1. OVERVIEW
QUADBAR 16 IP
Outdoor LED Bar - 16 LEDs 4-en-1 de 5W
Quadbar 16 IP is an outdoor LED bar that has 16
RGBW 5W LEDs with quadcolor LED technology
that allows a smooth RGBW mix without multicolor
shadows. The unit has a beam angle of 40º and is
ideal both for surface washing and for generating
stunning visual effects, both for its coverage and for
its power. Quadbar 16 IP has an electronic dimmer
of 0-100%, with four selectable dimmer curves, 14
integrated programs and IP66 rating, guaranteeing
an optimal performance in any climatic situation.

Specifications

Source & Optics
• Light Source: 16 4-in-1 RGBW Prolight 5W LEDs
• LEDs life: 50,000 hours
• Beam angle: 40º
Photometric data
• Luminous flux: 1,120 Lux @ 3M (10 ft.)
Effects & Functions
• Quad-color LED technology: Smooth RGBW mix
with no multi-colored shadows
• Dimmer: 0-100% general & for all colors
• Strobe effect
• 4 dimming curves
• 14 built-in programs
• 15 color presets
Control
• RDM function
• DMX Channels: 4/6/9
• Operational modes: DMX, Master/Slave, Au-
to-run, manual and built-in programs
P. 2
Tecshow Quadbar 16 IP |
English version
Physical
• LED Display
• IP Rating: IP65
• DMX connectors: 2 Outdoor XLR connectors
(XLR-3 input and output)
• IP66 In/Out power supply connectors
• Dimensions: 1008x145x145 mm. / 39.7x5.7x5.7 in.
• Weight: 6.2 Kg. / 13.6 Lbs.
