  • Page 1 SCL-2 ® In-Wall Loudspeaker OWNER’S MANUAL...

  • Page 2: Table Of Contents

    JBL products are the hands-down choice of leading recording artists and sound engineers. The SCL-2 is the latest member of the JBL Synthesis Home Theater system. To get the best performance from your new loudspeaker, please read these instructions thoroughly.

  • Page 3: Speaker Placement

    Left and Right channel speakers (Figure 3). Figure 3 www.jbl.com...
  • Page 4 NOTE: Some perforated projection screens have a batten bar or crossbar centered across the screen frame (Figure 4). In such cases make sure the bar does not block the horn. Position vertically oriented speakers so that the bar crosses in front of the speakers at the edge of the horn closest to the central woofer. Figure 4 If a non-perforated projection screen, LCD/plasma/OLED display is being used in the installation, the SLC-2 may be used in horizontal orientation mounted directly below or above and as close as possible to the video display (Figure 5).

  • Page 5: Surround Speakers

    In a 7.1-channel system, two speakers are added for rear fill, in addition to the surround speakers in a 5.1-channel system. The two additional speakers are placed on the rear wall or near the rear wall in the ceiling (Figure 7). LEFT RIGHT SIDE SIDE LEFT RIGHT REAR REAR Figure 7 www.jbl.com...

  • Page 6: General Installation Notes

    5. Speakers and electronics terminals have corresponding positive (+) and negative (–) terminals. Most manufacturers of speakers and electronics, including JBL, Inc., use red to denote the (+) terminal and black for the (–) terminal. Please confirm before connecting.
  • Page 7 5. Proceed to install the back box and speaker following the instructions elsewhere in this manual. Low Frequency Bi-Amp Connection Receiver/Amplifier (Be sure to remove internal jumpers) Side View of SCL-2 with Speaker Connection Panel High Frequency Receiver/Amplifier Figure 10 Single-Amp Jumper Hot (Blue) Single-Amp Jumper Ground (Blue) Figure 11 www.jbl.com...

  • Page 8: Back Box Installation

    Figure 12 IMPORTANT NOTES: The JBL SYNTHESIS SCL-2 speaker requires a minimum 6-inch (152mm) wall depth. The SCL-2 is a large, heavy loudspeaker. Installation will go more smoothly and safely with two people. We strongly suggest enlisting the aid of a helper when installing this product.
  • Page 9 10. Make sure the back box is securely attached to the frame and then remove the mounting bars completely. Discard. 11. Repeat step 8 with the remaining mounting holes Figure 15 Move to BAFFLE ASSEMBLY WIRING AND INSTALLATION on Page 11. www.jbl.com...
  • Page 10 HORIZONTAL ORIENTATION INSTALLATION STEPS: IF INSTALLING IN NEW CONSTRUCTION (PRE-DRYWALL), SKIP STEP 1 Cut a 46" wide x 14.5" high (971.6mm x 292.1mm) hole in the drywall. The center of the hole should align with the center of the video display. Cut completely through the wall studs that fall inside the space needed for the SCL-2 (Figure 16).

  • Page 11: Baffle Wiring And Installation

    5. Secure perimeter baffle mounting screws and tighten (See WARNINGS concerning over-tightening screws!). 6. Remove JBL Logo adhesive back and insert onto the grille with proper orientation. 7. Place the zero bezel metal onto baffle. Align the top edge and then let the grille gently ‘drop’...

  • Page 12: Specifications

    Ga naar JBLSYNTHESIS.COM voor de handleiding in andere talen. Gå til JBLSYNTHESIS.COM for bruksanvisning på flere språk. Если вам требуется дополнительные версии руководства пользователя на других языках, посетите сайт JBLSYNTHESIS.COM. 別の言語に対応したユーザーマニュアルを読むには、 JBL SYNTHESIS.COMにアクセスしてください。 사용자 설명서에 대한 추가 언어 지원은 JBLSYNTHESIS.COM에서 확인하십시오 请访问 JBLSYNTHESIS.COM 以获取其他语言版本的用户手册。...
  • Page 13 Торговая марка: Назначение товара: Пассивная акустическая система Изготовитель: Харман Интернешнл Индастриз Инкорпорейтед, США, 06901 Коннектикут, г.Стэмфорд, Атлантик Стрит 400, офис 1500 Страна происхождения: Китай Импортер в Россию: OOO “ХАРМАН РУС СиАйЭс“, Россия, 127018, г.Москва, ул. Двинцев, д.12, к 1 Гарантийный период: 1 год...
