Installation of this product requires detailed knowledge of automotive systems and repair procedures. We
recommend that this installation be carried out by a qualified automotive technician.
Installation of this product requires handling of gasoline. Ensure you are working in a well ventilated area
with an approved fire extinguisher nearby. Extinguish all open flames, prohibit smoking and eliminate all sources
of ignition in the area of the vehicle before proceeding with the installation.
When installing this product, wear eye goggles and other safety apparel as needed to protect yourself
from debris and sprayed gasoline.
The fuel system is under pressure. Do not open the fuel system until the pressure has been relieved.
Refer to the appropriate vehicle service manual for the procedure and precautions for relieving the fuel system
pressure.
The enclosed Aeromotive fuel pump utilizes an o-ring sealed AN-12 style outlet ports; this port is NOT PIPE THREAD
and utilizes NO THREAD SEALANT.
To use this pump in your vehicle's fuel system, we strongly recommend the following:
Gravity feed the pump by mounting it lower than the fuel cell.
Utilize high pressure fuel lines, fittings and o-rings for all connections from the
fuel cell to the engine.
Failure to follow the above recommendations may result in fuel leakage, bursting of the fuel lines, poor vehicle
performance and/or decreased fuel pump life! Improper installation will void all warranties for this product!
Aeromotive system components are not legal for sale or use on emission controlled motor vehicles.
Performance Specifications: Model 11117
Fuel Compatibility
Port Sizes
Recommended Fuel Pressure regulator:
EFI System
Carbureted System
AEROMOTIVE Part # 11117
INSTALLATION INSTRUCTIONS
Gasoline & Methyl Alcohol
1 ¼" or AN-16 Inlet & AN-12 Outlet
Aeromotive p/n 13110
Aeromotive p/n 13202
Not For Street Use!
CAUTION:
WARNING!
Advertisement
Table of Contents
Related Manuals for Aeromotive 11117
Summary of Contents for Aeromotive 11117
- Page 1 Refer to the appropriate vehicle service manual for the procedure and precautions for relieving the fuel system pressure. The enclosed Aeromotive fuel pump utilizes an o-ring sealed AN-12 style outlet ports; this port is NOT PIPE THREAD and utilizes NO THREAD SEALANT.
- Page 2 2. Raise the vehicle and support it with jack stands. 3. Using a suitable timing cover, mount the Aeromotive fuel pump adapter clamp to the timing cover using the supplied screws. Loosen the clamping screw on the adapter, slide the front of the fuel pump into the adapter clamp and tighten down the clamp bolt.
- Page 3 Protect fuel lines from abrasion and track obstructions or debris. 7. If you are using this fuel pump with an EFI style fuel system we recommend using Aeromotive p/n 13110 Fuel Pressure Regulator. For Carbureted fuel systems we recommend using Aeromotive Regulator p/n 13202.
- Page 4 AEROMOTIVE, INC. LIMITED WARRANTY This Aeromotive Product, with proof of purchase dated on or after January 1, 2003, is warranted to be free from defects in materials and workmanship for a period of one year from the original date of purchase.
