  • Page 28: Parts List

    PARTS LIST Part # Description 8050001 Main Frame 8050002 Frame Base 8050003 Seat Slider 8050004 Outer Slider 8050005 Link 8050006 Link Shaft 8050007 Shaft Bushing 8050008 Fastening Bracket 8050009 Clevis Pin 8050010 Fastening Bushing 8050011 Dual Torsion-Spring 8050012 Release Lever 8050013 Slide Wheel , Urethane 8050014...
  • Page 29 Part # Description 8050051 Aluminum Foot Rail 8050052 Ø 5.5 × 27 × 60 × 1.5T × 3.5H_Concave Washer 8050053 Controller Back Plate 8050054 Top Motor Cover Plate 8050055 Front Motor Cover 8050056 Adaptor 8050065 Power Cord 8050066 Console assembly 8050067 Bottom Frame Cover 8050068...
  • Page 30 Part # Description 80500105 Wire Tie Mount 80500106 Console Bracket Assembly 80500107 Tension Knob 80500108 M8_Bushing Washer 80500110 107 × 60 × 1m/m_Foam Pad 80500111 Ø 49 × 1m/m_Foam Pad 80500112 M5 × 12L_Phillips Head Screw 80500113 Fixed Upright Assembly 80500114 Sliding Upright Assembly 80500115...

  • Page 31: Warranty

    MANUFACTURER’S LIMITED WARRANTY Dyaco Canada Inc. warrants all its treadmill parts for a period of time listed below from the date of retail sale, as determined by sale receipt. Dyaco Canada Inc.’s responsibilities include providing new or remanufactured parts, at Dyaco Canada Inc.’s option, and technical support to our independent dealers and servicing organizations.
  • Page 32 Please visit us online for information about our other brands and products manufactured and distributed by Dyaco Canada Inc. www.dyaco.ca www.dyaco.ca www.dyaco.ca www.dyaco.ca www.spiritfitness.ca www.spiritmedical.ca www.dyaco.ca www.dyaco.ca www.solefitness.ca www.trainorsports.ca www.dyaco.ca www.dyaco.ca www.xterrafitness.ca www.dyaco. Dyaco Canada Inc. 2017 customerservice@dyaco.ca...

  • Page 33: Customerservice@Dyaco.ca Dyaco Canada Inc

    customerservice@dyaco.ca Dyaco Canada Inc. 2017...
