Installation of this product requires detailed knowledge of automotive systems and repair
procedures. We recommend that this installation be carried out by a qualified automotive
technician.
Installation of this product requires handling of gasoline. Ensure you are working in a well
ventilated area with an approved fire extinguisher nearby. Extinguish all open flames, prohibit
smoking and eliminate all sources of ignition in the area of the vehicle before proceeding with the
installation.
When installing this product, wear eye goggles and other safety apparel as needed to
protect yourself from debris and sprayed gasoline.
The fuel system may be under pressure. Do not open the fuel system until any pressure
has been relieved. Refer to the appropriate vehicle service manual for the procedure and
precautions for relieving the fuel system pressure.
The enclosed Aeromotive fuel pump utilizes o-ring sealed AN-04 style inlet, outlet and impuse ports; these
ports are NOT PIPE THREAD and utilize NO THREAD SEALANT.
To use this pump in your vehicle's fuel system, we strongly recommend the following:
Utilize AN-04 or 5/16" fuel lines and fittings for all connections (Call Aeromotive for availability.)
Mount the pump such that it is no more then 10 inches away from the impuse signal source.
A high capacity, 100 micron fuel filter should be installed between the fuel tank or cell and the
pump inlet (Aeromotive p/n 12316).
We recommend Aeromotive fuel filter p/n 12316. Call us for info.
Failure to follow the above recommendations may result in fuel leakage, poor vehicle performance and/or
decreased fuel pump life! Improper installation will void all warranties for this product!
Aeromotive system components are not legal for sale or use on emission controlled motor vehicles.
DO NOT RUN THE PUMP DRY! Excessive diaphragm wear will result if the pump runs dry.
AEROMOTIVE
Part # 11207
INSTALLATION INSTRUCTIONS
CAUTION:
WARNING!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 11207 and is the answer not in the manual?

Questions and answers

Related Manuals for Aeromotive 11207

Summary of Contents for Aeromotive 11207

  • Page 1 Refer to the appropriate vehicle service manual for the procedure and precautions for relieving the fuel system pressure. The enclosed Aeromotive fuel pump utilizes o-ring sealed AN-04 style inlet, outlet and impuse ports; these ports are NOT PIPE THREAD and utilize NO THREAD SEALANT.
  • Page 2 2. Disconnect the existing pump fuel lines. Plug the open fuel line ends and remove the existing pump. 3. Find a suitable place on the vehicle chassis to mount the Aeromotive fuel pump. Make sure the location will accommodate the pump mounting bolts, will position the pump as close to the engine as possible with the impulse input port facing downwards, is clear of the exhaust, is clear of any moving suspension or drivetrain components and will keep the pump clear of road obstructions or debris.
  • Page 3 11. Test-drive the vehicle to insure proper operation and re-check the fuel system for leaks. If any leaks are found, immediately discontinue use of the vehicle and repair the leak(s)! AEROMOTIVE, INC. 7805 Barton Street, Lenexa, KS 66214 913-647-7300 fax 913-647-7207...
  • Page 4 AEROMOTIVE, INC. LIMITED WARRANTY This Aeromotive Product, with proof of purchase dated on or after January 1, 2003, is warranted to be free from defects in materials and workmanship for a period of one year from the original date of purchase.
