- Page 1 By cmlam at 10:33 am, Jul 18, 2017 Wireless TENS Pain Reliever WT1 Series...
-
Page 2: Table Of Contents
Content Introduction Parts Features General Warnings and Safety 5 - 7 Using your Wireless TENS Pain Reliever 8 - 12 Troubleshooting Positions for use Mode Selection Specification Compatibility EMC 17 - 24 Maintenance and Cautions Explanation of Symbols on Unit Explanation of Symbols on Unit... -
Page 3: Introduction
Introduction Thank you for buying the Kinetik Wireless TENS Pain Reliever, a safe drug free way to relieve every day and long-term pain. Multiple stimulation and intensity settings allow you to customize your treatment for different parts of the body and levels of pain. -
Page 4: Parts
Parts About Wireless TENS Pain Reliever MAIN UNIT PARTS Front 1. On/Off switch 2. Intensity Increase Main Unit and Mode Change 3. Intensity Decrease and Mode Change Back 4. Battery Compartment Gel Pad x 1... -
Page 5: Features
Features • Single output channel. • Unit is adjusted via main control. • 5 mode settings to provide different pain relief and massage effects. • 15 output intensities to suit different parts of the body and pain. • Touch control buttons. •... -
Page 6: General Warnings And Safety
General Warnings and Safety Before you start: Please carefully read and understand the following warnings and cautions to ensure the safe and correct use of this device and to prevent injury. • Make sure the batteries are installed correctly. • Completely remove gel pad from both protective plastic covers. •... - Page 7 General Warnings and Safety Gel Pad not suitable for use on: • Head • Face • Throat • Back of neck • Heart • Chest area • Eyes • Oral cavity • Sexual organs • Spine • Bones • Scarred areas following surgery for at least 10 months after the operation •...
-
Page 8: General Warnings And Safety
General Warnings and Safety Be aware of the following. (1) to consult with your physician before using this device. The simulation with the device may: i. cause lethal rhythm disturbances to the heart in susceptible individuals, and, ii. disrupt the healing process after a recent surgical procedure; (2) that the device is not effective for pain of central origin, including headache;... -
Page 9: Using Your Wireless Tens Pain Reliever
Using your Wireless TENS Pain Reliever Instructions for use: 1. Before use, place a CR2032 battery into the battery compartment on the back of the Pain Relief Pad. As illustrated in the schematic, a coin-like tool is recommended to be used to open the battery compartment, and place the battery into the compartment with the side marked with “CR2032”... - Page 10 Using your Wireless TENS Pain Reliever 3. Follow the schematic to install the pad included onto the back side of the Pain Relief Pad unit. This should be done before applying pads onto the skin of treatment areas. Note – please keep the protective transparent film.
- Page 11 Using your Wireless TENS Pain Reliever 5. Press the On/Off button to turn on the unit, indicated by the light on for 3 seconds. 6. When turned on, the unit works at a default mode of combining Massage, Acupuncture, Tapping, and Scraping.
- Page 12 Using your Wireless TENS Pain Reliever Gel Pad Every gel pad is protected by a transparent and blue protective film. Connect the gel pad to the unit by initially removing the blue protective film, laying the gel pads onto the TENS machine and then removing the transparent film.
-
Page 13: Using Your Wireless Tens Pain Reliever
Using your Wireless TENS Pain Reliever Recommended practices: • Duration of 20 minute for each body area. • Frequency of 1-2 times per day per area. • Start from the lowest intensity and gradually adjust to a comfortable level on a scale level from 1 to 15. •... -
Page 14: Troubleshooting
Troubleshooting Problem Check points Possible solution Is the battery exhausted? Replace the battery. The unit does not switch on Is the battery installed correctly? Insert the battery observing correct polarity. No output stimulus/sensation Have you removed the transparent Remove the protective film. protective film from the gel pad? Is the gel pad stuck on the skin properly? Re-attach the gel pad correctly. -
Page 15: Positions For Use
Positions for use Back Waist Shoulder Arms... -
Page 16: Mode Selection
Mode Selection Remark: Modes are selected by pressing the “+” or “-“ buttons for 3 seconds. Pressing the “+” button for 3 seconds will select modes in the below order. Similarly, pressing the “-“ button for 3 seconds will select the desired mode in the opposite order. When the mode is changed from one to another, the light will flash twice. -
Page 17: Specification
Specification • Size: 11.7 x 7.1 x 1.1 cm • Weight: 19 g • Power supply: DC 3V, CR2032 battery • Output voltage: 40 V at 500 Ω • Pulse width: 100 µS • Frequency: 0-200 Hz • Timer: 20 min •... -
Page 18: Compatibility Emc
Compatibility EMC 1) This product needs special precautions regarding EMC and needs to be installed and put into service according to the EMC information provided, and this unit can be affected by portable and mobile RF communications equipment. 2) Do not use a mobile phone or other devices that emit electromagnetic fields, near the unit. This may result in incorrect operation of the unit. - Page 19 Compatibility EMC Guidance and manufacture’s declaration – electromagnetic emission The WT1 is intended for use in the electromagnetic environment specified below. The customer of the user of the WT1 should assure that it is used in such an environment. Emission test Compliance Electromagnetic environment –...
- Page 20 Compatibility EMC Guidance and manufacture’s declaration – electromagnetic immunity The WT1 is intended for use in the electromagnetic environment specified below. The customer or the user of the WT1 should assure that it is used in such an environment. Immunity test IEC 60601 test level Compliance level Electromagnetic environment - guidance...
- Page 21 Compatibility EMC Guidance and manufacture’s declaration – electromagnetic immunity The WT1 is intended for use in the electromagnetic environment specified below. The customer or the user of the WT1 should assure that it is used in such an environment. Immunity test IEC 60601 test level Compliance level Electromagnetic environment - guidance...
- Page 22 Compatibility EMC Guidance and manufacture’s declaration – electromagnetic immunity The WT1 is intended for use in the electromagnetic environment specified below. The customer or the user of the WT1 should assure that it is used in such an environment. Immunity test IEC 60601 test level Compliance level Electromagnetic environment - guidance...
- Page 23 Compatibility EMC Guidance and manufacture’s declaration – electromagnetic immunity The WT1 is intended for use in the electromagnetic environment specified below. The customer or the user of the WT1 should assure that it is used in such an environment. Immunity test IEC 60601 test level Compliance level Electromagnetic environment - guidance...
- Page 24 Compatibility EMC Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the WT1 is used exceeds the applicable RF compliance level above, the WT1 should be observed to verify normal operation.
- Page 25 Compatibility EMC Recommended separation distances between portable and mobile RF communications equipment and the WT1. The WT1 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the WT1 can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the WT1 as recommended below, according to the maximum output power of the communications equipment.
-
Page 26: Maintenance And Cautions
Maintenance and Cautions CAUTIONS REGARDING SAFETY • Do not immerse device in water or any liquid. Do not drop device or throw it from a height. • After using the device, please re-attach unit to protective transparent film. • Always use the protective film when pads are not in use. •... -
Page 27: Explanation Of Symbols On Unit
Explanation of Symbols on Unit Read the instructions (actual symbol colours are white on a blue background). This symbol indicates that this product is a Type BF device. Symbol for "Environment Protection" – Waste electrical products should not be disposed of with household waste. - Page 28 Harvard Medical Devices Ltd. Unit 1002, 10th Floor, Railway Plaza, 39 Chatham Road South, Tsimshatsui, Kowloon, Hong Kong. Kinetik Medical Devices Ltd. Medicity Nottingham, D6 Building West, Thane Road, Nottingham. NG90 6BH 0197 Made in PRC Kinetik WT1 UK IB 20170718...
