Aeromotive 13214 Installation Instructions

Installation of this product requires detailed knowledge of automotive

systems and repair procedures. We recommend that this installation be carried

out by a qualified automotive technician.

Installation of this product requires handling of gasoline. Ensure you are

working in a well ventilated area with an approved fire extinguisher nearby.

Extinguish all open flames, prohibit smoking and eliminate all sources of ignition

in the area of the vehicle before proceeding with the installation.

When installing this product, wear eye goggles and other safety apparel as

needed to protect yourself from debris and sprayed gasoline.

The fuel system may be under pressure. Do not open the fuel system until

any pressure has been relieved. Refer to the appropriate vehicle service manual

for the procedure and precautions for relieving the fuel system pressure.

NOTE: Testing the enclosed regulator by applying air pressure or vacuum to the vacuum port with a hand-

held pump will yield poor results, due to the slight air leakage through the adjustment screw threads. This

minute leakage, which is typical of all adjustable fuel pressure regulators, does not, in any way, affect the

performance of the regulator.

The enclose Aeromotive regulator utilizes a o-ring sealed AN-10 supply port on the side of the

regulator and one o-ring sealed AN-10 style bypass port on the bottom of the regulator (This port

requires a cutoff AN-10 style fitting Aeromotive P/N 15608 or equiv.); these regulator ports are NOT

PIPE THREAD and utilize NO THREAD SEALANT.

The enclosed Aeromotive regulator is designed to be used with high flow (300 gph minimum) belt

or cam driven fuel pumps similar to Aeromotive P/N 11105 or 11107. Performance may be

degraded if a similar pump is not used.

Aeromotive system components are not legal for sale or use on emission controlled motor vehicles.

AEROMOTIVE

Part # 13214

INSTALLATION INSTRUCTIONS

CAUTION:

WARNING!

Table of Contents

Need help?

Do you have a question about the 13214 and is the answer not in the manual?

Page 1 The enclose Aeromotive regulator utilizes a o-ring sealed AN-10 supply port on the side of the regulator and one o-ring sealed AN-10 style bypass port on the bottom of the regulator (This port requires a cutoff AN-10 style fitting Aeromotive P/N 15608 or equiv.);...
Page 2 Remove any regulator mounting hardware and connecting fuel lines, then carefully remove the regulator. 3. Find a suitable place in the vehicle’s engine compartment to mount the Aeromotive regulator. Using the supplied mounting bracket as a template, mark the bracket mounting holes and drill to accept a #10 screw.
Page 3 12. With the fuel pressure gauge registering fuel system pressure, check for fuel leaks from and around the Aeromotive regulator and all fuel lines and connections! If any fuel leaks are found, remove any spilled fuel and repair the leak before proceeding! 13.
Page 4 AEROMOTIVE, INC. LIMITED WARRANTY This Aeromotive Product, with proof of purchase dated on or after January 1, 2003, is warranted to be free from defects in materials and workmanship for a period of one year from the original date of purchase.
