Aeromotive 13217 Installation Instructions

Fuel systems

13217 INSTALLATION INSTRUCTIONS

Installation of this product requires detailed knowledge of automotive systems and

repair procedures. We recommend that this installation be carried out by a qualified automotive

technician.

Installation of this product requires handling of gasoline. Ensure you are working in a

well ventilated area with an approved fire extinguisher nearby. Extinguish all open flames,

prohibit smoking and eliminate all sources of ignition in the area of the vehicle before

proceeding with the installation.

When installing this product, wear eye goggles and other safety apparel as needed to

protect yourself from debris and sprayed gasoline.

The fuel system may be under pressure. Do not open the fuel system until any pressure

has been relieved. Refer to the appropriate vehicle service manual for the procedure and

precautions for relieving the fuel system pressure.

The enclosed Aeromotive regulator utilizes two o-ring sealed AN-10 style inlet ports and two o-

ring sealed AN-6 style outlet ports; these regulator ports are NOT PIPE THREAD and utilize NO

THREAD SEALANT.

Performance Specifications: Model 13217

Outlet Fuel Pressure, adjustable

Inlet Ports

Outlet Ports

Aeromotive system components are not legal for sale or use on emission controlled motor vehicles.

The following steps are typical of most installations:

1. Once the engine has been allowed to cool, disconnect the negative battery cable and relieve the

fuel system pressure.

2. Place shop towels around the existing regulator to catch any gasoline that is spilled during this step

of the installation. Remove any regulator mounting hardware and connecting fuel lines, then

carefully remove the regulator.

CAUTION:

WARNING!

5-12 psi

2x AN-10 or O-Ring Sealed Flange

2x AN-06

Table of Contents

Do you have a question about the 13217 and is the answer not in the manual?

Page 1 Refer to the appropriate vehicle service manual for the procedure and precautions for relieving the fuel system pressure. The enclosed Aeromotive regulator utilizes two o-ring sealed AN-10 style inlet ports and two o- ring sealed AN-6 style outlet ports; these regulator ports are NOT PIPE THREAD and utilize NO THREAD SEALANT.
Page 2 3. Find a suitable place in the vehicle’s engine compartment to mount the Aeromotive regulator. Using two flange mounting holes as a template, fabricate a bracket mounting. 4. If using more than one regulator, place the supplied o-ring in the o-ring groove on one of the regulator bodies.
Page 3 12. With the fuel pressure gauge registering fuel system pressure, check for fuel leaks from and around the Aeromotive regulator and all fuel lines and connections near the regulator! If any fuel leaks are found, turn the fuel pump OFF, remove any spilled fuel and repair the leak before proceeding! 13.
Page 4 AEROMOTIVE, INC. LIMITED WARRANTY This Aeromotive Product, with proof of purchase dated on or after January 1, 2003, is warranted to be free from defects in materials and workmanship for a period of one year from the original date of purchase.
