INSTALLATION INSTRUCTIONS
Installation
automotive systems and repair procedures. We recommend that this
installation be carried out by a qualified automotive technician.
Installation of this product requires handling of gasoline. Ensure you
are working in a well ventilated area with an approved fire extinguisher
nearby. Extinguish all open flames, prohibit smoking and eliminate all
sources of ignition in the area of the vehicle before proceeding with the
installation.
When installing this product, wear eye goggles and other safety
apparel as needed to protect yourself from debris and sprayed gasoline.
The fuel system is under pressure. Do not open the fuel system until
the pressure has been relieved. Refer to the appropriate vehicle service
manual for the procedure and precautions for relieving the fuel system
pressure.
The enclosed Aeromotive regulator utilizes two o-ring sealed ORB-10 style ports, and one
o-ring sealed ORB-08 style bypass port; These ports are NOT PIPE THREAD and utilize NO
THREAD SEALANT. ORB port fittings with the proper o-ring installed are required.
The enclosed Aeromotive fuel pressure regulator is intended to be installed on the outlet
side of an unmodified Aeromotive A3000 Fuel pump, Aeromotive p/n 11216 or 11222. It
must be installed with a return line from the regulator to the top of the fuel tank. It is
designed for the purpose of creating and maintaining stable line pressure in a range
between 14-24 PSI, for carbureted engine applications where a dead-head or static style
regulator is installed at the carburetor(s).
The regulator is not preset from the factory and must be adjusted to 18 psi.
This kit contains the following parts:
1ea 11217 By-Pass Style, HP (High Pressure) Regulator
2ea 1/4-28x 2-1/4" mounting screws
2ea Fuel pump mounting O-Rings (1 required, 1 spare)
Aeromotive system components are not legal for sale or use on emission controlled motor vehicles
Aeromotive Commonly used part numbers for your reference:
15608 ORB-10/AN-10 Port Fitting. (Outlet Fitting)
15607 ORB-08/AN-08 Port Fitting. (By-Pass Fitting)
AEROMOTIVE
Part # 11217
A3000 Regulator Assembly
CAUTION:
of
this
product
WARNING!
requires
detailed
knowledge
of
Advertisement
Table of Contents
Related Manuals for Aeromotive 11217
Summary of Contents for Aeromotive 11217
- Page 1 2ea 1/4-28x 2-1/4" mounting screws 2ea Fuel pump mounting O-Rings (1 required, 1 spare) Aeromotive system components are not legal for sale or use on emission controlled motor vehicles Aeromotive Commonly used part numbers for your reference: 15608 ORB-10/AN-10 Port Fitting. (Outlet Fitting)
- Page 2 A3000 fuel pump. If using a “dead head” (non-return) style regulator at the carburetor (Aeromotive P/N 13208 or 13210 for example), the HP Regulator is typically mounted directly to the fuel pump outlet port. The HP Regulator assembly may be clocked relative to the pump in 45-deg increments for optimum clearance of the adjusting stud and bypass line.
- Page 3 Note: The HP Regulator is adjustable from 14-24 PSI line pressure and has been pre- set for 18 PSI from the factory, ample to feed most dead-head style regulators. Plumbing Diagram for Engines using Dead-Head Style regulator at the Carburetor such as Aeromotive Pro-Stock 4-Port P/N 13208 and 2-Port P/N 13210.
- Page 4 In these applications, it may be advantageous to move the HP bypass regulator off the pump and into the engine compartment to better facilitate a full flow, dynamic fuel system. The A3000 HP Regulator is designed to “stack” onto the end of multiple, Aeromotive stackable regulators (Aeromotive part # 13217). (FIGURE 1-2) FIGURE 1-2 The “stackable”...
- Page 5 Thread the o-ring side of an ORB-08/AN-08 port fitting into the regulator return port and block the opposite (outlet) end with an ORB-10 port plug such as Aeromotive P/N 15617. 11. Plan the routing of and Install the AN-08 by-pass fuel line from the fuel HP Bypass Regulator return port back to the top of the fuel cell.
- Page 6 13. Test drive the car to insure proper operation and re-check the fuel system for leaks. If any leaks are found, immediately shutoff the engine and repair the leak(s)! AEROMOTIVE, INC. 7805 Barton Street, Lenexa, KS 66214 913-647-7300 fax 913-647-7207...
- Page 7 AEROMOTIVE, INC. LIMITED WARRANTY This Aeromotive Product, with proof of purchase dated on or after January 1, 2003, is warranted to be free from defects in materials and workmanship for a period of one year from the original date of purchase.
