add if0
add if1
dhcp server start:(ip:192.168.4.1,mask:255.255.255.0,gw:192.168.4.1)
bcn 100
finish

6.2.2. ESP8266 AT

If users download the ESP8266 AT firmware, or the default firmware in ESP-LAUNCHER or
ESP-WROOM-02, the system in working mode will display "Ready" at the end. Input
command "AT" in the terminal and the system will return "OK", which means that the
firmware works properly.
�� Notes:
The baud rate in AT firmware is configured as 115200 manually, however, the default baud rate of
•
ESP8266 is 74880, due to this discrepancy, the system initialization information will be displayed as
mojibake. It is a normal phenomenon as long as the system shows "Ready" at the end.
For more information on AT commands, please refer to
•
6.3. Configuration of RF initialization (Optional)
Before downloading binaries to flash, users can modify the RF initialization settings in the
RF InitConfig tab. The newly-generated esp_init_data_setting.bin can be downloaded to
the flash instead of esp_init_data_default.bin. Users can configure both the options and
the parameters of the RF settings.
