Information about the device

Device description
The Qube+ consists of only one device and is 50 % lighter and
50 % smaller than a comparable MultiQube tower.
A multi-device installation with complex hose connections can
be omitted without replacement. Just set it up, plug it in, switch
it on – all done! No further equipment technology is required.
The device comes ready for connection with all integrated parts:
a powerful fan motor, a water separator, a 4-stage filter system
and an efficient silencer – ultra-compact, united in a robust,
stackable aluminium construction, offering clearly more
advantages and at the same time causing considerably less
costs than multi-device solutions.
Globally unique integral solution:
• VX 5 turbine
• Water separator WA 4i
• HEPA filter module
• Silencer NR 19
Equipment features:
• Adaptronic power control for flexible low-pressure surface
drying operations ranging from 8 m
• Globally unique HiDry automatism for all power stages
• Optiflow NT multi-function display
• Non-wearing touchscreen control panel
• Counter for operating hours and energy consumption
(MID-compliant)
• Night operation – whisper mode
• 2 TTKwic quick couplings for drainage connection of
dehumidifiers
• Flexible 4-stage filter system
• DA 4 interface
• Efidry humidity sensor connection
• Residual water draining
• Connection for discharge of hot process air
• Service socket (tamper-proof)
• Cable holder
• Key lock to prevent maloperation
• ECO level (stage 1) for small surfaces
• Height-adjustable telescopic push handle
4
2 2
to 85 m
insulation drying unit Qube+
The device is equipped with a touch screen with LC display.
It provides information on the operating stage, air flow rate etc.
The background colour of the LC display changes according to
the traffic light principle to indicate how suitable your drying
installation is. An optimal air flow rate is indicated by a green
background colour during operation. If the display is illuminated
in yellow, this means that the installation is OK but the flow
conditions for the dry air are not optimal. Drying can be carried
out without any difficulties while the display is yellow. A red
background indicates an uneconomic operation. The
compressor should not be permanently operated in this
condition.
Practical benefits:
• The most light, compact and powerful system unit on the
market
• 50 % smaller than a comparable MultiQube installation, up
to 75 % smaller than constructions from competitors
• Flexible filter system with optional HEPA filter usage
• Total weight only 27 kg
• Stackable
With the device all negative time factors can be eliminated in
one sweep – this way less devices are needed and moved,
stock requirements are reduced, more equipment can be
transported to the damage site per tour, less time is needed for
set-up and disassembly as well as for cleaning. All in all, your
working, space and warehouse productivity can be increased
many times over by using the Qube+!
